Condition: excellent (used), Year of construction: 2020, We offer you: CNC machining centre – universal with milling-turning function Manufacturer: DMG MORI Model: DMU 125 FD duoBLOCK Year of manufacture: 2020 Control: Celos with Siemens 840D sl Operate Technical data: Travel: - X-axis travel: 1,250 mm - Y-axis travel: 1,250 mm - Z-axis travel: 1,000 mm Main spindle: - Speed: 12,000 rpm - Drive power (40/100%): 44 / 33 kW - Torque (40/100%): 288 / 187 Nm - Tool holder: HSK-A 100 - Swivel range: -30° / +180° NC rotary table: Golhswy Uy Sscdwzoiw - Table diameter: 1,250 mm - Max. table load: 2,600 kg - Rotary table speed: 500 rpm Tool changer: - Number of tool stations: 40 positions - On-time hours: approx. 9,500 h - Operating hours: approx. 5,000 h Technical features: - ICS 40 bar - Coolant spray gun for chip evacuation - Rotating inspection window - MPC Machine Protection Control - MDynamics: improved surface quality with simultaneously reduced machining time Accessories: - Paper band filter 980 l - Chip conveyor - Renishaw PP60 optical touch probe - 3D quickSET - Electronic handwheel Accessories, depicted tools and clamping devices are only included in the scope of delivery if specified in the additional information. Subject to technical changes, errors, and prior sale!

Condition: good (used), Year of construction: 2012, EiMa ALPHA T CONTURA 5-axis universal machining center Year of manufacture: 10/2012 Control: SIEMENS 840D sI 720 NCU Machine no.: 11744 Travel distances X – 5,029 mm / Y – 1,202 mm / Z – 772 mm B-axis travel ±121° C-axis travel ±211° Rapid traverse X/Y/Z = 60/60/40 m/min. New milling spindle installed on 19/05/2025 Equipment: - 5-axis fork head - Milling spindle 15 kW / 12 Nm / 24,000 rpm - For milling, drilling, sawing - Disc tool changer for 12 tools, HSK-63 F - Pick-up station for saw blade - Spindle cooling unit - Fluidtech minimum quantity lubrication system - Partition wall for pendulum/simultaneous machining - Vacuum clamping plate by WITTE, 2,100 mm x 1,200 x 42 mm - Chip conveyor - Extraction unit by LOSMA NEWTON N6 Gelhjwy Iw Rscdwzsiw Scope of delivery includes: approx. 35 tool holders / operating manual / documentation Equipment, technical data, and transport drawing – see PDF. Pictures, contents, and information are given without guarantee and therefore non-binding. All additional accessories visible in photos and videos are not included in the scope of delivery and thus not part of this sale. The delivery scope consists solely of the accessories expressly specified herein, in the order confirmation, and in the invoice. PRICE net €49,900 FCA (Free Carrier – loaded on truck) D-97944 Boxberg Packaging not included Delivery time: immediately Subject to prior sale / Payment due immediately upon completion of purchase

Condition: used, Year of construction: 2008, x-travel 1000 mm y-travel 1000 mm z-travel 1000 mm Control Heidenhain iTNC 530 max. turning speeds 12.000 min/-1 drive capacity - main spindle 100/40% ED 19 / 28 kW max. torque 100/40% ED 82 / 121 Nm tool taper HSK A 63 total power requirement 69 kW weight of the machine ca. 20,5 t Giolhcdwowy H Ibezsw dimensions of the machine ca. ca. 5,5 x 6,3 m In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: good (used), Year of construction: 2001, Functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 12,000 rpm, CNC control Heidenhain TNC 430 NC-swivel head B-axis NC-rotary table C-axis automatic tool changer for 30 tools coolant through spindle device (IKZ) 40bar chip conveyor coolant device Technische Daten / technical details: X-Weg / X-travel 1250 mm Y-Weg / Y-travel 880 mm Z-Weg / Z-travel 800 mm C-Achse Rundtisch / C-axis rotary table 360 x 0,001 ° Spindelaufnahme / spindle taper SK 40 Drehzahlbereich Spindel / spindle speed 12000 Upm /rpm Vorschub / infeed 20-10000 mm/min Eilgang / rapid feed 24 m/min Rundtischabmessungen / rotary table measures 1250x1000 mm Gewicht der Maschine ca. / weight 13000 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. Giolhswyu Ezjcdwzjw

Condition: ready for operation (used), Year of construction: 2000, General Data Measurements width 6000 mm Measurements depth 7000 mm Measurements height 3000 mm Machine weight 12200 kg Control Unit Brand HEIDENHAIN Model TNC 426 Main Drive Spindle speed range 8000 rpm Spindle motor power 15 / 10 kW Gislhcdwjwygn Iszow Tool taper SK 50 Number of axis 4+1 Movement X-Axis Movement 1250 mm X-Axis Rapid Traverse 40 m/min Y-Axis Movement 880 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 800 mm Z-Axis Rapid Traverse 40 m/min Table Number of tslots 9 Table load 2000 kg Tools Number of station 30 Max weight 20 kg Max tool diameter 110 mm Max tool length 420 mm Media Chip conveyor Yes Additional Equipment Documentation Coolant System High-pressure Coolant (40 bar) Through-spindle Coolant Electronic Handwheel 90° Swivelling Milling Head (H/V) 30-position Tool Magazine Touch Probe M&H RMP 2000 Hydraulic System Oil Mist Extraction This 5-axis DECKEL MAHO DMU 125 P hi-dyn was manufactured in 2000. It features a Heidenhain TNC 426 control, a swiveling head, and a NC rotary table with a 360° B-axis rotation. The main spindle supports up to 8,000 rpm with a power of 15 kW. It includes a 30-position tool magazine and a high-pressure coolant system. If you are looking to get high-quality milling capabilities consider the DECKEL MAHO DMU 125 P hi-dyn machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2006, operating hours: 16,421 h, Control Unit Brand HEIDENHAIN Model iTNC530 Main Drive Spindle speed range 18000 Gelewygraehcdwzoiw Tool taper BT40 Number of axis 5 Movement X-Axis Movement 2500 mm Y-Axis Movement 920 mm Z-Axis Movement 820 mm This 5-axis DECKEL MAHO DMF 250 linear was manufactured in 2006. It features a Heidenhain iTNC530 control, extensive travel capabilities with X2,500mm, Y920mm, Z820mm, and a high-speed spindle at 18,000rpm. The machine includes a BT40 spindle taper, ATC 30 magazine, and full NC rotary capabilities on A, B, and C axes. Consider the opportunity to buy this DECKEL MAHO DMF 250 linear universal machining centre. Contact us for more information about this machine. Application Types Milling

Condition: reconditioned (used), Year of construction: 2014, Immediately available: Traveling column machine FS 1200 • Total travel X=12,000 mm, ideal for flexible large-scale machining Gelhcdowyclcowzeiw • Travel X=12,000 mm, Y=1,500 mm; Z=3500mm • Control iTNC 530 with wireless radio handwheel HR 550 FS, operator cabin on the traveling column • 2-axis NC universal drilling, milling head, fully simultaneous and positioning operation per traveling column • Spindle HSK-A 100, 10,000 rpm, 220 Nm spindle torque • IKZ air up to 6 bar • Dust protection packages to protect the guides and drives • BA 4 per traveling column • Radio measuring probe RMP 60, Renishaw make • Work area monitoring with network camera and monitor on the back of the system • Process monitoring ToolScope basic system • Additional control panel on the back of the system • Partial housing consisting of work area and sheet metal door, back with protective fence with a clear view into the work area • incl. fixators • Cooling units • incl. internal tool cooling (closed cooling circuit) with Cooling unit • short delivery time, available immediately, ---subject to prior sale--- Viewing possible by arrangement Spindle hours: approx. 9079 SPECIAL PRICE!

Condition: good (used), Year of construction: 2018, operating hours: 2,487 h, Functionality: fully functional, CNC command : Fanuc 31i Model B Table Size 2,700 x 950 MM Table Load 4,500 KG Axis Travels - X / Y / Z 2,450 / 960 / 850 MM Spindle Nose to Table 200 ~ 1,050 MM Spindle Taper BBT 50 Gelhcdswyb D Rewzeiw Spindle Speeds 8,000 RPM Spindle Power 22.0 / 18.5 KW Rapid Traverse Rates - X / Y / Z 16 / 16 / 20 M/MIN Number of ATC Stations 20 Machine is equipped with the following accessories: - 4th Axis - Coolant Tank + High pressure cooling pump - Chip conveyor - Tools

Condition: excellent (used), Year of construction: 2005, Functionality: fully functional, Technical details x-travel 3600 mm y-travel 920 mm z-travel 820 mm Control Siemens 840 D table surface area 4200 x 900 mm table load capacity - central/maximum 4200 kg tool taper HSK-A63 DIN 69893 spindle turning speed - stepless 20 - 18000 U/min feed speeds - 20000 mm/min rapid travel x/y/z 100 / 60 / 60 m/min spindle motor (100/40% ED) 25/35 kW total power requirement 92 kVA weight of the machine ca. 29,5 t dimensions of the machine ca. 10,00 x 6,50 m Additional information Maintenance condition: Regular maintenance, no maintenance backlog. Very good used condition ! * CNC control Siemens Sinumerik 840 D Powerline with ShopMill * Controlled axes 5 * Controlled swivel milling head (B-axis) +/- 90 deg., 1 deg. indexing * C-axis with CNC-rotary table * 126-station ATC 0 - 6,000 rpm Max. tool diameter (with free neighbouring space) 130 mm Max. tool length 360 mm 6,001 - 10,000 rpm. max. tool diameter 100 mm max. tool length 250 mm 10,001 - 12,000 rpm. max. tool diameter 80 mm max. tool length 250 mm 12,001 - 18,000 rpm. max. tool diameter 50 mm max. tool length 200 mm max. tool weight with automatic tool change 6 kg max. total tool weight in the magazine 180 kg * 5-station Pick-up magazine (additionally installed in the work area) - Max. tool length 450 mm * Chip conveyor * Compact filter system, 900 liters volume * Coolant through spindle 40 bar Without clamping plates, toolholders, etc. Transport dimensions approx. (L x W x H) Machine 7.830 x 3.400 x 3.100 mm Coolant system 2.100 x 1.200 x 2.150 mm Chip conveyor 1.300 x 8.900 x 1.700 mm Working area Travels X-axis 3,600 mm with B-axis travel left 1,316 mm with B-axis travel right 1,399 mm Work table Rigid table Clamping surface 4,200 x 900 mm Distance between T-slots 100 mm Number of T-slots 9 pieces Permissible load of the worktable Rigid table (table centre) 4,200 kg Gielhjwx Hxkocdwzjw Main drive Drive power 25 KW (100% ED)35 KW (40% ED) Torque 87Nm (100% ED)130Nm (40% ED) Speed Infinitely programmable 20 - 18,000 rpm Speed in set-up mode 20 - 800 rpm

Condition: used, Year of construction: 1999, x-travel 1200 mm y-travel 800 mm z-travel 500 mm control HEIDENHAIN TNC 430 spindle turning speed range 20 - 10000 U/min Spindle power 25 kW tool magazin: 30 stck. weight of the machine ca. 15000 t required space 3,1 x 4,0 x 2,76 m Giolhcdwowxy Daozow The A-axis has a cable break, therefore without function.

Condition: good (used), Year of construction: 2010, Ref. -No.: 10524 Manufacturer: DMG Type: DMU 100 monoBLOCK Year of construction: 2010 Type of control: CNC Control: HEIDENHAIN iTNC 530 Storage location: Halberstadt Country of origin: Germany - Japan Machine-No.: 116XXXXX X-Travel: 1250 mm Y-Travel: 710 mm Z-Travel: 710 mm B-Axis: 360 ° Golhcdswxvnzjwzjiw C-Axis: 0,001 ° Machine length: 3500 mm Machine width: 2650 mm Machine Height: 2700 mm Table Load: 800 kg Tool Taper: HSK 100 Tool Piece Magazine With: 60 Pcs./pcs. Spindle Speed: 16.000 RPM Weight Of The Machine Ca.: 11 t Size Of Pallet: 1500 x 800 mm Further information: B-axis (-120° / +30°) NC rotary table integrated in fixed table Direct measuring system 3D probe infrared HEIDENHAIN TS 640 IKZ 40bar, 600l Flushing gun, chip conveyor 3D quickset software The machine is currently in production and can be inspected under power by prior arrangement.

Condition: used, Year of construction: 2014, Functionality: unexamined, Hurco VMX60SRTI machining centre (2014) Gislhewxfl Ajcdwzew

Condition: ready for operation (used), Year of construction: 2004, operating hours: 30,238 h, Control Unit Brand HEIDENHAIN Model TNC 530 Main Drive Spindle speed range 60 - 5000 rpm Spindle motor power 28/38 kW Tool taper SK 50 DIN 69871 Movement X-Axis Movement 5300 Y-Axis Movement 1500 Z-Axis Movement 2000 A-Axis Movement +45 to -225° B-Axis Movement +165 to -18° Clamping Unit Gielhcewwxl Todwzew Clamping force 8 kg This 5-axis ANAYAK HVM 6000 universal machining center was manufactured in 2004. It features a HEIDENHAIN TNC 530 control, extensive travel capabilities with x-travel at 5,300 mm, y-travel at 1,500 mm, and z-travel at 2,000 mm. The machine has undergone a thorough overhaul, ensuring all components meet original specifications. If you are looking to get high-quality milling capabilities, consider the ANAYAK HVM 6000 machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2018, operating hours: 2,195 h, General Data Measurements width 3767 Measurements depth 4954 Measurements height 3187 Machine weight 8400 Control Unit Brand HURCO Main Drive Spindle speed range 12000 / optional 16000 Spindle motor power 36.5 kw Tool taper SK40 Movement Gijlowwm R Rehcdwzjw X-Axis Movement 1067 mm X-Axis Rapid Traverse 38 m/min Y-Axis Movement 610 mm Y-Axis Rapid Traverse 38 m/min Z-Axis Movement 610 mm Z-Axis Rapid Traverse 32 m/min B-Axis Movement +/- 90º B-Axis Rapid Traverse 50 rpm C-Axis Movement 360º C-Axis Rapid Traverse 100 rpm Table Tslots size 5 x 18 x 100 Min distance between vertical spindle and table 9 mm Max distance between vertical spindle and table 619 mm Table load 1360 kg Tools Slots in storage 40 Max weight 7 kg Max tool diameter 75 mm Max tool length 250 mm Media Chip conveyor Yes Additional Equipment Coolant capacity (l): 314 Equipped with: Renishaw calibration, through-spindle cooling, linear scales This 5-axis Hurco VMX 42 SRTi was manufactured in 2018. A universal machining centre, it offers advanced capabilities for complex and precise machining tasks. If you are looking to get high-quality milling capabilities, consider the Hurco VMX 42 SRTi machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2013, Ref. -No.: 10450 Manufacturer: SHW Type: UNISPEED 5 Year of construction: 2013 Type of control: CNC Control: HEIDENHAIN iTNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 32XX X-Travel: 2000 mm Y-Travel: 2300 mm Z-Travel: 1300 mm B-Axis: 360 ° Gislowwgrhshcdwzow C-Axis: 360 ° W-Axis: 1500 mm Table Load: 15000 kg Max. Tool Weight: 25 kg Max. Tool Length: 500 mm Max. rotary table diameter: 1600 O Table speed range: 5 min/-1 Tool Taper: HSK 100 Tool Piece Magazine With: 150 Pcs./pcs. Turning Speed Range - Stepless: 22 - 8000 RPM Max. Torque: 40 Nm Feed Speeds X/Y/Z Axis: 2 - 30.000 mm / min axes: 5 Rapid Travel X/Y/Z: 30.000 mm / min acceleration: 2 m/s² Dimensions Of The Machine Ca.: 8,4 x 7,1 x 5,3 m Operating hours: 42.499 H Tool change time: 10 s Further information: automatic universal milling head, 360 x 1°; 180 x1° compact coolant system, make Knoll, type KF150/950 high pressure pump belt filter coolant temperature control Blum laser measuring system Renishaw RMP 60M infrared measuring system 140 tool holders HSK 100 included Machine can be inspected under power by appointment.

Condition: good (used), Year of construction: 2000, Ref. -No.: 10427 Manufacturer: OMV Type: MAV 412 Year of construction: 2000 Type of control: CNC Control: HEIDENHAIN TNC 426/430 Storage location: Halberstadt Country of origin: Italy X-Travel: 1200 mm Y-Travel: 850 mm Z-Travel: 800 mm B-Axis: +/- 95 ° C-Axis: 0,0001 ° NC swivel rotary table: 520 O Golhcewwgrbjdwzjiw Table Load: 3000 kg Table surface: 2300 x 980 mm Tool Taper: HSK 63 Tool Piece Magazine With: 20 Pcs./pcs. Spindle Speed: 0 - 16.000 RPM Turning Speed Range - Stepless: 0 - 20.000 mm / min Drive Capacity - Spindle Motor: 26 kW Total Power Requirement: 36 kW Weight Of The Machine Ca.: 17 t Dimensions Of The Machine Ca.: 5,4 x 4,4 x 3,1 m Further information: Operating hours: 32500 h Spindle hours: 10000 h - IKZ (internal cooling) - Milling spindle overhaul: Motor winding, bearing, tool clamp (2022) - AXA FSB400 chip conveyor (year 2021) - Compressed air preparation renewed (2023)

Condition: good (used), Year of construction: 2009, Ref. -No.: 10286 Manufacturer: STARRAG HECKERT Type: HEC 1600 Athletic Year of construction: 2009 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Schweiz Machine-No.: 24139 X-Travel: 2800 mm Y-Travel: 2100 mm Z-Travel: 1900 mm Table Dimensions (Lengthxwidth): 2 x 1.250 x 1.600 mm Table Load: 8.000 kg Max. Tool Weight: 35 kg Workpiece Diameter At Full Load: 110 mm Tool Piece Magazine With: 240 Pcs./pcs. Turning Speeds: 20 - 9.000 RPM Tool dimensions (with occupied adjacent spaces): 125 mm Rapid Travel X/Y/Z: 40.000 mm / min Weight Of The Machine Ca.: 35 t Numbers Of Pallets: 2 Gijlhcjwwgpyedwzjw pallet change time: 60 s Further information: internal coolant supply

Condition: ready for operation (used), Year of construction: 2012, Control Unit Brand HEIDENHAIN Model iTNC 630 Gelhcdjwwbkljwzoiw Main Drive Number of axis 5 Movement X-Axis Movement 1520 mm Y-Axis Movement 700 mm Z-Axis Movement 600 mm This 5-axis SPINNER U-1520 was manufactured in 2012. It features a Heidenhain iTNC630 control, a 3D measuring probe, and both internal and air cooling systems. The machine includes an 89-position tool changer with travels of X=1520mm, Y=700mm, and Z=600mm. If you are looking to get high-quality milling capabilities, consider the SPINNER U-1520 machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2019, Control Unit Brand HEIDENHAIN Model iTNC 640 Main Drive Spindle speed range 16000 Spindle motor power 38 kW Number of axis 5 Movement X-Axis Movement 1000 mm Y-Axis Movement 1100 mm Z-Axis Movement 810 mm Tools Type of tool holder HSK 63-A Additional Equipment Chip Transport: Scraper belt chip conveyor (ejection height: 1100 mm) Protective systems: Full-space protective cladding with angled door and quick-access door Laminated glass viewing windows This 5-axis Reiden RX10 5X was manufactured in 2019 and features a HEIDENHAIN TNC 640 control system, a swiveling control panel with dual 19" monitors, and a high-speed swivel milling head with a speed of 16,000 min-¹. It includes a rack magazine with 85 tool places and an internal coolant supply at 80 bar. If you are looking to get high-quality milling capabilities, consider the Reiden RX10 5X machine we have for sale. Contact us for more information. Application Types Milling Giolhcswvmwzedwzew

Condition: used, Year of construction: 2005, 3-Axis Machining Center • Manufacturer: Keppler • Type: 000830.08 • Serial number: 240538-01 • Year of manufacture: 2005 • Control system: Siemens Transline 2000HMI Winpro • Machine dimensions: approx. 7,750 x 7,140 mm, height: 3,930 mm • Weight: approx. 12 t • Operating hours (displayed): Drill head 1: 2,875 h Drill head 3: 4,677 h Drill head 4: 4,623 h Total: 19,045 h • Equipped with 4 holders for drill heads, HSK63 tool holder, dual, rotatable workpiece fixture • Handling system with 2 gripper arms • Tool loading and unloading station • Chip conveyor, manufacturer: Ruez, year: 2004, S/N: 2009902-110 • Hydraulic power unit, manufacturer: GKS, type: A4.8554.1-01, S/N: 15464 • Lubrication filter unit, manufacturer: Ruez, type: Filteranlage, S/N: 2009902-10, year: 2004 • Clamping device, workbench with 8 drawers, double-door tool cabinet (mid-height) • Tool presetting unit, manufacturer: Kelch, and various accessories Gielhswvixhjcdwzjw

Condition: ready for operation (used), Year of construction: 2018, Control Unit Gislhcdwjwvb Emjzow Brand HEIDENHAIN Model TNC 630 Main Drive Number of axis 5 Movement X-Axis Movement 1800 mm Y-Axis Movement 700 mm Z-Axis Movement 700 mm Tools Type of tool holder HSG 63 This 5-axis DMG MORI DMF 180/7 was manufactured in 2018 and features a Heidenhain TNC630 control unit. It includes a 90-fold tool changer, internal and air cooling, and a 3D probe. A new spindle was installed a year ago, enhancing its performance. If you are looking to get high-quality milling capabilities, consider the DMG MORI DMF 180/7 machine we have for sale. Contact us for more information about this machine. Application Types Milling

Condition: not inspected (used), Year of construction: 2010, Functionality: unexamined, machine/vehicle number: 1159, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,700 mm, number of slots in tool magazine: 40, swivel angle A-axis (min.): -105 °, swivel angle A-axis (max.): 105 °, Equipment: documentation/manual, No reserve price – guaranteed sale to the highest bidder! Placing a bid is binding and obligates the buyer to collect the machine within the specified period: July 28, 2025, to July 31, 2025. Machine includes approx. 90 tool holders TECHNICAL DETAILS Travel Range X-axis: 4,000 mm Travel Range Y-axis: 1,200 mm Z-axis Travel (horizontal): 1,700 mm Z-axis Travel (vertical): 1,690 mm Gislswu E Ezehcdwzsw Rapid traverse: 30 m/min Swivel Head and Axis System Swivel Head: Two-axis universal swivel head, continuously adjustable in both axes simultaneously Clamping: Axes can be hydraulically clamped via M-function A-Axis Working Range: ±180° Torque without clamping: max. 1,750 Nm Torque with clamping: max. 2,500 Nm Direct measuring system: ±3″ B-Axis Working Range: ±180° Torque without clamping: max. 4,200 Nm Torque with clamping: max. 12,000 Nm Direct measuring system: ±5″ Spindle Speed range: 20 – 8,000 rpm Power at 40/100% duty cycle: 33/24 kW Torque at 40/100% duty cycle: 382/278 Nm Tool Magazine Number of tool stations: 40 Tool holders included: approx. 50 HSK 100 + 40 HSK 100 in magazine Max. tool weight: 20 kg Tool length: 460 mm Max. tool diameter with adjacent positions occupied: 125 mm Max. tool diameter without adjacent positions: 200 mm Tool change time: approx. 8.5 s Chip-to-chip time: approx. 9.5 s CNC Control Control: Siemens SINUMERIK 840 D-POWERLINE Rotary Table Type: NC rotary table with direct drive Faceplate diameter: 1,900 mm Max. load capacity horizontal (turning/milling): 5,000 kg Circular run-out accuracy: 0.02 mm Flatness accuracy: 0.015 mm over 1,000 mm Rated speed: 180 rpm at 100% duty cycle Total clamping surface: approx. 4,300 × 1,200 mm (excluding full diameter of NC rotary table) T-slots: 11 × 18H7 MACHINE DETAILS Installation dimensions: 8000 x 6000 x 5000 mm Weight: 45 t Transport width: approx. 3,450 mm Transport length: approx. 6,900 mm Loading height: approx. 4,015 mm EQUIPMENT - Two-axis universal swivel head with stepless adjustment - Direct measuring systems in A/B-axis - NC rotary table with direct drive - Siemens SINUMERIK 840 D-POWERLINE CNC control - 40-station tool magazine - Approx. 90 HSK 100 tool holders - Complete documentation The machine can be transported on trucks up to 3,000 mm wide.

Condition: as good as new (ex-display), Year of construction: 2024, Functionality: fully functional, travel distance X-axis: 1,530 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 465 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 54, TECHNICAL DETAILS Control: Sinumerik One - Spios 24 touch Travel X: 1,530 mm Travel Y: 530 mm Travel Z: 465 mm Spindle and Tool System Number of tools: 54 Milling spindle: High-precision milling spindle, in-line spindle with direct drive, no belt Spindle speed: max. 12,000 rpm Spindle power: 15.2 kW Spindle torque: max. 97 Nm Tool holder: SK40 DIN 69871 Tool changer type: Double gripper Spindle pressure: 22 bar Table System Rotary-tilt table: 2 axes, D = 650 mm Table design: Precision design “T” Fixed table: left in the working area Hydraulic brake: on B and C axes Rotary feed: dual, at the center of the C axis Table load: 500 kg B axis: -5° / 110° Direct measurement system: on B and C axes Direct measurement systems: on X, Y, and Z axes Control Control type: Siemens SINUMERIK ONE Language selection: CNC dialog German, English as second language Touch panel: SPIOS Touch V2 Operation: Multi-Control-Wheel, multifunctional hand-held control unit Software: Machining software: ONE-Dyn. Operate 3A-Fr Programming function: ShopMill step programming Axis machining: 4-axis with rotary axis 3D function: 3D simulation of the finished part Residual material detection: included DXF reader: single license Machining tracking: recording of machining process Kinematic measurement: Cycle 996 Memory upgrade: 2 GB additional user memory Probing functions: for integrating measuring probes MACHINE DETAILS Cooling and Pressure Universal chip conveyor: with coolant tank Gislhcjwu Ebijdwzew High-pressure tank: 22 bar Spindle preparation: for high pressure Blow air: additional blow air at the spindle head Spindle probe preparation: available Robot Integration Robot door: available Interface: UNIROB universal robot interface Electrics Operating voltage: 3×400 V ±10 % Mains frequency: 50 Hz (±2%) Mains system: TN system (5-wire system) Standards: Technical design according to CE EQUIPMENT - Chip conveyor - Blow air at the spindle head - Robot door right - UNIROB universal robot interface - BLUM spindle probe

Condition: refurbished (used), Year of construction: 2018, Functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Z-axis: 550 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, feed length X-axis: 2,000 mm, feed length Y-axis: 600 mm, feed length Z-axis: 550 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 20 m/min, total height: 3,200 mm, total length: 6,350 mm, total width: 3,150 mm, table length: 1,250 mm, rotary table diameter: 600 mm, overall weight: 15,000 kg, spindle motor power: 17,000 W, spindle nose: ISO 40, tool length: 300 mm, tool weight: 7,000 g, Equipment: chip conveyor, Vertical machining center FAGIMA Jazz L5 AX TECHNICAL CHARACTERISTICS : CNC control : HEIDENHAIN iTNC 640 Number of simultaneous axes : 5 Stroke X axis : 2000 [mm] Stroke Y axis : 600 [mm] Stroke Z axis : 550 [mm] Feed rate on X, Y and Z axes : 20000 [mm/min] Traversing feeds X, Y and Z axes : 40000 [mm/min] Axes acceleration : 2.5 [mm/sec²] Min. distance spindle nose / table : 30 [mm] Table length : 1250 [mm] Table width : 800 [mm] Max. load on table : 500 [Kg] Rotary tilting table surface : 600 x 600 [mm] Stroke C axis : table revolution : 360 [°] Max. speed C axis : 25 [rpm] B axis swivelling stroke : -110 / +110 [°] Spindle type : ISO 40 Max. spindle speed : 15000 [rpm] Spindle power : 17 [kW] Tool changer magazin number of stations : 80 Max. tool length : 300 [mm] Max. weight of single tool : 7 [Kg] Total max. weight in tool changer magazin : 400 [Kg] Total power required : 57 [kVA] Supply voltage : 400 [V] Number of hours under power : 17840 [h] Weight : 15000 [Kg] EQUIPMENT INCLUDED : Gelhcdwowu D A Sszsiw - HEIDENHAIN glass scales on all 3 axes - Coolant through spindle (20 bars) - Chip conveyor - Blowing inside + outside spindle - Collision monitoring - Simultaneous 5-axis software - Electrical cabinet chiller - HEIDENHAIN part probe - HEIDENHAIN tool probe Machine visible under power in our premises by appointment. Price on request, loading on truck included. Worldwide shipping is possible. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. The FAGIMA Jazz L 5 AX is a 5-axis continuous pendulum machining centre designed to provide optimum precision and flexibility for complex machining operations. Thanks to its 5 continuous axes, it can machine complex parts in a single configuration, reducing set-up times and increasing productivity. This machining centre is ideal for the aerospace, medical and automotive sectors, where tight tolerances and machining quality are essential. Comparable to well-known brands such as Mikron, Hermle, DMG Mori, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas and Alzmetall, the FAGIMA Jazz L 5 AX stands out for its ability to integrate milling, drilling and tapping operations with high precision. In addition to its multi-axis machining capabilities, it integrates perfectly into workshops equipped with CNC grinders, milling machines or machining centres, creating a complete solution for versatile machining operations.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 24,000 h, Functionality: fully functional, travel distance X-axis: 3,600 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, controller model: HEIDENHAIN TNC 530, rotational speed (max.): 8,000 rpm, overall weight: 35,000 kg, spindle speed (max.): 8,000 rpm, 1 x Dmg DMF 360 LINEAR, Year 2004 Golhjwu A Rhscdwzsiw 4 axes Technical Details Travel X-axis: 3,600 mm Travel Y-axis: 920 mm Travel Z-axis: 820 mm CNC controller: Heidenhain iTNC 530 Overall height: 2,900 mm Overall length: 8,300 mm Overall width: 3,400 mm Table width: 900 mm Table length: 3,600 mm Total weight: 35,000 kg Spindle speed (max.): 8,000 rpm B axis in head +- 180° 1° indexing Number of tool magazine positions: 40 SK 50 Description CNC Control: Heidenhain iTNC 530 Axes Travel X-axis mm: 3,600 Travel Y-axis mm: 920 Travel Z-axis mm: 820 Working Table Pallet dimensions mm: 4,200 x 900 Spindle Max. spindle speed rpm: 8,000 Spindle drive power kW: 48 (40% duty cycle) Spindle torque Nm: 294 (40% duty cycle) Tool System Tool holder: SK50 Number of tools in magazine: 40 Features/Equipment Chip conveyor Rotating safety windows Rinsing gun Operating mode 4 Internal coolant supply Vertical spindle Linear drive X-axis Work area partition wall Cooling Coolant supply through spindle: yes Tank capacity liters: 600 High-pressure cooling bar: 40 Machine hours: Powered hours: 800,171 Spindle running hours: 26,114 Base Machine: Dimensions/Weight Length mm: 8,300 Width mm: 3,400 Height mm: 2,900 Weight kg: 35,000
