Laminating machine

Komfi Amiga 52 I Intelligent In-Line Feeding

Condition: new, Year of construction: 2020, operating hours: 10 h, functionality: fully functional, machine/vehicle number: 52AMG162, compressed air connection: 6 bar, working width: 560 mm, warranty duration: 12 months, operating speed: 400 mm/s, Komfi Laminator Amiga 52I (Intelligent In-Line Feeding) New, Manufactured 2020 Specifications: Max. speed of lamination: 25 m/min Max. output: 8000 sheets/h Min. sheet dimensions: 200 × 250 mm Max. sheet dimensions: 560 × 800 mm (or up to 1016 mm) Paper weight: 115-600 g/m² Paper thickness: Max 0.7 mm (with overlap > 0) / Max 1.4 mm (with overlap < 0) Max. paper pile: 6 cm (depending on sheet length) Thickness of laminating film: 24-50 μm; OPP, PET, Nylon Sheet overlap accuracy: ± 1 mm Feeder: Intelligent In-Line Feeding (connection with the PRinter) Laminating Unit: Adjustable distance stoppers for lamination unit to enable processing thick substrates and windows lamination. ”On-the-fly” side-adjustable unwinding shaft with adjustable brake force. Dcedpfozb Db Hex Agvoh Height-adjustable and removable spread roller perfectly removes wrinkles from laminate. IR heating for laminating cylinder. Temperature sensor inside the cylinder for precise regulation. Rubber coated pressure roller. The powerful pneumatic pressure system guarantees even nip pressure and perfect lamination results. Separator & Delivery: Decurling unit consisting of bar and roller with position control to move the snapping moment automatically when the position of decurler is changed. Built-in film perforator to enable sheet separation. Cam-driven separation roller with adjustable tearing action, delivery roller and sheet skewing wheel. Fixed delivery desk with adjustable air nozzles.
