Condition: used, Year of construction: 2005, total height: 2,700 mm, total length: 5,500 mm, total width: 2,600 mm, overall weight: 14,000 kg, - Manufacturer / Model: Gildemeister GMX 200 linear - Bed Design: 4-way bed with roller guides WORK AREA & TRAVEL - Swing diameter / Max. turning diameter: 560 mm - Max. turning diameter counter spindle / tailstock: 400 mm - Turning length: 1,070 mm - Spindle distance: 1,300 mm - Slide travel X1 / Y1: 485 / 160 mm - Slide travel Z1: 1,070 mm - Slide travel Z3: 1,060 mm - Swivel travel B1: 240° - Max. workpiece weight chuck parts: 150 kg (chuck weight 100 kg) - Max. workpiece weight shaft parts: 800 kg MAIN SPINDLE & COUNTER SPINDLE (Spindle 1 & Spindle 2) - Chuck diameter: 200 – 250 mm - Max. bar diameter: 65 mm - Spindle head diameter: 170 h5 (flat flange) - Spindle bore / draw tube diameter: 79 mm / 68 mm - Speed range: 0 – 5,000 rpm - Drive power (100% / 40% ED): 25 / 37 kW - Max. torque (100% / 40% ED): 270 / 390 Nm - C-axis: 5,000 rpm | 390 Nm | Resolution 0.001° TOOL SPINDLE (MILLING SPINDLE) & B-AXIS - Tool holder: HSK63-A (optional CAPTO C6) - Tool magazine: 80 tool positions - Max. spindle speed: 12,000 rpm - Drive power (100% / 40% ED): 13.2 / 22 kW - Max. torque (100% / 40% ED): 60 / 100 Nm - B-axis swivel speed: max. 20 rpm - B-axis torque / clamping: 2,860 / 5,720 Nm (S6-40%) | 2,000 Nm hydraulically clamped FEED & AXIS DRIVES - Rapid traverse rate slide 1 (X / Y / Z): 40 / 24 / 70 m/min - Linear motor Z1 axis: 1FN3600-4WB00 - Rapid traverse rate slide 3 (Z counter spindle): 48 m/min Ljdpfx Ae Ad R N Ssb Aehn COOLANT, HYDRAULIC & PNEUMATIC SYSTEM - Coolant system: Band filter with 600 l (980 l) tank - Coolant pressure (optional): up to 80 bar - Hydraulic tank: 40 l (max. pressure 100 bar) - Pneumatic pressure / air consumption: 6 bar / 40 m³/h DIMENSIONS, WEIGHT & CONNECTION - Transport dimensions (L x W x H): 5,950 x 2,610 x 2,500 mm - Machine weight (incl. control cabinet): approx. 14,500 kg - Total space requirement (L x W x H): 9,000 x 5,000 x 2,800 mm - Electrical connection: 75 kVA / 400 V / 50 Hz / 125 A slow-blow fuse

Condition: used, Year of construction: 1991, Mazak Super Quick Turn 15M – CNC turning machine with C-axis and powered tools Year of manufacture: 08/1991 Lhjdpfj Ad R Hdex Ab Aon

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm Ledj Ad Izropfx Ab Ajhn spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: good (used), Year of construction: 1993, functionality: fully functional, travel distance X-axis: 212 mm, travel distance Z-axis: 640 mm, total height: 1,730 mm, total length: 4,530 mm, total width: 1,940 mm, overall weight: 5,200 kg, Gildemeister CTX 400, CNC turning machine. The machine is in good, well-maintained condition. Manual included. Machine with EPL2 programming. Travel distances: Z-axis = 640 mm X-axis = 212 mm Max. turning diameter over the bed: 500 mm Data: - Year of manufacture: 1993 - CNC control: EltroPilot L2 - 12 tool stations - Spindle power: 22 kW - Rapid traverse X-axis: 10 m/min - Rapid traverse Z-axis: 15 m/min - Speed range: 25 - 5000 rpm Lhodpfj Ad H Ukex Ab Ajn - Chip conveyor GB 25L 38L (discharge height 1100mm, belt width 225mm, feed height 250mm) - Double foot switch - Machine weight (with chip conveyor): approx. 5.15 tons - Dimensions with chip conveyor (W x D x H): 4.53 x 1.94 x 1.73 m The machine can be inspected at any time. The sale is only to business customers and is without guarantee or warranty. You will receive an invoice with the currently applicable VAT. The machine can be loaded.

Condition: used, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 25.0122, For sale is a highly precise CNC turning and milling machine, type Benzinger TNE5, manufactured in 2007. Benzinger machines are known worldwide for their exceptional mechanical rigidity, extreme repeatability, and durability. They are particularly used in the watchmaking industry, medical technology, precision engineering, and optics. This model is ideal for the complete machining of complex precision parts from bar stock or in a chuck. Thanks to its robust design and excellent thermal management, the machine is perfectly suited for tight tolerances and hard turning. Equipment: - Siemens Sinumerik control - 2 x 12-station turret - Knoll 200S-1/200 chip conveyor, year of manufacture 2006 - High-pressure hydraulic unit Terms: Ljdpj Adz Acefx Ab Ajhn - ex works. Attractive offer – flexible & hassle-free We offer you not only a high-quality product but also customized financing options that adapt to your needs. Whether it's a down payment, installment payment, or individual financing models – together we will find the right solution. On request, we also take over the complete transport organization. From planning to reliable delivery, we ensure a smooth and on-time process so that you don't have to worry about anything. 📞 Please contact us for further information or a non-binding offer. We will provide you with personal and expert advice. Subject to prior sale, changes, and errors!

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, CNC Control: MORI SEIKI MSX-850III Maximum turning diameter: Ø 356 mm Maximum turning length: 705 mm Swing over bed: Ø 923.8 mm Maximum bar capacity: Ø 80 mm Travel of X / Y / Z axes: 260 / ±50 / 795 mm Lhsdpfx Ae Adyr Njb Ajn Maximum spindle speed: 4,000 rpm Main spindle power: 18.5 kW C-axis increment: 0.001° Motorized positions / stations: 12 / 12 Operating hours: 5,347 / 3,776 h

Condition: excellent (used), Year of construction: 2014, Takisawa NEX - 908 – 6-axis machine Year of manufacture: 2014 Control system: Lsdpfx Abs Adrf Uo Ashn - Fanuc Series 32i - Model B Tool turret: - 12 stations, all stations driven (powered tools) Main spindle: - Spindle bore 52 mm. Axes: - X, - Z, - C, - Y, - A, - B Accessories: - Various driven tools, axial/radial - Various collets - 1 collet chuck - Parts collection system - Chip conveyor - Coolant system Availability: - Immediate Special features: - The machine will be sold complete with all accessories (full equipment package). - The machine can be inspected and tested under power.

Condition: ready for operation (used), Year of construction: 1973, travel distance X-axis: 850 mm, travel distance Z-axis: 2,900 mm, controller manufacturer: SIEMENS, number of axes: 2, Turn-mill centre manufactured in 1973. This MAX MULLER 3000 / Norma 2900 x 850 features a turning length between centers of approximately 2850 mm and a faceplate diameter of Ø 630 mm. It is equipped with a SIEMENS CNC Control and has a drive power of 32 kW. If you are looking to get high-quality turning capabilities, consider the MAX MULLER 3000 / Norma 2900 x 850 machine we have for sale. Contact us for further details. - Turning Length between Centers: Approx. 2850 mm- Faceplate Diameter: Ø 630 mm- Drive Power: 32 kW- Operating Hours: Approx. 60,000h - 70,000h (mathematically calculated after 1998 retrofit)- Control Unit: SIEMENS CNC Control- Additional Accessories / Scope of Delivery: Complete machine, 1x hydraulic steady rest (Ø 50 mm - Ø 150 mm), faceplate Technical Specification Counter Spindle No Lhedpe Adp Tvefx Ab Ajn Driven Tools Yes

Condition: used, Year of construction: 2005, turning diameter 275 mm turning length 900 mm control TRAUB TX8i spindle passage 65 mm power capacity at 100 % load 25,20 kW power capacity at 40 % load 30,20 KW max. torque at 40% / 100% load 180 / 135 Nm spindle turning speed - stepless 1 - 5.000 U/min spindle diameter in front bearing 110 mm C-axis 1 - 500 U/min worktool support No. 1 x-axis 290 mm y-axis 165 mm z-axis 600/950 mm B - axis 360 ° rapid traverse X/Y/Z 18 / 18 / 30 m/min feed capacity X/Y/Z 10 / 10 / 7 kN number of tools 2x2 + 2x2 number of driven tools 2x2 + 2x2 mm toolpiece turning speed range 8.000 / 2.000 U/min power capacity at 25 % load 5,80 kW max. torque at 25% load 4x18,6 / 4x74 Nm tool taper TRAUB Ø60 worktool support No.2 / No.3 / No.4 x-axis 170 mm z-axis 600/950 mm y-axis +/- 60 mm rapid traverse X/Y/Z 18 / 15 / 30 m/min feed capacity X/Y/Z 10 / 10 / 7 kN tool turret - number of stations 10 number of driven tools 10 mm Ljdo Ac Uu Nopfx Ab Ajhn toolpiece turning speed range 1 - 6.000 U/min power capacity at 25 % load 5,80 kW max. torque at 25% load 18,60 Nm tool taper DIN 69880 Ø40x63 bar loader DNH61 / 3000 Bar length 1.000 - 3.200 mm bar material dia. 18 - 63 mm hexagon max.45 mm total power requirement 95,00 kW weight of the machine ca. 16,00 t dimensions of the machine ca. 10,00 x 3,50 x H3,00 m With TRAUB TX 8i control unit, main and counter spindle with C-axis, 3 turrets, 1 vertical-tool-carrier with B-axis, dust exhauster, chip conveyor, coolant system with coalescence-separator. Barfeeder TRAUB Stamag DNH61 /3000 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package Machine can be inspected under power.

Condition: good (used), Year of construction: 2012, functionality: fully functional, DOOSAN PUMA 2600S – CNC turning center with subspindle, FANUC, year 2012 We offer for sale a DOOSAN PUMA 2600S CNC turning center with subspindle, equipped with a reliable DOOSAN-FANUC i Series control system. The machine is in operation and can be demonstrated and tested upon request. Technical specifications: Manufacturer: Doosan Infracore Model: PUMA 2600S Year of manufacture: 09/2012 Serial number: ML0218-000034 CNC control: DOOSAN-FANUC i Series Configuration: main spindle + subspindle Max. turning diameter: approx. 376 mm Max. turning length: approx. 760 mm Main spindle chuck: approx. 10" Bar capacity through main spindle: approx. 76 mm Lhsds Acnp Tepfx Ab Aen Max. main spindle speed: approx. 3,500 rpm Main spindle power: approx. 18.5 / 22 kW X-axis travel: approx. 260 mm Z-axis travel: approx. 830 mm Turret: 12 positions Automatic subspindle for complete part machining Chip conveyor Rated machine power: 40.7 kVA Power supply: 200/220 V, 3 phases, 50/60 Hz Machine weight: 5,400 kg Robust CNC turning center suitable for both series and single-piece production. Thanks to the subspindle, it enables machining of the part from both sides without the need for manual switching between individual operations. The machine is currently powered on and can be demonstrated in operation.

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, machine/vehicle number: 1, Equipment: documentation/manual, Machine in perfect working order, primarily made of brass. IEMCA loader included. Lhjdpfx Abo Abkz Ao Asn

Condition: used, Year of construction: 2023, overall weight: 9,600 kg, DN SOLUTIONS PUMA TT2100SYYB (2023) – Twin Spindle / Twin Turret CNC Turning Center For sale: DN SOLUTIONS PUMA TT2100SYYB, manufactured in April 2023, equipped with twin spindles, twin turrets, dual Y-axis, driven tools, and an LNS automatic bar feeder. High-productivity CNC turning center designed for precision and high-volume manufacturing of complex components. Machine specifications Manufacturer: DN Solutions (Doosan) Model: PUMA TT2100SYYB Year of manufacture: 2023 (April) Serial number: ML0429-000147 CNC control: DOOSAN-FANUC i Series Plus Maximum turning diameter: 230 mm Maximum turning length: 230 mm Main spindle chuck size: 10" Sub-spindle chuck size: 8" Main spindle bar capacity: 81 mm Sub-spindle bar capacity: 65 mm Main spindle speed: 3,500 rpm Main spindle power: 22 kW Sub-spindle speed: 5,000 rpm Sub-spindle power: 25 kW Turrets: 2 × 12 stations Live tooling: Both turrets Live tool speed: Up to 5,000 rpm Y-axis: Upper and lower turret Y-axis travel: ±50 mm C-axis: Both spindles Machine weight: 9,600 kg Additional equipment LNS Quick Load Servo 80 S2 automatic bar feeder Automatic machine doors (CNC Autodoor) External coolant pumping system 15 bar Chip conveyor Twin driven-tool turrets Main and sub-spindle configuration LNS Bar Feeder Model: Quick Load Servo 80 S2 Bar diameter range: 6–80 mm Maximum bar length: 1,605 mm - with spindle extender included in the price Servo-controlled automatic bar loading Automatic diameter adjustment Highlights Complete front and back machining in a single production cycle Simultaneous operations using two independent turrets Two Y-axes for complex milling and drilling operations Automatic bar-fed production Suitable for high-volume precision manufacturing Lhsdps Aa Abrjfx Ab Aen Modern 2023 machine Machine location: Slovenia, European Union Price: On request Inspection: Available by appointment Additional information, photographs, and machine inspection are available upon request.

Condition: excellent (used), Nakamura-Tome Super NTJ 9-Axis Turn/Mill Centre Year: 2003/2004 Serial Number: B150509 Control: Fanuc 18i-TB Main Spindle Maximum bar capacity: 65 mm Maximum turning diameter: 190 mm Spindle nose: A2-6 Spindle power: 15 kW Spindle speed: 4,500 rpm C-axis indexing: 0.001° Sub-Spindle Maximum bar capacity: 51 mm Spindle nose: A2-5 Spindle power: 11 kW Spindle speed: 5,000 rpm C-axis indexing: 0.001° Stroke: 760 mm Upper Turret Number of tool stations: 24 Motorised tool stations: 24 X-axis travel: 345 mm Y-axis travel: ±45 mm Z-axis travel: 1,240 mm B-axis travel: ±91° Live tooling speed: 6,000 rpm Live tooling power: 5.5 kW Lower Turret Number of tool stations: 24 Motorised tool stations: 12 X-axis travel: 167.5 mm Z-axis travel: 685 mm Live tooling speed: 6,000 rpm Live tooling power: 5.5 kW Ljdpfxe Aaz Nze Ab Aohn

Condition: reconditioned (used), Year of construction: 2003, functionality: fully functional, CNC lathe GILDEMEISTER CTX 420 linear With Heidenhain ELTROPILOT 4290 control system Year of manufacture: 2003 Max. turning diameter: 324 mm Max. turning length: 600 mm Max. swing diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4500 rpm With the following accessories: Sliding guard with internal lighting 12-station turret Various tool holders VDI 40 Tailstock with quill Chip conveyor Hydraulic chuck SMW Autoblok 0 250 mm Foot switch for chuck + tailstock adjustment Oil mist extractor Coolant system Operating manuals Ljdpe Aazxvjfx Ab Aohn

Condition: used, Year of construction: 2019, operating hours: 22,000 h, functionality: fully functional, turning length: 650 mm, spindle motor power: 15,000 W, spindle bore: 76 mm, travel distance X-axis: 215 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 750 mm, rotational speed (max.): 4,500 rpm, bar passage: 76 mm, total height: 2,340 mm, total length: 2,334 mm, total width: 3,550 mm, overall weight: 11,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Multi-axis turning and milling center including a short bar loader from Samsys - SMW Autoblock chuck BBM 210 Ljdpez Uxh Eefx Ab Ajhn - SMW Autoblock chuck BBM 210 - Chip conveyor - Tool measuring arm Renishaw - Bar loader interface - Part gripper from the sub-spindle including conveyor belt - Oil separator - Air conditioning unit for the control cabinet - SAMSYS bar loader MULTI 3000 with numerous accessories - Chuck purging system - Automatic door - 6 driven tools on the X-axis - 6 driven tools on the Z-axis - Numerous basic setups - Collet chuck for the main spindle with collets - Fanuc 0iTF with a 15" monitor - 10 bar coolant - 2 x 16-position turret

Condition: good (used), Year of construction: 2001, Machine is in good working condition. Ledpfjz Uvpmex Ab Ajhn Parts shown by hand not come.

Condition: used, Year of construction: 2011, Manufacturer: DMG GILDEMEISTER, Type: NEV 400, Year of manufacture: 2011, Operating hours: 39,722, Spindle hours: 12,928, Control system, Manufacturer: Siemens, Type: Sinumerik 840D, 21" operator terminal ERGOline, Touchscreen, 3-jaw chuck, Tool turret, 12 tool positions, Center distance 805 mm, Turning length 650 mm, Travel X/Z/Z 255 x 800 x 680 mm, Chip conveyor Lhodpfx Ajz Tlfzeb Aen +++ ATTENTION! This machine is part of an online auction! +++

Condition: good (used), Year of construction: 1998, functionality: fully functional, CNC turning machine EMCOTURN 365 MC with counter spindle Year of manufacture: 1998 Control system: Sinumerik 840D Lhjdpfsz Tc Utjx Ab Ajn Accessories: - Parts collector - Chip conveyor Further details to follow Includes a wide range of accessories.

Condition: good (used), Year of construction: 2011, operating hours: 18,000 h, functionality: fully functional, turning length: 740 mm, turning diameter: 430 mm, spindle bore: 65 mm, travel distance X-axis: 280 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 750 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 10 rpm, bar passage: 65 mm, overall weight: 8,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Turn-milling center EMCO HYPERTURN 665 MC Plus Year of manufacture: 2011 Control system: Sinumerik 840D Operating hours: 18,300h (according to hour meter) Technical data: Main spindle speed: 0 - 5,000 rpm Drive power: 21/29 kW (100/40%) Torque: 250 Nm Spindle mounting: KK6 Bar diameter: 65 mm Counter spindle speed: 0 - 7,000 rpm Drive power: 17/21 kW (40/100%) Torque: 130 Nm Spindle mounting: KK6 Milling spindle speed: Mounting: Capto C4 Number of magazine positions: 23 Travel ranges: X1/Z1: 280/750 mm X”/Z2: 205/750 mm Y-axis: +/- 50 mm Lower turret: Mounting: VDI 30 Number of positions: 12 Number of powered tools: 12 Lhsdpsz Tc Umofx Ab Asn Accessories: - Emco short magazine LM 1200 - Chip conveyor - High-pressure coolant system - Parts catcher - Extensive equipment with tool holders

Condition: used, Year of construction: 2013, operating hours: 51,438 h, functionality: fully functional, turning length: 2,000 mm, turning diameter: 630 mm, spindle motor power: 34 W, spindle speed (max.): 4,000 rpm, spindle bore: 102 mm, travel distance X-axis: 650 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 2,050 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 40 m/min, type of input current: AC, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 30 m/min, total height: 2,670 mm, total length: 7,601 mm, total width: 4,215 mm, spindle nose: 220h5, overall weight: 24,000 kg, Equipment: documentation/manual, Control system: Siemens 840D sl with ShopTurn Year of manufacture: 2013 Spindle hours: 16,310 Location: Germany Equipment: -Main spindle ISM 102 -Counter spindle ISM 102 -Milling spindle HSK63A 12,000 rpm -Eccentric turning and milling -Milling of gears using the involute method -Easy Tool Monitor for Siemens control system -Chuck flushing system, external -Chuck flushing system, counter spindle -Differential pressure monitoring for H-spindle -Differential pressure monitoring for C-spindle -Coolant supply through the counter spindle -Partially hollow chuck, Ø 104 mm -Tailstock function for the counter spindle -Rest support for rest 30-245 mm -Rest slide, NC-controlled -BFA 8/20/80 bar, 980 l, cooler -Hinged belt chip conveyor -Automatic sliding hood, electric -Tool measuring device -Chain magazine for 120 tools HSK63A -Signal light, 4-way -Cleaning of the safety glass -Coolant spray gun -Control cabinet lighting -Oil mist separator Lsdpfjz Tc Tpjx Ab Aohn Including the following overhaul/repair measures: -General overhaul of main spindle S1 HSK 63 12,000 rpm -Replacement of safety glass -Replacement of hoses (pneumatics, cooling system, CNC)

Condition: excellent (used), Year of construction: 2012, Machine data Year of manufacture: 2012 Control system: Mitsubishi Spindles: Main and counter spindle Y-axis: Available Tool turret: 8 stations Bar feeder: LNS Sprint 542 Full load current: 84 A Connection, weight and dimensions Machine weight: 3,000 kg Voltage / phases / frequency: 200 V / 3~ / 50–60 Hz Connection power: 29 kVA Equipment and scope of supply Main and counter spindle Y-axis Tool turret with 8 stations LNS Sprint 542 bar feeder Basic set of tool holders; the exact scope of holders will be listed in the quotation. Lsdpjz Tc S Ejfx Ab Aehn Further accessories belonging to the machine, as shown in the offer photos. LNS Sprint 542, basic set of tool holders and further accessories belonging to the machine, as shown in the offer photos. Exact scope of holders as per quotation. Technical specifications are subject to change without notice. Errors and prior sale excepted. The properties and scope of supply agreed upon in the purchase contract shall be binding.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, table length: 1,120 mm, table width: 600 mm, Cincinnati Arrow 2-1000 machining center, with Siemens Acramatic 2100 CNC, automatic tool changer, 1120mm x 600mm table, maximum table load of 1000kg, travels X 1016mm, Y 510mm, Z 560mm, with electronic handwheel, BT40 taper, 11/15 hp, maximum spindle speed of 12500 rpm, oil-lubricated spindle, Heidenhain measuring scales on all three axes, automatic tool changer with 21 positions, year 2006, serial number 7049-AQA-KE1134, part number 91204519A, machine in very good condition, machine has never been used for metalworking. Lsdpfx Aoz Tc Igeb Ashn

Condition: ready for operation (used), Moriseiki SL-250B Ledpfoz Tc Exsx Ab Ashn

Condition: used, Year of construction: 2015, turning diameter max. 500 mm turning length 800 mm control sl Operate 3G ShopTurn Siemens swing diameter 500 mm distance between spindles 1.020 mm turning speed range - main spindle max. 5.000 min/-1 power capacity - main spindel 25 / 34 kW max. Torque 280 / 380 Nm spindle head 170h5 spindle diameter in front bearing 130 mm spindle bore 87 mm C-Axis 0,001 ° tool taper HSK 63 A number of toolpositions 80 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 120 mm max. tool weight 12 kg max. tool length 300 mm Speed Milling Spindle max. 12.000 min/-1 power capacity - milling spindle 19 / 22 kW Torque 85 / 100 Nm tool taper HSK 63 A B-Axis +/- 110 ° Lhjdpfoz S Nygsx Ab Aen x-axis -10 ... +490 mm y-axis +/- 100 mm z-axis 1: 845 mm z-axis 2: 600 mm z-axis 3: 800 mm Spindle speed range subspindle max. 6.000 min/-1 power capacity - Sub spindle 20 / 27 kW bar material dia. 51 mm spindle bore diameter 73 mm spindle diameter in front bearing 100 mm C-Axis 0,001 ° total power requirement 85 kVA weight of the machine ca. 10,0 t dimensions of the machine ca. 7,0 x 2,9 x 2,6 m CNC - Turning- and Millingcenter DMG MORI - CTX beta 800 TC V6 - 5-axis simultaneous machining - Main and counter-spindle - Swivel-type milling spindle - ShopTurn - Off-center turning and milling - Multi-thread cycle - Program state control - Tool sorting cycle - Easy Tool Monitor for Siemens control system - Chuck flushing system for main spindle - Chuck flushing system for counter-spindle - Differential pressure clamping - Coolant supply through the counter-spindle - Bar machining package for CTX beta (77 mm capacity) Workpiece the-take-off device (left side) Hydraulic hollow clamping system 4-color signal tower Interface for bar feeder or bar magazine - In-process workpiece measuring system (Renishaw) - Safety window cleaning system - Coolant spray gun

Condition: used, Year of construction: 2015, turning diameter max. 240 mm turning length 470 mm control 840 D sl Operate 4.8 Celos greates pass round over bed 500 mm swing diameter over slide rest 290 mm centre distance 780 mm turning speed range - main spindle max. 6.000 min/-1 power capacity - main spindel 13 / 14 kW max. Torque 171,5 / 192 Nm inner draw tube diameter 52 mm C-Axis 0,001 ° spindle diameter in front bearing 100 mm spindle nose FL 140H5 Spindle speed range subspindle max. 6.000 min/-1 power capacity - Sub spindle 12,6 / 16,2 kW max. Torque 48 / 62 Nm Ljdpez S Nyaofx Ab Aehn inner draw tube diameter 37 mm C-Axis 0,001 ° spindle diameter in front bearing 90 mm spindle nose FL 140H5 number of toolpositions 12 pos. Number of driven toolspositions 12 pos. tool taper VDI 30 Spindle speed - driven tool stations max. 5.000 min -1 power capacity - driven tool-stations 4,18 kW max. Torque 16 / 20 Nm y-axis 80 (+/- 40) mm x-axis 145 mm y-axis 80 (+/- 40) mm z-axis 520 mm z2-Axis 550 mm rapid traverse ( X / Y / Z ) 30 / 22,5 / 30 m/min Feed force ( X / Y / Z ) 4,5 / 4,5 / 7,5 kN total power requirement 30 kVA weight of the machine ca. 4,3 t dimensions of the machine ca. 7,0 x 3,0 x 2,2 m CNC - Turning- and MillingCenter DMG GILDEMEISTER - CTX alpha 500 V6 - Only approx. 11,139 spindle hours - External chuck flushing system for the main spindle - External chuck flushing system for the counter-spindle Coolant supply through the counter-spindle - Coolant spray gun - Bar machining package Workpiece unloading device with conveyor belt (left-hand side) for parts up to 51 mm in diameter and 185 mm in length, max. 3 kg Hydraulic hollow clamping system Draw tube inner diameter: max. 52 mm 4-color signal light Connection for bar feeder or bar loading magazine - Preparation for external handling Electrical robot interface (Profibus) Automatic work area door Chuck flushing system with coolant (main spindle)
