Fertigungstechnik Weißenfels

Condition: refurbished (used), Year of construction: 1996, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 900 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, feed rate X-axis: 5 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 5 m/min, position of the milling head: osa A 105°+ osa B 90°, spindle speed (max.): 3,500 rpm, spindle speed (min.): 3,500 rpm, table width: 800 mm, table load: 8,500 kg, table length: 3,000 mm, table height: 1,000 mm, total height: 3,400 mm, total width: 4,360 mm, total length: 7,760 mm, type of input current: three-phase, rotational speed (max.): 3,500 rpm, workpiece weight (max.): 8,500 kg, overall weight: 18,000 kg, year of last overhaul: 2025, spindle motor power: 22,000 W, power: 22 kW (29.91 HP), Equipment: rotational speed infinitely variable, FSQ 80(100) S/A3 CNC - TOS KUŘIM Bed Milling Machine, Table Length 3m Control System: Heidenhain 415F Complete Mechanical Overhaul: 2024 Availability: IMMEDIATE DELIVERY Warranty: 6 months FSQ 80(100) O/A3 CNC – Technical Specifications: Basic machine data: Manufacturer: TOS Kuřim Overall length: 7,760 mm Overall width: 4,360 mm Overall height: 3,400 mm Total weight: 18,000 kg Total power consumption: 40 kVA Working range: Longitudinal travel X-axis: 3,000 mm Cross travel Y-axis: 1,000 mm Vertical travel Z-axis: 900 mm Spindle head (S Head): Max. power: 22 kW Speed range: 16 – 3,500 rpm Number of speed ranges: stepless Spindle rotation around A-axis: 105° Spindle rotation around B-axis: 90° Lhsdpfxsxp Dkce Ab Ujn Feed range X – Y / Z: Number of speed ranges / range: stepless / 1 – 5,000 mm/min Rapid traverse Y – Z / X: 10,000 / 15,000 mm/min Table: Table area: 800 x 3,000 mm Max. load: 8,500 kg Control System: Heidenhain 415F Further details on request.

Condition: ready for operation (used), Year of construction: 2003, operating hours: 54,000 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 20,000 rpm, table width: 850 mm, table load: 4,000 kg, table length: 2,100 mm, total height: 330 mm, total width: 2,570 mm, total length: 5,200 mm, type of input current: three-phase, overall weight: 12,000 kg, distance table to spindle center: 45 mm, quill travel distance: 500 mm, spindle motor power: 15,000 W, MANUFACTURER: PARPAS • YEAR OF MANUFACTURE: 2003 • MODEL: PHS 920P • OPERATING HOURS: 54,178 • CONTROL UNIT BRAND: HEIDENHAIN iTNC 530 TECHNICAL DETAILS GENERAL DATA • WIDTH: 2570 mm • LENGTH: 5200 mm • HEIGHT: 3300 mm • WEIGHT: 12,000 kg CONTROL SYSTEM • BRAND: HEIDENHAIN • MODEL: 530 DRIVE • SPINDLE SPEED: 20,000 rpm (HSK A50) • SPINDLE POWER: 15 kW • NUMBER OF AXES: 5 TRAVELS • X-AXIS TRAVEL: 2000 mm • Y-AXIS TRAVEL: 1200 mm • Z-AXIS TRAVEL: 500 mm • A-AXIS ROTATION: +/- 65° • C-AXIS ROTATION: +/- 100° • MAX. RAPID TRAVERSE: 30 m/min TABLE • LENGTH: 2100 mm • WIDTH: 850 mm • T-SLOTS: 7 • DISTANCE BETWEEN T-SLOTS: 120 mm • MIN. DISTANCE SPINDLE TO TABLE: 45 mm • MAX. DISTANCE SPINDLE TO TABLE: 545 mm • MAX. TABLE LOAD: 4000 kg TOOLING • MAX. TOOL WEIGHT: 3 kg • MAX. TOOL DIAMETER: 50 mm • MAX. TOOL LENGTH: 150 mm • TOOL HOLDER TYPE: HSK A50 ADDITIONAL FEATURES • Spindle chiller • Air dryer for spindle lubrication Lhodsxg Rd Rjpfx Ab Usn • 20-position tool magazine with Heidenhain tool probe • Highly rigid construction • 5-axis simultaneous machining • Air and oil-cooled spindle • Z-axis compensation • Approx. 95 shrink-fit tool holders plus other accessories

Condition: refurbished (used), Year of construction: 2002, functionality: limited functionality, travel distance X-axis: 2,000 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 900 mm, feed length X-axis: 15,000 mm, feed length Y-axis: 15,000 mm, feed length Z-axis: 15,000 mm, Technical Description – CNC Machine Brand: ANAYAK Model: VH-2200 Lodpsxfa Aysfx Ab Ujhn Category: CNC Milling Machine Year of Manufacture: 2002 CNC Control: SELCA S3045 Machine weight: 10,000 kg Machine Dimensions: Length: 4,960 mm Width: 3,535 mm Height: 3,080 mm Spindle Technical Specifications: Taper size: ISO 50 Toolholder type: DIN69871-A50 Shank type: DIN69872-B50 Spindle speed: 60 ÷ 3,000 rpm Spindle motor power (cont./30 min.): 22/33 kW Universal milling head: 45° B-axis and C-axis angular positioning: Manual Working Capacity X-axis travel: 2,000 mm Y-axis travel: 920 mm Z-axis travel: 900 mm Spindle centre to column distance: 810 mm Table Dimensions: 2,200 × 750 mm Load capacity: 3,000 kg Number of T-slots: 6 T-slot width: 18 mm Distance between T-slots: 120 mm Feeds Rapid feed X / Y / Z axes: 10,000 mm/min Working feed X / Y / Z axes: 3,000 mm/min Other Machine supplied without automatic tool changer, complete with accessories and manuals.

Condition: good (used), Year of construction: 2009, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, Soraluce TA universal bed type milling machine, year of manufacture 2009, Heidenhain iTNC 530 control, travel X/Y/Z 2000/1000/1000 mm, table size 2000 x 800 mm, spindle speed up to 3,000 rpm, SK 40, electronic handwheel, universal milling head manually swiveling in 2 planes, thermal compensation, direct measuring systems X/Y/Z, 3D touch probe, linear roller guideways, prepared for tool changer, prepared for chip conveyor. Ledoxd Tn Hepfx Ab Uohn

Condition: good (used), Year of construction: 2002, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, Soraluce TA 20 Universal Bed Milling Machine, Year of manufacture: 2002, Control: Heidenhain TNC 426 M, 4th axis: Hofmann RW / NC 160, Travel X/Y/Z: 2000/800/800 mm, Linear roller guides on all axes, Table size: 2000 x 800 mm, Spindle taper: SK 40, Drive power: 21.5 kW, Universal milling head manually swiveling in 2 axes, Spindle speed up to 3,000 rpm, 3D touch probe, Thermal compensation, Direct measuring systems X/Y/Z, Lhodpoxd Tgcsfx Ab Uen Automatic cycle lubrication, Spindle orientation and thread cutting without compensating chuck, Machine weight: 10,000 kg,

Condition: used, Year of construction: 2008, MILLING MACHINE STS AVANTGARDE HS YEAR: 2008 CNC: SELCA S 4045 DH WORKTABLE DIMENSIONS: 2,200 mm x 1,100 mm TRAVEL PATHS: X: 2,000 mm Y: 1,500 mm Z: 1,500 mm SPINDLE TAPER: ISO 50 MAX. ALLOWABLE LOAD: 6,000 KG Ljdpexc Umhefx Ab Ujhn AUTOMATIC BI-ROTARY HEAD: A 2.5° - B 2.5° SPINDLE SPEED: 4,000 rpm POWER: 37 KW TOOL MAGAZINE: RANDOM, 24 POSITIONS HIGH PRESSURE: 20 BAR ACCESSORIES: 2-SPEED RANGE SELECTOR CHIP CONVEYOR MACHINE CAN BE SEEN IN OPERATION COMPLETE DOCUMENTATION

Condition: good (used), functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,200 mm, table width: 1,100 mm, table length: 2,700 mm, Sachman T22 fixed table milling machine with: - X axis 2500 mm - Y axis 1400 mm - Z axis 1200 mm - Table 2700 x 1100 mm - 24-position tool changer - Automatic head 1° x 3° at 5000 rpm Lhsdpfx Asxbn R Reb Usn - Heidenhain 430 digital CNC Free deferred payment over 12/24 months

Condition: used, TECHNICAL DETAILS TABLE - Table dimensions : 3100/800 [mm] - Maximum weight upon table : 7000 [kg] - Travels on X/Y/Z axes : 3000/1000/1200 [mm] - Rapid traverses rates (X/Y/Z) : 15000/15000/15000 [mm/min] MILLING HEAD Manual head MILLING SPINDLE - Tool holder type : ISO50 * Spindle speeds : 4000 [rpm] * Spindle power : 27 [kW] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 24 WEIGHT & DIMENSIONS - Machine floor space : 7913/5043 [mm] - Machine height : 3440 [mm] - Machine weight : 13410 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 38 [kW] MACHINE HOURS - Number of hours under power : 24689 [h] - Number of working hours : 23809 [h] - Number of spindle hours : 7658 [h] EQUIPMENT - CNC : Heidenhain iTNC530 - Electronic handwheel Interface : RS232/RJ45/USB - Interactive programming - Coolant tank Lsdpfxsw Tnhbe Ab Uehn - Tool-holders

Condition: used, Year of construction: 1993, Sachman T20 Universal Head Bed Milling Machine. Serial No. 166987 (1993) with Heidenhain 407 CNC Control, Travel X/Y/Z = 3600/1200/1200mm, Table Size 3800 x 1100mm, 30 Tool ATC, Spindle Power 24 Kw, Spindle Taper ISO 50, Swarf Conveyor, Instal Power 69kw, Machine Weight 17.000kg Lodpfx Abow Tk T Ho Ushn Please Note: Dismantling and Loading will be carried out by our own supplier.

Condition: ready for operation (used), travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, Correa A-20-25 Bed Type Travelling Universal Milling Machine Spindle Speeds 20 - 2000rpm Spindle Taper ISO50 Spindle Motor 15kW Table Size 2500 x 700mm Longitudinal X Axis Travel - 2200mm Vertical Y Axis Travel - 1000mm Cross Ram Z Axis Travel - 1000mm Lodpfxow Rg Rve Ab Ushn Range of Feeds Inf. Variable 5 - 1500mm/min Rapid Feeds 3000mm/min Overall dims - 3600 (5800) x 2220 (3320) x 2750 (WDH) Weight 9500kgs. *For sale with Jet Machinery Ltd* Stock No: 78976 Serial No: 9210511 Price: £17,500.00 + VAT

Condition: good (used), Year of construction: 2009, Working hours (dated April 2025): - Machine on: 34.320 h - Control on: 23.218 h - Auto. cycle: 11.987 h Ledpow Icccjfx Ab Uehn * CNC control HEIDENHAIN iTNC 530 * Electronic handwheel * Automatic universal milling head (overhauled in 2018), 2.5 / 2.5 deg. indexing * Coolant device with paper band filter * Cooling through the spindle * Chip conveyor * NC rotary table YRT F 1000/1250 (4th axis): - Diameter 1250 mm - Max. load 3500 kg - Overall height 265 mm - Table top thickness 125 mm - Partial accuracy +/- 2.5" x-travel 2500 mm y-travel 1600 mm z-travel 1200 mm Table dimensions 2860 x 1200 mm tool taper ISO 50 spindle turning speed range 20 - 3000 rpm max. torque on the spindle 700 Nm feed range 2 - 10000 mm/min rapid traverse 25 m/min spindle motor 32 kW weight of the machine approx. 25,0 t

Condition: ready for operation (used), Year of construction: 2003, Control Unit Brand SELCA Model SELCA 3040 Main Drive Spindle speed range 5000 Lodpjwyyhhjfx Ab Ushn Spindle motor power 22 kW Tool taper ISO 50 Number of axis 4 Movement X-Axis Movement 2000 mm Y-Axis Movement 1250 mm Z-Axis Movement 1250 mm Media Chip conveyor Yes Additional Equipment Remote handwheel Chip conveyor Through-spindle coolant This 3-axis Parpas THS125/2000TG was manufactured in 2003. It features a SELCA 3040 control unit, a main spindle with 5000 rpm and 22 kW power, and an electrospindle that reaches up to 28,600 rpm. The machine includes a 24-position tool changer and accessories like a chip conveyor and through-spindle coolant. If you are looking to get high-quality milling capabilities consider the Parpas THS125/2000TG machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2000, Main Drive Spindle speed range 45000 Spindle motor power 6 kw Movement X-Axis Movement 2450 mm Y-Axis Movement 1400 mm Z-Axis Movement 800 mm This 5-axis GEISS FZ 2000 x 1000 was manufactured in 2000. It features a robust CNC milling machine capability with X-axis travel of 2450 mm, Y-axis of 1400 mm, and Z-axis of 800 mm. The milling spindle supports a maximum speed of 45000 rpm with a power of 6 kW. Consider the opportunity to buy this GEISS FZ 2000 x 1000 CNC milling machine. Contact us for more information about this machine. Application Types Milling Lodpjwwbkrofx Ab Uohn

Condition: used, Year of construction: 2007, MILLING MACHINE STS AVANTGARDE HS YEAR : 2007 CNC : SELCA S 4045 DH TRAVELS : X : 3,000 mm Y : 1,500 mm Z : 2,000 mm TABLE DIMENSION : 1,500 mm x 1,500 mm MAX. PERMISSIBLE LOAD : 8,000 KG. AUTOMATIC DOUBLE-ROTATION HEAD: A 2.5° - B 2.5° ISO: 50 4,000 rpm 37 KW TOOL MAGAZINE: RANDOM 32 POSITIONS Lodpfx Aewtd Uxeb Ushn HIGH PRESSURE: 20 BAR ACCESSORIES: 2-SPEED RANGE CHANGE CHIP CONVEYOR MACHINE VISIBLE IN OPERATION COMPLETE WITH ALL DOCUMENTATION

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: M-970504, travel distance X-axis: 2,500 mm, travel distance Y-axis: 935 mm, travel distance Z-axis: 900 mm, spindle speed (max.): 3,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS CNC control: Heidenhain (2x control units) Ledpfx Aowpiuvsb Ushn Travel X: 2,500 mm Travel Y: 935 mm Travel Z: 900 mm Machine Table Table size: 2,900 × 800 mm Rotary table size: 800 × 800 mm Spindle Spindle speed: 3,000 rpm Tool holder: ISO 50 Tool magazine: 30 slots Milling head: pivotable Machine dimensions and weight Machine dimensions (L × W × H): 6,500 × 3,200 × 3,500 mm Machine weight: 18,500 kg EQUIPMENT - Dual CNC control with Heidenhain control systems - Large bed table with separate 800 × 800 mm rotary table - Swivel milling head for flexible machining - Spindle with 3,000 rpm and ISO 50 tool holder - Automatic tool magazine for 30 tools - Includes all peripheral devices and documentation - Machine is already dismantled for transport

Condition: used, Year of construction: 1999, operating hours: 56,000 h, functionality: fully functional, machine/vehicle number: 99100253, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, table width: 750 mm, table load: 4,000 kg, table length: 2,200 mm, overall weight: 10,000 kg, - Heidenhain TNC 410 control - Including printed user manual - No accessories included For further information, please refer to the photos. A video of the machine in operation can be provided upon request. Viewings are possible by appointment. Collection must be organized by the buyer. Loading onto a truck/container provided by the buyer is included. Price negotiable -- Ledpfx Abjwk A D Te Uehn As these are used machines / used spare parts, we exclude any warranty and guarantee. The information has been compiled to the best of our knowledge, but we assume no liability. We reserve the right for technical data deviations and errors in the description. The buyer has the right to inspect the goods for condition and functionality before entering into the contract. We exclude any warranty for visible and hidden defects, as well as any compensation for damages of any kind, including damages not affecting the delivered item itself.

Condition: reconditioned (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 12473, travel distance X-axis: 2,995 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 795 mm, spindle speed (max.): 2,000 rpm, The scope of delivery includes 15 ISO 50 tools for various applications, 1 rotary table, and 2 vices, as shown in the pictures. TECHNICAL DETAILS Travel X-axis: 2,995 mm Travel Y-axis: 800 mm Travel Z-axis: 795 mm Table size: 2,995 × 800 mm Number of T-slots: 5 Coolant tank: 300 L Spindle Tool holder: SK50 Spindle speed: max. 2,000 rpm Feed Max. feed rate: 5,000 mm/min Max. rapid traverse: 6,000 mm/min MACHINE DETAILS Lodpfx Abjwkqa Ae Ushn Dimensions: 8,000 × 3,500 × 3,000 mm EQUIPMENT - CNC control retrofitted by NCT - Horizontal and vertical machining possible

Condition: ready for operation (used), Year of construction: 1998, Control Unit Brand BOSCH Model OSA3 Main Drive Number of axis 4 Movement X-Axis Movement 2000 mm Y-Axis Movement 500 mm Z-Axis Movement 500 mm Tools Number of index 48 Type of tool holder HSK63 Media Chip conveyor Yes This 4-axis Matec 30 L gantry milling machine was manufactured in 1998. Consider the opportunity to buy this Matec 30 L gantry milling machine. Contact us for more information. Application Types Lsdpfxswd Ux Ns Ab Ushn Milling

Condition: used, Year of construction: 1998, Technical details: x-travel: 6.000 mm y-travel: 1.000 mm z-travel: 1.700 mm table surface area: 7.200 x 1.100 mm control: FIDIA M 30 turning speeds: 4.000 1/min tool taper: SK 50 spindle drive: 25 kW rapid traverse: 20 m/min total power requirement: 60 kW dimensions of the machine ca.: 11,5 x 6,2 x 4,15 m CNC universal-travelling column-milling machine, automatic millling head (type TBA4) swivelable in 2 layers 1°/3°, NC-controlled rotary table TABONI 1.500 x 1.500mm, 0,5° indexing, incl. HSC-spindle E28 (electrospindle, 500 - 21.000 1/min, HSK 50, 15kW, 12Nm), incl. 2 clamping angles (each 1.000 x h2.500mm), chiller, minimum quantity lublication, airblast outside, no toolchanger, no chipconveyor hour meter defect - estimated hours "machine on": approx. 100.000. Lhedpfx Abowcc Dke Usn under power in factory (near Munich) *

Condition: like new (used), Year of construction: 2023, DIVISIO 5100 (2023) Machine Type: Automatic Depaneling System Ljdpfx Abov R D Nlo Ujhn Model: DIVISIO 5100 Transport height: 920 mm ± 50 mm Max. transport width: 460 mm Interface: SMEMA, Hermes, Siemens Transfer direction: Left to right or right to left Operating side: Front of the machine Fixed rail: Front of the machine Panel length: 70 to 460 mm Panel width: 50 to 460 mm Panel thickness: 0.5 to 5.0 mm Max. panel weight: 1.5 kg Max. PCB weight: 1.5 kg Component height, spindle-side: 8 mm; partial 18 mm (other height on request) Component height, gripper-side: 40 mm Trays on lane 2: 600 x 400 mm Power supply: 400V, 208V 50/60Hz, ±10% Power supply system: 3L + N + PE Fuse protection: 3x C16 A without ELCB Power consumption (without suction): 0.8 kW Air supply: 6 bar Air consumption: 120 Nl/min Machine dimensions (L x W x H): 1200 x 2360 x 2152 mm Weight: 1800 kg (standard equipped) Speed (X, Y): 2000 mm/s Speed (Z): 1500 mm/s Acceleration (X, Y): 20 m/s² Acceleration (Z): 15 m/s² Positioning accuracy: ±0.02 mm (20°C ±1°C) Repeatability: ±0.005 mm (20°C ±1°C) Cutting accuracy: ±0.08 mm (20°C ±1°C) Noise level: < 75 dB(A) (may vary due to material mix of the panel)

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, year of last overhaul: 2025, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! Technical details of the machine: Year of manufacture: 2008 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 2,500 Y-axis (mm) 1,250 Z-axis (mm) 1,000 Rotary table size: Length (mm) 1,000 Width (mm) 1,000 Spindle speed range: 15,000 rpm Feed rates: X, Y & Z axes (mm/min): 10 - 10,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 25,000 Milling head: Automatic milling head, vertical Tool holder: HSK 63 A Main spindle drive power: 100% duty cycle KW25 - Chip conveyor - Cooling lubricant system - 3D thermal expansion compensation - Portable electronic handwheel Heidenhain HR 410 with 3m spiral cable - INA RUE 45 linear guideway system on all linear axes with central lubrication - Complete splash guard enclosure RepairFIT is our proven offering for a profitable entry into our product lines. Lsdpfx Asv Rw Uujb Ushn The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team.

Condition: used, Year of construction: 1999, Technical details: x-travel: 2000 mm y-travel: 1500 mm z-travel: 1460 mm milling spindle motor: 35/30 kW spindle taper ISO: 50 spindle turning speed range: 24 - 3000 U/min table surface area: 1350 x 1550 mm table load: 6 t feed speeds: 10 - 3000 mm/min rapid speed: 10 m/min Lhjdsv Rdzbspfx Ab Uon total power requirement: 48 kW weight of the machine ca.: 24 t CNC HEIDENHAIN TNC 426 B-axis table round Horiz. and Vertikal automatic positioning Milling Head *

Condition: used, Year of construction: 2010, STS AVANTGARDE MILLING MACHINE YEAR: 2010 5 AXES: 3 + 2 CNC: HEIDENAIN 530 TRAVELS: X: 3,000 mm Y: 1,500 mm Z: 2,000 mm TABLE DIMENSION: 3,200 mm x 1,200 mm MAX. PERMITTED LOAD: 8,000 KG. ATC: N° 24 SPINDLE SPEED: 8,000 RPM CONE: HSK HIGH PRESSURE: 20 BAR CHIP CONVEYOR MACHINE VISIBLE IN OPERATION VARIOUS VIDEOS OF THE MACHINE IN OPERATION AVAILABLE. N.B. : HEAD TO BE OVERHAULED POSSIBILITY OF GIVING IT WITH HEAD OVERHAULED DIRECTLY BY STS. Lhjdsv Igblepfx Ab Ujn

Condition: good (used), travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,600 mm, Manufacturer: SORALUCE Type: TL-25 Control: HeidenHain TNC 430 Year of manufacture: 1998 Aiptek ATC 30 positions Automatic head 2.5 x 2.5 Gr Central lubrication Machine housing with front doors Large tool package Specifications Metric US Standard X-axis 2500 mm Y-axis 1000 mm Z-axis 1600 mm Table length 2860 mm Table width 1000 mm Table load 7500 Spindle power 25 kW Spindle speed 0 - 3000 rpm Tool holder 50 ISO/Bt/Mk X-axis feed 10000 mm/min. Ljdpfxjv Idalj Ab Uehn Y-axis feed 10000 mm/min. Z-axis feed 10000 mm/min. Milling head auto index 2.5 x 2.5° Working hours 12500 H Dimensions (estimate) Length 6000 mm Width 3500 mm Height 3500 mm Weight 15000 kg Please note: The information on this page is correct to the best of our knowledge and belief and, where possible, has been obtained from the manufacturer. The information is given in good faith but its accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you check all important details.

Condition: used, Year of construction: 1999, x-travel 2000 mm y-travel 800 mm z-travel 850 mm control HEIDENHAIN TNC 360 Lodov H Ertjpfx Ab Uehn total power requirement / kW weight of the machine ca. / t required space / m
