Laser scan micrometer

AEROEL / Marposs 290D2B0 XLS 40

AEROEL 290D2B0 XLS 40 Laser Scan Micrometer Tabletop Laser Micrometer

Measuring field (vertical): 40 mm

Measurable diameters: from 0.06 mm to 38 mm

Resolution (selectable): 10 µm / 1 µm / 0.1 µm / 0.01 µm

Linearity accuracy (centered): ±0.5 µm for Ø ≤ 25 mm (up to ±0.75 µm for Ø up to 38 mm)

Linearity (within the measuring plane): ±0.5 µm

Lateral linearity (per mm deviation): ±0.5 µm/mm

Repeatability (T = 1 s, ±2σ): ±0.07 µm

Beam spot size (elliptical): approx. 0.08 × 2 mm (Model A) or 0.06 × 0.1 mm (Model B)

Scan frequency: approx. 1,500 Hz

Scan speed: approx. 300 m/s

Thermal coefficient (with “NO-VAR” option): approx. −11.5 µm/mm °C

Power supply: 24 V DC, 0.3 A (1 A peak current)

Laser source: VLD (Visible Laser Diode), wavelength λ = 650 nm

Dimensions (L × W × H): approx. 500 × 134 × 68.5 mm

Weight: approx. 4.2 kg

Operating temperature: 0 °C to +50 °C (storage temperature −20 °C to +70 °C)

Max. operating altitude: up to 3,000 m above sea level

Technical description adopted as provided.
