Used Drill Sharpener for sale (5,247)

Condition: used, Technical details: number of spindles: 1000 bore capacity in steel (diameter): 32 mm Rcsdpfx Ajw Th Nlscdjb bore stroke: 200 mm range of revolution per miute: 63 - 1000 U/min bore capacity in cast iron: 50 mm drill spindle - Morse Taper: MK4 spindle throat: 315 mm spindle distance: 475 mm number of drilling stations: 3 headstock adjustment: 280 mm feed:: 0,08 - 1,25 (9 Steps) mm/U distance between table/spindle: 710 mm table surface area: 450 x 560 mm total power requirement: 12,4 kW weight of the machine ca.: 3,1 t dimension machine xH: 2,15 x 1,40 x 2,65 m The previous owner removed a drill spindle with box from the gang drilling machine! *

Condition: used, for manual drilling machines for stone, wood, and a few for metal Rcsdpfx Aohagt Socdjb

Condition: used, Year of construction: 1978, Technical details: bore capacity in steel (diameter): 100 mm arm length: 400 - 2100 mm cantilever adjustment vertical: 100 mm spindle taper MT: 50 drill depth: 415 mm spindle stroke: 400 (Skala) mm column turnable: 360 ° column diameter: Ø 500 mm distance drilling head - clamping area: min./max.: 400 / 1.800 mm number of spindle speeds: 12,5 ... 1.600 / 15 step U/min feed: 0,063 ... 2,5 / 15 step mm/U table clamping surface:: L x B: 2.000 x B: 950 mm total power requirement: ca. 35 kW weight of the machine ca.: o. Würfel = 8,0 t dimension machine xH: 3,40 x 1,16 x 3,51 m further information: - drilling spindle travel horizontal 1.700mm Equipment: Rcsdju Id Awepfx Acdob - incl. drilling cube (horizontal surface: 1000 x 1000 x 500 mm, central bore Ø 35mm; 6 T-slots), (vertical surface: 1,000 x 500mm, 3-T-slots) - control panel - coolant system *

Condition: used, Year of construction: 1993, Technical details: workpiece thickness - max.: 80 mm workpiece thickness min.: 5 mm plate size without being adjusted: 2000x1000 mm size of plate min.: 100x100 mm longitudinal travel: 2800 mm cross travel: 1000 mm control: CNC Mubea Matic100 hole diameter: min/max:10/40 mm tool taper: Kegel/cone/cono DIN 6327 bore spindle stroke: max. 150 mm positioning accuracy: +/- 0,5 mm spindle speeds:: 112-180-224-280-355-560 U/min traversing speed: 80 m/min feed length: max. 150 mm rapid traverse: 8 m/min work table:: L:2500;B:950 mm workpiece weight: 750 kg deburring device max.: d=40 mm work height max.: 1050 mm arm gripping device: 4 Stück/ pcs opening of gripping pliers min/max.: Typ I: 5/45 mm opening of gripping pliers min/max.: Typ II: 45/85 mm air-pressure connection: 6 bar total power requirement: 30 kw Weight approx.: 5,5 t space requirements approx. LxWxH: 5,0 x 5,5 x 2,7 (je nach Aufstellung) m - plate size with beeing adjusted also 1000x4000 mm possible - with roller conveyor 2x1000mm - material supporting table complete with supporting elements, guidance rail for guidance and transportation of the positioning wagons , cooling of the drill via air pressure - control for 2 axis positioning x-axis 80m/min and y-axis 30m/min, - memory capacity approx. 10.000 programs - position wagon/carriage, 2 material support table, material standard gauge railway, Rcodpfx Acsu Id Rusdeb - electric cabinet, control panel, hydr. aggregate accessories: - 1 position trolley, 2 material support tables, material web, control panel, hydraulic unit, deburring device Equipment: - 2 pieces drill sleeves, roller track 1800x1000mm and roller tracks 2x1000mm Machine is not under power and ready for transport. *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1250 workpiece height max.: - mm distance column till spindle centre: 1250 mm drill head horizontal traverse: 980 mm vertical adjustment of arm: 800 mm distance table - lower edge spindle: 2,05 x 9,2 x 2,85 mm spindle taper MT: MK4 bore spindle stroke: 280 mm Rcsdpfewid Auox Acdsb range of revolutions per minute - continous: 28-1.195 3 Steps U/min swivel range of the arm: 90 Grad feed: 0,1/0,2/0,3/0,4/0,8/1,2 6 Steps mm/U column diameter: 300 mm base plate surface area: 1.370 x 750 mm weight of the machine ca.: - t dimension machine xH: 2,05 x 9,2 x 2,85 m Cooling water system with feed Table with clamping surface 1,370mm x 750mm incl. drilling cube *

Condition: used, Year of construction: 1998, Technical details: bore capacity in steel (diameter): 15 mm bore stroke: 100 mm threading: M16 number of drilling stations: 3 drill spindle - Morse Taper: 3x MK2 spindle throat: 220 mm spindle distance: 335 mm headstock adjustment: (vertikal) 290 manuell mm feed:: mauell mm/U spindle speed:: 220-1600 / 400-3200 / 800-6400 U/min distance between table/spindle: min./max.: 235/525 mm table surface area: 1270 x 315 mm table adjustment: fest / fix mm total power requirement: nicht bekannt kW Rjdpfx Asu Idutocdscb weight of the machine ca.: 0,72 t dimension machine xH: 1,4 x 0,8 x 2,25 m incl. cooling water system operation by hand and foot The drilling spindles are equipped as follows: 1x drill chuck 13mm 2x quick chuck 10mm *

Condition: used, Technical details: bore capacity in steel (diameter): 13 mm throat: 160 mm bore stroke: 60 mm spindle taper MT: MK2 spindle speed:: 210 - 2580 / 16 step U/min feed: manual mm/U table clamping surface:: 200 x 185 (fest) mm Redpfxsvgbdxs Acdocb Distance spindle/table max.: 620 mm table clamping surface:: 260 x 265 (verstellbar) Distance spindle/table max.: 160 - 460 mm table rotating: ja ° drill table adjustment: 300 (Handkurbel) mm column diameter: Ø ca. 70 mm total power requirement: 900 Watt weight of the machine ca.: 90 kg dimension machine xH: 0,6 x 0,31 x 1,7 m The machine is equipped with a RÖHM 1-13 drill chuck incl. drill chuck key. Spindle run right. Small vice included *

Condition: used, Technical details: bore capacity in steel (diameter): 22 mm throat: 205 mm Rcedpfxevxf Ire Acdsb bore stroke: 100 mm spindle taper MT: MK2 spindle speed:: 2 step U/min feed: manuell mm/U Distance spindle/table max.: 150 - 600 mm base plate surface area: 350 x 400 mm table clamping surface:: 360 x 280 mm table rotating: 360 ° drill table adjustment: 450 mit Kurbel mm column diameter: Ø 100 mm control voltage: 380 V total power requirement: 0,8 kW weight of the machine ca.: 270 kg dimension machine xH: 0,6 x 0,5 x 1,95 m column drill incl. machine + vice. *

Condition: used, Year of construction: 1976, Technical details: bore capacity in steel (diameter): 32 mm arm length: ./x. . 400 / 50 mm drill head horizontal traverse: 400 mm drilling head vertical adjustable: 400 mm bore spindle stroke: 150 mm spindle taper MT: 4 grinding spindle speed: 100 - 2000 U/min Arm length: Spindel: min./max: ca. 400 / 50 mm cantilever adjustment vertical: 850 mm cantilever adjustment horizontal: 400 mm arm: Länge: 1360 arm horizontal: schwenkbar mm/min number of revolutions per minute of drill spindle:: 100...2 step U/min. feed steps: 0,1 / 0,2 / - step mm/U Table dimensions: 00 x 510 mm distance table - lower edge spindle: min./max.: 350 / 800 mm total power requirement: 2,4 kW weight of the machine ca.: 1,8 t dimension machine xH: 1,3 x 1,3 x 2,25 m Rcodpfowi Iqvex Acdsb Equipment: 2x foot rail Attachment option for a vertical table Accessories: Various clamping devices *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm Rodev S Ay Sepfx Acdocb arm length:: 1000 workpiece height max.: - mm column diameter: 300 mm horizontal adjustment of the boring slide: 400 mm distance table - lower edge spindle: 200 mm spindle taper MT: MK 4 bore spindle stroke: 200 mm range of revolutions per minute - continous: 18steps 14-710 U/min swivel range of the arm: 360 Grad feed: 0,09/0,12/0,25/0,5 mm/U weight of the machine ca.: 2,0 t dimension machine xH: 2,4 x 0,9 x 2,4 m Transportable! Operation via pressure switch Support feet 4x D=16x30mm Height-adjustable 60 mm with ratchet wrench *

Condition: used, Year of construction: 2008, Technical details: bore capacity in steel (diameter): 40 mm throat: 350 mm bore stroke: 120 mm bore capacity in cast iron: 60 mm spindle taper MT: MK 4 spindle throat: 350 mm spindle speed:: 50 - 1450 / 18 step U/min feed: automatisch/manuell mm/U Distance spindle/table max.: 25 - 705 mm table clamping surface:: 430 x 430 mm drill table adjustment: 680 mm column diameter: 150 mm distance spindle center to floor plate:: 1210 mm total power requirement: 1,6 kW weight of the machine ca.: 350 kg dimension machine xH: 0,95 x 0,55 x 2,3 m Height-adjustable table(swivel and tilt adjustable ) Rcjdpfx Acoviqybodjb Table can be swiveled 45° left/right and rotated 360° around the column Thread cutting up to M24 Coolant system A vise is mounted, and a threading device is included with this machine. *

Condition: used, Technical details: bore capacity in steel (diameter): 30 mm bore stroke: 180 mm drill spindle - Morse Taper: 4 x MK 3 spindle throat: 310 mm spindle distance: 490 mm number of drilling stations: 4 headstock adjustment: 300 (manuell) mm feed:: 0,08 - 0,64 / 6 step mm/U spindle speed:: 50 - 1.215 / 19 step U/min distance between table/spindle: max./min.: 500 / 200 mm table surface area: 1820 x 395 mm table adjustment: Höhe: 300 (manuell) mm total power requirement: 4x 1,5 (6,0 kW) kW weight of the machine ca.: 2,8 t dimension machine xH: 2,1 x 1,1 x 2,75 m Further technical data: -Center distance of the drilling spindle 490mm -thread cutting on drilling columns 3 and 4 with automatic switchover -All drilling spindles run with clockwise and counter-clockwise rotation -spindle countershaft and variator -with coolant system Rsdpfx Aou Idu Hocdecb *

Condition: used, Technical details: bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm table rotating: 360 ° base plate surface area: 175 x 175 mm Rsdsu Id Dzepfx Acdocb distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable *

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 20 mm throat: 220 mm bore stroke: 85 mm Distance spindle/table max.: max. 260 mm range of revolution per miute: Keilriemen U/min Redpfxou Id D Ue Acdjcb spindle taper MT: 2 table surface area: 220 x 280 mm base plate surface area: 225 x 280 mm distance spindle center to floor plate:: max. 380 mm total power requirement: 0,33 kW machine weight ab.: 125 kg dimensions L x W x H: 0,8 x 0,4 x 0,8 m The machine is currently in the technical department. Table rotatable 380 V with connection cable 2500mm *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 30 mm bore stroke: 200 mm drill spindle - Morse Taper: MK3 spindle throat: 350 mm spindle distance: Mittenstand: 490 mm headstock adjustment: 500 mm feed:: 0,07; 0,15; 0,25; 0,33 / 4step mm/U feed:: manuell und automatisch Rcedpfeu Idt Nex Acdsb spindle speed:: 70 ... 1.600 / 8step U/min distance between table/spindle: max. 430 mm distance between table/spindle: min. 180 mm table surface area: 1820 x 400 mm table adjustment: 250mm mit Handkurbel mm total power requirement: 10,8 kW dimension machine xH: ca. 1,0 x 2,1 x 2,8 m All spindle heads with clockwise and counter-clockwise rotation Drill head 1 to 3 clockwise and counter-clockwise rotation without tapping function Drill head 4 with automatic thread-cutting function, rawhide chuck up to Ø 33mm All drill heads and the table are height-adjustable. Equipment: Coolant supply i.D. *

Condition: used, Technical details: material thickness: 1,0 mm material width: 17,0 mm internal diameter: 30,0 mm external diameter: 78,0 mm Spare part for bench drill BT 2 Patt spring - Return spring - Spiral spring Declaration of conformity according to ISO/IEC 17050-1 Acceptance test certificate 3.1 according to DIN EN 10204 available Rcsdpfx Aeu N E Evscdsb *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 2-16 mm bore stroke: 140 mm drill spindle - Morse Taper: MK 3 spindle throat: 280 mm spindle distance: 455 mm headstock adjustment: 250 via Hand - Kurbel mm feed:: 0,08 - 0,12 - 0,20 - 0,31 / 4 steps mm/U feed:: automatic + manuell spindle speed:: 180 - 2000 / 8 steps U/min distance between table/spindle: min. 3x 140mm und 1x 260mm mm distance between table/spindle: max. 3x 700mm und 1x 820mm mm table surface area: 1800 x 350 mm table adjustment: 300 via Hand mm total power requirement: 6,3 kW weight of the machine ca.: 2,4 t dimension machine xH: 2,1 x 0,9 x 2,2 m Rcjdpju Idugjfx Acdob Application: Drilling, countersinking; reaming and thread cutting. Each drill spindle has its own drive motor Equipment: Foot pedal/operation Hand crank *

Condition: used, Year of construction: 1966, Technical details: bore capacity in steel (diameter): 63 mm arm length:: 2000 workpiece height max.: 1270 mm spindle taper MT: MK 5 drill depth: 400 (Hub) mm quill stroke: 400 mm feed: 0,05 - 0,32 m/min revolutions per minute spindle:: 14 - 1000 (40/50/63/160+200 o.Funktion) U/min column turnable: 360 ° electrics - voltage/frequency: 380/50 V/Hz base plate: 1900 x 950 mm total power requirement: 13 kW weight of the machine ca.: 7,9 t space requirements approx. LxWxH: 3,9 x 1,5 x 3,4 m This radial drilling machine has an electric sliding table! Further features: - Distance from spindle center to stand: 360 - 2000mm - Distance from drill chuck to table top: 1270mm - Distance from spindle to base plate: 1220 - 4520mm - Drilling capacity in St 60: 63mm at feed rate 0.32 - Drilling capacity in GG 22: 80mm at feed rate 0.5 - Horizontal travel of the drilling head: 1640mm - Vertical travel of the drill head: 980mm - Distance from spindle nose to base plate: 430-1770mm Equipment: - Coolant pump (out of function) - Support stand - 1 electrically driven sliding table 1250 x 1000mm type TI 18 with digital display (interface to the machine) Rsdpfxeu Id Dbo Acdscb - incl. machine vice Not all revolutions are currently selectable. i.D. *

Condition: new, This is a new machine which is manufactured in Romania by the manufacturer Emsil. Customer wishes can be taken into account depending on technical implementability and are checked in advance by the manufacturer's engineering office. Narwhal features a drilling spindle that is made of hardened, tempered and rectified alloy steel. It is mounted with preloaded oblique precision ball bearings. The machine is also equipped with a milling and boring bar which can handle exceptional power and torque. The bar is made of nitrided alloy steel and is also mounted with oblique preloaded precision ball bearings. It moves on bronze guide bushings. The clamps of both units, used for securing and releasing the tool holder cone with ISO 50 coupling, open and close automatically Rotary Turntable: The table is turned by means of a double pinion gearbox, a central rod wth bearings and hydrostatic sliding block of the centre bearing which is of a suitable size to guarantee maximum precision with large loads, even unbalanced ones. There is a recirculating ball screw slide guide system for the x-axes. Both axes are equipped with a direct measuring system. CNC Axes Control: The 9 axes of the machine are monitored at all times. The monitoring system is equipped with a 15'' TFT screen, a control panel, remote diagnostics that alert the user in case of faults, a user memory, network connectivity, remote control of the process, integrated PLC, etc. The machine is compatible with the multiple control systems such as Heidenhain, Fanuc, Siemens etc. You can choose the sizes of machining of X/Y and Z axes: from 1200 - 3500 / 1000 - 3500 / 400 - 1500mm Redeu Id H Ajpfx Acdecb *

Condition: used, Technical details: grinding wheel diameter: 240 mm saw blade diameter: 600 mm total power requirement: 1,1 + (0,37 kW) kW weight of the machine approx.: 600 kg Saw Blade Sharpening Machine Machine performs grinding process automatically saw blade continue to move automatically grinding wheel diameter: max.: 240 mm driving motor for feed (0,37 KW) * Rsdpou Ng Edofx Acdecb

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg dimension machine xH: 0,73 x 0,56 x 0,22 m Rcedpfx Aceyli Sfsdsb

Condition: used, Technical details: bore capacity in steel (diameter): 28 mm throat: 345 mm Rodpfx Aoyq Rpijcdocb bore stroke: 190 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 4 spindle speed:: 50 - 1280 / 4 steples U/min feed: 0,1; 0,2, 0,3 manuell/automastic mm/U Distance spindle/table max.: 200 - 800 mm table clamping surface:: 450 x 600 mm table rotating: 360 ° table adjustment: vertical 600 mm column diameter: Ø 160 mm weight of the machine ca.: 273 kg dimension machine xH: 1,0 x 0,71 x 2,0 m Thread cutting with right and left rotation via foot switch Table adjustment via hand crank Without coolant tank Machine vice Quick-action clamping chuck Röhm Supra 3 - 16mm i.D. *

Condition: used, Year of construction: 1982, Technical details: bore capacity in steel (diameter): 28 mm throat: 300 mm bore stroke: 150 mm drill capacity in cast iron: 30 mm spindle taper MT: MK3 spindle speed:: 200; 300; 500; 800; 1250; 2000 / 6 step U/min feed: manuell mm/U Distance spindle/table max.: 50 - 600 mm table clamping surface:: 330 x 300 mm Redpou Idkbsfx Acdecb table rotating: nein ° drill table adjustment: 550 (Handkurbel) mm column diameter: Ø 125 mm total power requirement: 1,5 kW weight of the machine ca.: ca. 300 kg dimension machine xH: 0,7 x 0,45 x 1,87 m Equipped with RÖHM Supra 3 - 16mm quick-action chuck Machine vice *

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Rcjdou Idkzepfx Acdeb Table can be swiveled and adjusted in height. *

Condition: used, Year of construction: 1975, Technical details: bore capacity in steel (diameter): 32 mm throat: 230 mm bore stroke: 160 mm spindle taper MT: 3 feed - manual: Handhebel mm revolution per minute: 100...2000 U/min headstock adjustment: 180° Grad Rcedpfx Ajvc Aytjcdjb headstock traverse: in Höhe/height/altura 350 mm clamping surface area: 1020x615 mm height over floor: 860 mm column diameter: 102 mm total power requirement: ca. 1,2 kW weight of the machine ca.: 0,5 t space requirements approx. LxWxH: L:1,2xB:0,77xH:2,26 m equipped: - toothed drill chuck up to 16mm Machine on sale as is, without test run. i.D. *
