Used Letterpress Machine for sale (64,015)

Condition: refurbished (used), functionality: limited functionality, Year of construction: 2003, operating hours: 24,000 h, pipe diameter (max.): 100 mm, pipe length (max.): 4,100 mm, bending angle (max.): 183 °, bending radius (max.): 300 mm, wall thickness: 8 mm, Transfluid DB 2090 DB CNC Mandrel Tube Bending Machine. Excellent High Quality Germany Machine, with fully refurbished main hydraulic pumps and main head fully reconditioned. Only requires new encoder to be fitted and this machine is ready to go. Features include. 100mm x 1.6mm Tube Maximum Capacity at 1.5D Anticipated Mandrel Withdrawal Fully automatic setup of clamps and follower Klsdpfxetrd T Tj Ah Njl Boosted Follower for tight radius thin wall tube bending. Long bed with 4000mm over mandrel. Comes with huge amount of tooling worth over AU$150k. Tooling Included: 101.6mm 152mm CLR 101.6mm 200mm CLR 76.2mm 114mm CLR 76.2mm 200mm CLR 76.2mm 238mm CLR 63.5mm 96mm CLR 57.2mm 86mm CLR 50.8mm 76mm CLR 44.5mm 67mm CLR 40 x 40 120mm CLR 50 x 50 150mm CLR 60.3mm 150mm CLR 48.3mm 120mm CLR

Year of construction: 2026, operating hours: 1 h, condition: new, functionality: fully functional, machine/vehicle number: Mzbp06, Equipment: CE marking, The fully automatic horizontal automatic cartoning machine is a high-tech product integrating optics, electronics, pneumatics, and mechanics. Kljdpfxsya Uq No Ah Nel It is suitable for the automatic cartoning of various products. Its workingprocess involves the conveying of items; automatic opening andconveying of cartons; automatic loading of materials into the cartons;and automatic gluing and tongue insertion, among other complex sealingprocesses. The machine's exterior is entirely constructed of high-qualitystainless steel and is innovatively designed in strict accordance with thepharmaceutical industry's "GMP" standards. The transmission system isdesigned with overload protection and an emergency stop device. Theoperating system uses a human-machine interface video screen to ensureoperator safety.

Condition: like new (used), functionality: fully functional, Year of construction: 2026, operating hours: 8 h, machine/vehicle number: BD38NCCOMP, bending angle (max.): 190 °, overall weight: 900 kg, total length: 3,100 mm, total width: 950 mm, total height: 1,500 mm, power: 6 kW (8.16 HP), input voltage: 220 V, type of input current: AC, warranty duration: 12 months, Semi-Automatic Single-Head Hydraulic Pipe Bending Machine BD50NC2A Machine Model: BD38NCCOMP Machine Applications  Transportation Sector For locomotives, automobiles, and bicycles: exhaust manifolds, brake lines, fuel supply conduits, steering mechanisms, air - conditioning ducting systems, seating assemblies, balancing components, bumper structures, window frame assemblies, handlebar components, and frame structures.  Furniture Industry Indoor and outdoor seating and table sets, office furniture including desks and chairs, shelving units, bed frames and associated furniture pieces.  Leisure and Recreation Industry Fitness apparatus, infant strollers, utility carts, and amusement ride installations.  HVAC (Heating, Ventilation, and Air - Conditioning) and Appliance Industry Water heating units, electric heating appliances, gas - fired cooktops, refrigeration units, and air - conditioning equipment.  Heavy Industrial Sphere Piping networks for boilers, heat exchanger, power generation plants, chemical processing facilities, diesel engine manufacturing, and shipbuilding operations.  Diverse Other Industries Household consumer goods, rehabilitation - oriented medical devices, sanitary fixtures, the decoration and interior design sector, the construction industry, agricultural machinery and equipment, and the aviation manufacturing and maintenance industry. Specification The largest applicable carbon steel pipe (bending radius ≥ 2d) Φ38×2.0mm (thickness Max. 2.0) The largest applicable stainless steel pipe (bending radius ≥ 2d) Φ38×1.5mm (thickness Max. 1.5) Maximum core length (*) 850mm Kledpfx Ahoya An Ns Njl Critical Parts and Functional Components Maximum bending radius (*) 320mm Maximum bend angle 190° The number of bends that can be set for each pipe fitting (*) 25 bends The number of pipe fitting files can be set 280 sets (extensible) Working speed bending speed Max.90°/s Machine tool bending angle ±0.1°

Condition: like new (used), functionality: fully functional, Year of construction: 2026, operating hours: 8 h, machine/vehicle number: BD63CNC4A2SP, control type: CNC control, degree of automation: automatic, actuation type: electric, pipe diameter (max.): 63 mm, bending angle (max.): 190 °, overall weight: 1,800 kg, total length: 4,000 mm, total width: 1,000 mm, total height: 1,300 mm, power: 18 kW (24.47 HP), input voltage: 380 V, type of input current: AC, number of digital displays: 1, warranty duration: 12 months, Equipment: emergency stop, foot remote control, Full-Automatic Single-Head CNC Bending Machine with Auxiliary Push Function Machine Model: BD63CNC4A2SP Machine Applications  Transportation Sector For municipal engineering, locomotives, automobiles, and bicycles: exhaust manifolds, brake lines, fuel supply conduits, steering mechanisms, air - conditioning ducting systems, seating assemblies, balancing components, bumper structures, window frame assemblies, handlebar components, and frame structures.  Furniture Industry Indoor and outdoor seating and table sets, office furniture including desks and chairs, shelving units, bed frames and associated furniture pieces.  Leisure and Recreation Industry Fitness apparatus, infant strollers, utility carts, and amusement ride installations.  HVAC (Heating, Ventilation, and Air - Conditioning) and Appliance Industry Water heating units, electric heating appliances, gas - fired cooktops, refrigeration units, and air - conditioning equipment.  Heavy Industrial Sphere Kljdpfxjyaz Egs Ah Nsl Piping networks for boilers, heat exchanger, power generation plants, chemical processing facilities, diesel engine manufacturing, and shipbuilding operations.  Diverse Other Industries Household consumer goods, rehabilitation - oriented medical devices, sanitary fixtures, the decoration and interior design sector, the construction industry, agricultural machinery and equipment, and the aviation manufacturing and maintenance industry. Specification Model: BD63CNC4A2SP The Largest Applicable Carbon Steel, Copper, Aluminum Pipe or Profiles Φ63×2.0MM (THICKNESS MAX. 2.0) OR PROFILES AS PER MOLD DESIGN * The Largest Applicable Stainless Steel or High Alloy Steel Pipe, Profile Etc. Φ55×2.0MM (THICKNESS MAX. 2.0) OR PROFILES AS PER MOLD DESIGN * Maximum Reciprocating Feeding Pipe Φ63MM PROFILE AS PER MOLD DESIGN * Maximum Feeding Stokes (*) 3200MM Maximum Bending Radius (*) 550MM Maximum Bend Angle 190° Maximum Core Pulling Distance 3500MM Equipment Working Height 1300MM Pipe Bending Servo Power 7.0KW Pipe Bending Speed MAX. 150°/S ADJUSTABLE Bending Accuracy ±0.1° Feeding Servo Power 2.0KW Feeding Speed 200-1000MM/S ADJUSTABLE Feeding Accuracy ±0.1MM Rotation Servo Power 1.0KW Rotation Speed 180°/S ADJUSTABLE Rotation Accuracy ±0.1° Hydraulic Motor 7.5KW Hydraulic System Pressure 12 MPA Total Power 18 KW Equipment Size: Length * Width * Height 4000*1000*1300mm Equipment Weight 1800KG

Condition: like new (used), Year of construction: 2026, operating hours: 8 h, functionality: fully functional, machine/vehicle number: SG202640, total length: 1,500 mm, power: 4 kW (5.44 HP), overall weight: 650 kg, total width: 800 mm, total height: 1,150 mm, input voltage: 380 V, warranty duration: 12 months, Pipe Shrinking, Profile Forming Machine SG40NC Kledpfx Aoyak Ikoh Nol Machine Model: SG40NC Product Description: Microcomputer-controlled and hydraulically driven. Equipped with a mobile foot switch featuring three functions: automatic operation, emergency stop, and continuous emergency stop, ensuring high safety. Capable of multiple processing methods including tube Forming, tube expanding, tube end blunting, and bulging. Processed shapes include concave-convex joints, elongated, flat, square, flared, angled, V-shaped, open elbow, etc. Molds can be changed according to the user’s processed products. Mold replacement is simple and convenient, facilitating flexible production. The machine has a compact and sturdy structure, uses hydraulic power, operates stably with a high yield rate, minimal vibration, and low noise. It can perform tube end reduction, expansion, bulging, upsetting rib forming, and other shape forming processes. Suitable for processing various shapes at the connecting parts of pipe fittings (for insertion), automotive oil pipes, air ducts, water pipes, and air conditioning pipes. Maximum Tube Forming Capacity mm Ø40×2mm Maximum Tube Forming Length mm 100mm Motor Power kW 4 Weight kg 600

Condition: like new (used), functionality: fully functional, Year of construction: 2026, operating hours: 8 h, machine/vehicle number: 2026BD25, bending angle (max.): 190 °, overall weight: 1,000 kg, total length: 1,800 mm, total width: 850 mm, total height: 1,230 mm, power: 8 kW (10.88 HP), input voltage: 380 V, type of input current: AC, warranty duration: 12 months, control cabinet height: 1,200 mm, Single - Head Servo CNC Pipe Bending Machine BD25CNC3A1S Machine Model: BD25CNC3A1S Machine Applications  Transportation Sector For locomotives, automobiles, and bicycles: exhaust manifolds, brake lines, fuel supply conduits, steering mechanisms, air - conditioning ducting systems, seating assemblies, balancing components, bumper structures, window frame assemblies, handlebar components, and frame structures.  Furniture Industry Indoor and outdoor seating and table sets, office furniture including desks and chairs, shelving units, bed frames and associated furniture pieces.  Leisure and Recreation Industry Fitness apparatus, infant strollers, utility carts, and amusement ride installations.  HVAC (Heating, Ventilation, and Air - Conditioning) and Appliance Industry Water heating units, electric heating appliances, gas - fired cooktops, refrigeration units, and air - conditioning equipment.  Heavy Industrial Sphere Piping networks for boilers, heat exchanger, power generation plants, chemical processing facilities, diesel engine manufacturing, and shipbuilding operations.  Diverse Other Industries Household consumer goods, rehabilitation - oriented medical devices, sanitary fixtures, the decoration and interior design sector, the construction industry, agricultural machinery and equipment, and the aviation manufacturing and maintenance industry. Maximum Bending Pipe Diameter × Wall Thickness (Normal Steel, Aluminum, Copper etc.) Φ25mm×1.2mm Maximum Bending Radius R150mm Maximum Bending Angle 190° Maximum Feeding Length 1200mm Working Speed: Bending Speed Max. 150°/s Working Speed: Pipe Rotating Speed Max. 200°/s Working Speed: Feeding Speed Max. 1000mm/s Working Precision: Bending Precision ±0.1° Working Precision: Pipe Rotating Precision ±0.1° Working Precision: Feeding Precision ±0.1mm Data Transmission Mode 1. Coordinates (X.Y.Z) 2. Working Values (Y.B.C) Bending Mode Servo Bending Klodoyak E Nepfx Ah Nel

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 15 Kjdpfox A E Tfex Ah Noll

Condition: excellent (used), functionality: fully functional, Comec FMC 900 4M + CA Pneumatic Drilling Machine Automatic loading from magazine Number of spindles: 3 Maximum workpiece length: 900 mm Maximum workpiece width: 100 mm Maximum drilling distance: 800 mm Kjdeycb Hiepfx Ah Noll Drilling capacity depending on workpiece length: 500–1100 pcs/h Intended for large batch production of chairs, beds, cribs, as well as components for other furniture pieces

Year of construction: 1997, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD LONGITUDINAL TRAVEL: 4000 mm TRANSVERSAL TRAVEL: 1200 mm VERTICAL TRAVEL: 2000 mm RAPID FEEDS L-T-V: 15 m/min TABLE SIZE: 5000 x 2000 mm SPINDLE: 4000 rpm; 27 kW; 1200 Nm HEAD: A/B AXIS AUTOMATIC ; A 2,5°- B 2,5° ; ISO 50 ; 4000 rpm TOOL MAGAZINE: CHAIN-TYPE ; 30 POS Ksdpsh Stzksfx Ah Nell CONTROL UNIT: SELCA S3045 WEIGHT: 25500 Kg ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL NOTE: EXTENSION 400mm -ISO50 -6.500rpm; AUTOMATIC HEAD EXCHANGE; PERIMETER GUARDING

Condition: ready for operation (used), Year of construction: 2008, operating hours: 9,965 h, - USED - 3-AXIS VERTICAL MACHINING CENTRE WITH ROTO-PALLET X-AXIS TRAVEL: 560 mm Y-AXIS TRAVEL: 400 mm Z-AXIS TRAVEL: 570 mm DISTANCE SPINDLE NOSE-TABLE: 210 - 780 mm RAPID FEEDS X-Y-Z: 40 - 40 - 32 m/min SPINDLE: 80-10000 rpm; 15-18,5 kW; ISO 40 - BT Kjdpfx Ajq Nqkxoh Nsll PALLET: N.2 ; 712X475 mm MAX ADMITTED LOAD: 300X2 Kg HIGH PRESSURE COOLANT: 15 Bar TOOL MAGAZINE: CHAIN-TYPE ; 32 POS MAX TOOL DIAMETER: 90(150) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 8 Kg CONTROL UNIT: FANUC 21i - MB WEIGHT: 7600 Kg OVERALL DIMENSIONS: 3010 x 3450 x 3145 mm

Year of construction: 2011, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH ROTARY AND SHIFTING TABLE LONGITUDINAL TRAVEL: 8000 mm Kledpfx Aswl R Agjh Nol TRANSVERSAL TRAVEL: 1500 mm VERTICAL TRAVEL: 2500 mm RAPID FEEDS L-T-V: 35 m/min TABLE SIZE: 2000 x 2000 mm TRANSVERSAL TRAVEL OF THE TABLE: 1500 mm HEAD: A/B AXIS AUTOMATIC ; CONTINUOUS ; ISO 50 ; 7000 rpm; 49 kW; 1180 Nm TOOL MAGAZINE: CHAIN-TYPE ; 80 POS CONTROL UNIT: HEIDENHAIN iTNC 530 ACCESSORIES: SWARF CONVEYOR ; LASER TOOL SETTER ; PORTABLE HANDWHEEL NOTE: WITH ROTARY TABLE 1500X1500 mm

Condition: ready for operation (used), Year of construction: 2019, - USED - 3-AXIS VERTICAL MACHINING CENTRE   X-AXIS TRAVEL: 1360 mm Y-AXIS TRAVEL: 700 mm Z-AXIS TRAVEL: 700 mm DISTANCE SPINDLE NOSE-TABLE: 100-800 mm DISTANCE COLUMN-SPINDLE AXIS: 792 mm RAPID FEEDS X-Y-Z: 32 m/min SPINDLE: 12000 rpm; 11-16.5-20-28 kW; BBT-40 TABLE SIZE: 1400 x 700 mm MAX ADMITTED LOAD: 1000 Kg HIGH PRESSURE COOLANT: 20 Bar Kljdonzn I Eopfx Ah Njl TOOL MAGAZINE: CHAIN-TYPE ; 30 POS MAX TOOL DIAMETER: 75 (150) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 7 Kg CONTROL UNIT: HEIDENHAIN TNC 620 WEIGHT: 9000 Kg OVERALL DIMENSIONS: 4670 x 2985 x 3105 mm ACCESSORIES: SWARF CONVEYOR ; ETHERNET PORT ; USB PORT ; PORTABLE HANDWHEEL

Condition: ready for operation (used), - USED - SURFACE GRINDING MACHINE MAX GRINDING LENGTH: 1015 mm MAX GRINDING WIDTH: 405 mm MAX GRINDING HEIGTH: 350 mm MAGNETIC CHUCK: 400 x 1000 mm GRINDING WHEEL SIZE: 50 x 127 x 350 mm MOTOR POWER: 3,7 kW WEIGHT: 3600 Kg OVERALL DIMENSIONS: 3500 x 1700 x 2000 mm ACCESSORIES: DRESSING TOOL Klodpfx Ajh St Dqoh Nol

Condition: ready for operation (used), Year of construction: 2008, - USED - 5-AXIS BRIDGE-TYPE VERTICAL MACHINING CENTRE     X-AXIS TRAVEL: 1750 mm Y-AXIS TRAVEL: 1400 mm Z-AXIS TRAVEL: 600 mm Klsdpfx Aswl R Ddsh Njl RAPID FEEDS X-Y-Z: 35 m/min SPINDLE: 18000 rpm; 18,5-25 kW; HSK A63 TABLE SIZE: 1000 x 1200 mm MAX ADMITTED LOAD: 5000 Kg TOOL MAGAZINE: A CATENA ; 30 POS HEAD: A/B AXIS AUTOMATIC CONTROL UNIT: HEIDENHAIN iTNC 530 WEIGHT: 18000 Kg OVERALL DIMENSIONS: 6000 x 4000 x 3850 mm ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL ; LASER TOOL SETTER

Year of construction: 2014, condition: ready for operation (used), - USED - CNC DIE SINKING EDM X-AXIS TRAVEL: 600 mm Y-AXIS TRAVEL: 400 mm Z-AXIS TRAVEL: 500 mm MAX ELECTRODE WEIGHT: 50 Kg Kjdjh St D Hjpfx Ah Noll MAX  PIECE WEIGHT: 2000 Kg MAX PIECE SIZE: 1200 x 800 x 350 mm TANK SIZE: 1280 x 850 x 390 mm CONTROL UNIT: VISION 5 WEIGHT: 5500 Kg OVERALL DIMENSIONS: 1800 x 2900 x 3200 mm ACCESSORIES: C-AXIS NOTE: POSSIBILITA' DI AGGIUNTA MAGAZZINO CAMBIO ELETTRODI.

Year of construction: 2018, condition: ready for operation (used), - USED - 5-AXIS BRIDGE-TYPE CNC MILLING MACHINE LONGITUDINAL TRAVEL: 2500 mm TRANSVERSAL TRAVEL: 3500 mm Kljdpfx Aewla Hnjh Nel VERTICAL TRAVEL: 1300 mm RAPID FEEDS L-T-V: 40 m/min TABLE SIZE: 3500 x 2500 mm HEAD: A/B AXIS AUTOMATIC ; A-axis ±185° - B-axis ±270° ; HSK A100 ; 12000 rpm TOOL MAGAZINE: CHAIN-TYPE ; 64 POS CONTROL UNIT: HEIDENHAIN TNC640 WEIGHT: 51370 Kg ACCESSORIES: HIGH PRESSURE COOLANT ; SWARF CONVEYOR ; LASER TOOL SETTER ; PAPER FILTER ; TOUCH PROBE ; PORTABLE HANDWHEEL

Year of construction: 2017, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD LONGITUDINAL TRAVEL: 3500 mm TRANSVERSAL TRAVEL: 1100 mm VERTICAL TRAVEL: 1500 mm RAPID FEEDS L-T-V: 40 m/min TABLE SIZE: 3800 x 1000 mm HEAD: A/B AXIS AUTOMATIC ; MILLESIMAL POSITIONING ; ISO 50 ; 5000 rpm; 34 kW Klsdpfx Ahewla Hze Njl TOOL MAGAZINE: CHAIN-TYPE ; 40 POS CONTROL UNIT: HEIDENHAIN TNC 640 HIGH PRESSURE COOLANT: 40 Bar WEIGHT: 35020 Kg OVERALL DIMENSIONS: 8760 x 4950 x 3780 mm ACCESSORIES: SWARF CONVEYOR ; LASER TOOL SETTER ; TOUCH PROBE ; PORTABLE HANDWHEEL

Condition: ready for operation (used), Year of construction: 2020, operating hours: 3,300 h, - USED - 4-AXIS HORIZONTAL MACHINING CENTRE WITH PALLET CHANGER X-AXIS TRAVEL: 1050 mm Y-AXIS TRAVEL: 900 mm Z-AXIS TRAVEL: 1000 mm DISTANCE SPINDLE NOSE-TABLE: 100 - 1100 mm RAPID FEEDS X-Y-Z: 60 m/min SPINDLE: 10000 rpm; 25-45 kW; 600 Nm; ISO 50 - BT PALLET: N.2 ; CONTINUOUS ; 630x630 mm MAX ADMITTED LOAD: 1500 Kg MAX MACHINABLE PIECE DIMENSIONS: ø1050 x 1350 mm TOOL MAGAZINE: CHAIN-TYPE ; 90 POS CONTROL UNIT: FANUC 31i WEIGHT: 18000 Kg Kjdjxvfuvepfx Ah Nell OVERALL DIMENSIONS: 6520 x 3930 x 3495 mm ACCESSORIES: SWARF CONVEYOR ; TOOL SETTER

Condition: ready for operation (used), Year of construction: 1997, - USED - 4-AXIS HORIZONTAL MACHINING CENTRE WITH PALLET CHANGER Kjdpjh Hfrnofx Ah Nsll X-AXIS TRAVEL: 1500 mm Y-AXIS TRAVEL: 1200 mm Z-AXIS TRAVEL: 1250 mm SPINDLE: 10-4000 rpm; 40 kW; HSK-A 100 PALLET: CONTINUOUS ; 1000X1000 mm; 1-500 rpm MAX ADMITTED LOAD: 2000 Kg TOOL MAGAZINE: CHAIN-TYPE ; 161 POS CONTROL UNIT: SIEMENS 840 C OVERALL DIMENSIONS: 8500 x 4800 x 4800 mm ACCESSORIES: SWARF CONVEYOR ; PAPER FILTER NOTE: COMPLETELY OVERHAULED MACHINE; HORIZONTAL AND VERTICAL AUTOMATIC HEAD; TURNING TABLE

Condition: used, Storage location: Sonnefeld Ksdeway Dcspfx Ah Nell

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Kljdevvi I Rjpfx Ah Nsl

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Kledovwbp Ajpfx Ah Nel

Condition: used, Year of construction: 1994, Edge thickness 0.3 - 20 mm, edgeband height: max. 66 mm, edgeband length: min. 200 mm, workpiece width min. 60 mm, workpiece length min. 140 mm, workpiece thickness: min. 6 mm, max. 60 mm, feed speed 8 or 16 m/min - Edgebanding with Ultra - Granupress - End trimming with 2 saws, 0 - 15° tiltable - Milling, radius / flush - Corner copying - Scraper - Pneumatic buffing Location: Nattheim Kjdpfsvvkdtex Ah Noll

Condition: used, Year of construction: 1980, Number of drill spindles: 23 Pitch: 32 mm Drill bit holder: Screw-in thread Operation: Foot pedal Drilling direction: From above and from the front Swivel: Pneumatic Maximum throughput width: 720 mm Number of material clamps: 2 Type of material clamping: Pneumatic Design: Mobile Stop system: For hole line and construction line Dimensions: 1300 x 1200 x 1700 mm Approx. weight: 365 kg Motor power: 2.2 kW Kjdswkir Djpfx Ah Noll Storage location: Nattheim

Condition: used, Year of construction: 1996, Edge thickness: 0.4 - 12 mm Roll edge: 3 x 45 mm or 0.8 - 60 mm Minimum workpiece width: 65 mm Minimum workpiece length: 160 mm Workpiece thickness: 10 - 55 mm Feed rate: 13 m/min Pre-milling (joining) Glue pot Quickmelt Gluing unit Trimming Flush trimming Chamfering Radius trimming Corner rounding Flat scraper Buffing unit Machine dimensions: 7450 x 1220 x 2400 mm Weight: 3000 kg Klodpfx Ahevvkd Tj Nsl Storage location: Nattheim
