Condition: used, Year of construction: 1992, CNC Milling Center Mori Seiki Cede Ahyz Espfx Agrshd Type/Model: MH-40 Condition: Used Year of Manufacture: 1992 Control: Fanuc Technical Data Travel range X-/Y-/Z-axis: 560 x 500 x 510 mm Spindle axis to table distance: 50 - 550 mm Spindle nose to table distance: 100 - 610 mm Table size: 400 x 400 mm Max. table load: 400 kg Max. workpiece diameter: 610 mm Table type: M16 thread 24, pitch 80 Spindle speed: 7000 rpm Taper bore: 7/24 taper No. 40 Diameter of front bearing: 80 mm Rapid traverse speed: 20000 mm/min Cutting feed rate: 0.1 - 5000 mm/min Tool holder: BT 40 / CAT 40 Number of tools: 60 Max. tool diameter: approx. 100 mm with adjacent positions occupied Max. tool diameter: approx. 150 mm with adjacent positions free Number of pallets: 2 Pallet changing system: rotating design Spindle motor: 11 kW Feed motor X-/Y-/Z-axis: 1.8 / 3.5 / 3.5 kW Power connection: 40 kVA Footprint: approx. 1850 x 3710 mm Machine height: approx. 2550 mm Weight: approx. 10,000 kg Equipment: Internal coolant supply, 70 bar Inquiry item: Transportation costs will be provided in a separate offer.

Condition: used, Year of construction: 2000, Technical details: x-travel: 560 mm y-travel: 560 mm z-travel: 600 mm Chedpfx Ae Ahmtrogrsd control: Fanuc 16 iMA rapid travel x/y/z: 84 / 84 / 94 m/min feeds x/y/z -stepless: 50000 mm/min spindle drive: 22 kW spindle speed:: 50 - 14000 1/min max. torque on the spindle: 156 Nm size of pallet: 400x400 mm numbers of pallets: 2 table load: 500 kg working diameter: 630 mm workpiece - installed height: 1000 mm change time of pallets: 10 sec distance spindle center to table: 80 -640 mm Distance spindle nose - pallet centre: 70-670 mm tool magazin:: 60 x HSK-A 63 tool changing time: 1 (4) sec max. tool weight: 8 kg max. tool diameter: 70 / 170 mm tool length - max.: 360 mm total power requirement: 64 kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 15 m² Accerories Tool life management Macro B 600 Variables Chip conveyor scraper type Coolant through Spindle 50 bar Knoll VRF unit This well maintained horizontal machining center has a full 4th axis, twin pallet changer, 60 tools magazine for HSK-A 63 toolholders and coolant through spindle 50 bar. An external hydraulic pressure control system for fixtures is provided. There also are 3 more Makino A 55 available from YOM 2004, stock No. 300455, one of them is non functional and can be used for spare parts. *

Condition: good (used), Year of construction: 1998, functionality: fully functional, CNC Machining Center, Horizontal Chjdpfx Age Agwm Nsred Manufacturer: MORI SEIKI Machine Model: SH400 Control: MSC 518 (FANUC) Year of Manufacture: 1998 TECHNICAL DATA Travel Ranges - X-axis: (mm) 560 - Y-axis: (mm) 510 - Z-axis: (mm) 510 Rapid Traverse Rates - Rapid traverse in X (mm/min) 40,000 - Rapid traverse in Y (mm/min) 40,000 - Rapid traverse in Z (mm/min) 40,000 Main Spindle - Speed range RPM: 12,000 Tool Magazine - Tool holder: MAS BT 40 - Number of tool positions: 60 - Maximum tool length (mm) 350 Pallet System - Pallet size (L x W) (mm) 400 x 400 - Number of pallets: 2 EQUIPMENT FEATURES + Chip conveyor + 3D measuring probe Renishaw + Tool length measuring device Blum + Tool breakage detection Blum Dimensions and Weight - Machine weight approx.: 9,000 kg Subject to changes and errors in the technical data and specifications.

Condition: good (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 660 mm, spindle speed (max.): 12,000 rpm, Equipment: chip conveyor, MORI SEIKI NHX 4000 CNC Horizontal Machining Center with Pallet Changer General Machine Data Manufacturer: MORI SEIKI Model: NHX 4000 Year of Construction: 2012 Control System: Siemens Sinumerik 840D solutionline with SLIMline operator panel Machine Type: CNC Horizontal Machining Center Number of Axes: 4 (X, Y, Z, B) Chodpfx As Agn Tlsgred Travel and Feed Rates X-axis: 560 mm Y-axis: 560 mm Z-axis: 660 mm B-axis: 360° NC rotary table Rapid Traverse X/Y/Z: 60 m/min Maximum Feed Rate: 60,000 mm/min Main Spindle Maximum Spindle Speed: 12,000 rpm Tool Interface: HSK-A63 Spindle Power: Dependent on the installed spindle version Internal Coolant Supply (ICS) through the Spindle Tool Changer Automatic Tool Changer Tool Interface: HSK-A63 Tool Magazine: 40 positions Maximum Tool Diameter: approx. 70 mm Maximum Tool Diameter with Free Adjacent Positions: approx. 170 mm Maximum Tool Length: approx. 450 mm Maximum Tool Weight: approx. 8 kg Work Table and Pallet Changer Automatic 2-position Pallet Changer Pallet Size: 400 × 400 mm Maximum Pallet Load: approx. 400 kg Maximum Workpiece Diameter: approx. 630 mm Maximum Workpiece Height: approx. 880 mm B-axis: 360° Equipment Siemens Sinumerik 840D solutionline SLIMline operator panel HSK-A63 main spindle with 12,000 rpm Automatic Tool Changer Automatic 2-position Pallet Changer NC rotary table / B-axis Internal Coolant Supply (ICS) Chip Conveyor Coolant System Machine Dimensions and Weight Length: approx. 4,214 mm Width: approx. 2,720 mm Height: approx. 2,512 mm Machine Weight: approx. 8,000 kg The machine has been regularly maintained. All hydraulic and air hoses have been replaced. Spindle hours: 39,000

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, CNC Horizontal Machining Center with Pallet Changer DECKEL MAHO DMC 55 H duoBLOCK Year of manufacture: 2008 Control system: Siemens Sinumerik 840D Machine type: CNC Horizontal Machining Center Number of axes: 4 (X, Y, Z, B) Spindle hours: approx. 44,000 hours Travel distances X-axis: 560 mm Y-axis: 600 mm Z-axis: 600 mm B-axis: 360° NC rotary table Rapid traverse rate X/Y/Z: 40 m/min Positioning accuracy according to the manufacturer: ± 0.003 mm Repeatability according to the manufacturer: ± 0.001 mm Main spindle Spindle speed: 12,000 rpm Tool interface: HSK-A63 Spindle power: 20 kW (40% duty cycle, standard version according to the manufacturer) Spindle torque: 110 Nm (standard version according to the manufacturer) Tool changer Tool magazine: 40 tool positions Tool interface: HSK-A63 Maximum tool diameter: 80 mm Maximum tool diameter with free adjacent positions: 160 mm Maximum tool length: 330 mm Automatic tool change Work table and pallet changer Automatic 2-position pallet changer Pallet dimensions: 400 × 400 mm Maximum pallet load: 500 kg Maximum workpiece height: 850 mm NC rotary table with 360° B-axis Equipment Siemens Sinumerik 840D CNC control system HSK-A63 main spindle with 12,000 rpm 40-position tool magazine Automatic 2-position pallet changer NC rotary table / B-axis Internal cooling system (IKZ) Chip conveyor Measuring probe Coolant system Electrical connection data Mains connection: 400 V / 50 Hz Connected power: approx. 58 kVA Maximum circuit breaker rating: approx. 100 A Dimensions and weight Length: approx. 5,000 mm Width: approx. 3,000 mm Height: approx. 2,800 mm Cjdpfxo Agn Sco Agrshd Machine weight: approx. 11,000–13,000 kg The machine has been regularly maintained. All hydraulic and air hoses have been replaced. Emergency stop switch on the control panel is defective. Clamping devices and tool holders are not included.

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, CNC horizontal machining center with pallet changer DECKEL MAHO DMC 55 H duoBLOCK Year of manufacture: 2008 Control system: Siemens Sinumerik 840D Machine type: CNC horizontal machining center Number of axes: 4 (X, Y, Z, B) Spindle hours: approx. 46,000 h Travel distances X-axis: 560 mm Y-axis: 600 mm Z-axis: 600 mm B-axis: 360° NC rotary table Rapid traverse X/Y/Z: 40 m/min Positioning accuracy according to manufacturer: ± 0.003 mm Repeatability accuracy according to manufacturer: ± 0.001 mm Main spindle Spindle speed: 12,000 rpm Tool holder: HSK-A63 Spindle power: 20 kW (40% duty cycle, standard version according to manufacturer) Spindle torque: 110 Nm (standard version according to manufacturer) Tool changer Tool magazine: 40 tool positions Tool holder: HSK-A63 Maximum tool diameter: 80 mm Maximum tool diameter with free adjacent positions: 160 mm Maximum tool length: 330 mm Automatic tool change Work table and pallet changer Automatic 2-position pallet changer Pallet dimensions: 400 × 400 mm Maximum pallet load: 500 kg Maximum workpiece height: 850 mm NC rotary table with 360° B-axis Equipment Siemens Sinumerik 840D CNC control system HSK-A63 main spindle with 12,000 rpm 40-position tool magazine Automatic 2-position pallet changer NC rotary table / B-axis Internal cooling (IKZ) Chip conveyor Measuring probe Coolant system Electrical connection data Mains connection: 400 V / 50 Hz Connected power: approx. 58 kVA Maximum fuse rating: approx. 100 A Dimensions and weight Length: approx. 5,000 mm Chodpfx Ags Agn H Uerod Width: approx. 3,000 mm Height: approx. 2,800 mm Machine weight: approx. 11,000–13,000 kg The machine has been regularly maintained. All hydraulic and air hoses have been replaced. Emergency stop switch on the control panel is defective. Clamping devices and tool holders are not included.

Condition: used, Year of construction: 2011, x-travel 730 mm y-travel 730 mm z-travel 850 mm control MSX 701 IV MAPPS 4 max. spindle speed 14.000 min/-1 Cjds Af Naijpfx Agrshd power capacity - milling spindle 22 / 18,5 kW tool taper HSK A-63 distance ground floor - table top edge 1.200 mm distance Spindlenose and center of table 100 - 950 mm numbers of pallets 2 size of pallet 500 x 500 mm max. workpiece weight 500 kg max. workpiecediameter 800 mm max. workpiece height 1.000 mm change time of pallets 7 sec Indexing-time 1,57 sec B-axis (table) 0,001 ° number of toolpositions 120 pos. tool taper HSK A-63 max. tool diameter 70 mm max. tool-dia with free toolbox 140 mm max. tool length 500 mm max. tool weight 12 kg rapid traverse 50 m/min feed speeds max. 50.000 mm/min Tipp feed 0 - 1.260 mm/min total power requirement 51 kW weight of the machine ca. 12 t dimensions of the machine ca. 5,5 x 3,0 x 2,8 m CNC - MachiningCenter Horizontal MORI SEIKI - NH 5000 / 40 DCG - 2 pos. palletchanger - 2x mounting towers - Processing time: approx. 14,200 hours

Condition: used, Year of construction: 2004, Technical details: Codpfxj Afyu Tj Agrshd x-travel: 560 mm y-travel: 560 mm z-travel: 600 mm control: Fanuc 16 iMA rapid travel x/y/z: 84 / 84 / 94 m/min feeds x/y/z -stepless: 50000 mm/min spindle drive: 22 kW spindle speed:: 50 - 14000 1/min max. torque on the spindle: 156 Nm size of pallet: 400x400 mm numbers of pallets: 2 table load: 500 kg working diameter: 630 mm workpiece - installed height: 1000 mm change time of pallets: 10 sec distance spindle center to table: 80 -640 mm Distance spindle nose - pallet centre: 70-670 mm tool magazin:: 60 x HSK-A 63 tool changing time: 1 (4) sec max. tool weight: 8 kg max. tool diameter: 70 / 170 mm tool length - max.: 360 mm total power requirement: 64 kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 15 m² Accerories Tool life management Macro B 600 Variables Chip conveyor scraper type Coolant through Spindle 50 bar Knoll VRF unit This well maintained horizontal machining center has a full 4th axis, twin pallet changer, 60 tools magazine for HSK-A 63 toolholders and coolant through spindle 50 bar. An external hydraulic pressure control system for fixtures is provided. There are a total of 4 machines available, 3 machines YOM 2004, thereof one machine is non-functional and can be used for spareparts, and one machine YOM 2000 (our stock-No. 300457) *

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, Horizontal Machine Center DMG MORI Cedpfx As Ad Ucijgrehd NH 5000DCG/40 Year 2010 Tavel X 730 Y 730 Z850mm Fully C axis 0.001 degree MAPPS FAUNC Spindle 14,000rpm 37/22KW 303Nm HSK-A63 Taper 60 ATC Pallet 500 x 500mm

Condition: good (used), Year of construction: 2016, operating hours: 36,629 h, functionality: fully functional, machine/vehicle number: 196091, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 625 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed length X-axis: 560 mm, feed length Y-axis: 560 mm, feed length Z-axis: 625 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, nominal power (apparent): 42 kVA, controller manufacturer: Okuma, controller model: OSP-P300M, workpiece weight (max.): 400 kg, total height: 2,650 mm, total length: 4,700 mm, total width: 2,420 mm, table width: 400 mm, table length: 400 mm, table load: 400 kg, rotary table diameter: 400 mm, rotational speed (max.): 15,000 rpm, overall weight: 9,500 kg, spindle speed (max.): 15,000 rpm, operating hours of spindle: 22,704 h, coolant supply: 50 bar, spindle motor power: 26,000 W, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 60, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, We offer a used Okuma MB-4000H, a 4-axis CNC horizontal machining center, manufactured in 2016 (produced in June 2016), in good condition. Manufacturer: Okuma Model: MB-4000H Serial number: 196091 Chedpfxs Ad Rcls Agred Year of manufacture: 2016 Condition: used, good condition Key specifications: - CNC control: Okuma OSP-P300M - X/Y/Z travels: 560 / 560 / 625 mm - 2 pallets, 400 x 400 mm, with automatic pallet changer - Maximum pallet load: 400 kg - B-axis: NC table with 0.001° indexing - Spindle: BT40, 15,000 rpm, power 26 / 18.5 kW (30 min / continuous) - Rapid traverse rates X/Y/Z: 60 m/min - Automatic tool changer with 60 positions - Coolant through spindle with high-pressure pump - Tool wear/breakage monitoring probe - Power supply: 400 V - 3-phase - 50 Hz, 42 kVA - Approximate weight: 9,500 kg; approximate footprint: 2,420 x 4,700 x 2,650 mm Machine hours recorded (09/29/2026): - CNC on: 45,737 h - Operating: 36,629 h - Cutting time: 17,380 h - Spindle active: 22,704 h Accessories, tools, and tool holders: to be agreed upon. Complete technical data sheet with photos available upon request. Available for viewing by appointment. If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: used, Year of construction: 1999, Technical details: x-travel: 560 mm y-travel: 510 mm z-travel: 510 mm control: Fanuc 18i M power capacity - milling spindle: 22 / 18,5 kW spindle turning speed - stepless: 12.000 1/min numbers of tools in magazin: 60 BT 40 size of pallet: 2x 400 x 400 mm max. workpiece diameter on pallets: 580 mm Chedpfx Agj Adth Rorod workpiece height max.: 650 mm feeds x/y/z -stepless: 16.000 mm/min rapid travel x/y/z: 32.000 mm/min total power requirement: 54 kVA weight of the machine ca.: 8,7 t dimensions of the machine ca.: 2,9 x 3,9 x 2,6 m Accerories Chip conveyor Coolant through Spindle 50 bar Knoll VRF unit Horizontal twin - pallet machining center with full 4th axis, 60-tool magazine BT 40 and 50 bar coolant through spindle. *

Condition: used, Year of construction: 2001, Technical details: x-travel: 560 mm y-travel: 510 mm z-travel: 510 mm control: Fanuc 18i GOP 3 spindle speeds: 12000 1/min spindle drive: 22 kW rapid travel x/y/z: 42 mm/min Number of tool station: 40 BT 40 Pallet dimension: 2x 400x400 mm table load: 0,5 t working diameter: max. 580 mm Chjdps Adtcnsfx Agrod total power requirement: 56 kVA weight of the machine ca.: 8,7 t dimensions of the machine ca.: 2,9x4,1 m Accerories Chip conveyor Coolant Gun Coolant shower Memory 125 Memory 320 m No. of tool offset pairs 64 offsets for parts 6 Macro B 82 var. Interface for coolant through the spindle spindle load monitor Program restart Coolant through Spindle 50 bar Knoll VRF unit Control Fanuc 18i M, 40 tool stations, trough spindle coolant Knoll 50 bar, 4th axis, Chipconveyor, twin pallet-changer tool magazine 40 BT 40 *

Condition: like new (used), Year of construction: 2018, operating hours: 240 h, functionality: fully functional, travel distance X-axis: 460 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 410 mm, feed rate X-axis: 48,000 m/min, feed rate Y-axis: 48,000 m/min, feed rate Z-axis: 48,000 m/min, controller manufacturer: siemens 828D, controller model: 828D, total height: 2,602 mm, total length: 3,350 mm, total width: 2,265 mm, table width: 320 mm, table length: 320 mm, table load: 250 kg, rotational speed (max.): 200 rpm, overall weight: 6,200 kg, spindle speed (max.): 18,000 rpm, coolant supply: 20 bar, distance table center to spindle nose: 60 mm, spindle motor power: 23 W, spindle nose: hsk63, number of spindles: 1, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, Due to the cessation of business operations, we are offering this like-new Hardinge H320 horizontal machining center, manufactured in 2018. Model: H320 Serial number: GHLB7G0001 Date of manufacture: 05/31/2018 Supply voltage: 400 V Number of phases: 3 Weight: 6200 kg Cooling on the ball screw spindles Spindle cooled Glass scales on all axes High-speed 4th axis with direct drive motor, 200 rpm Scraper chip conveyor It is also possible to take over the tool holders and machine clamps. Chedpfs Aazdxjx Agred If you have any questions or would like more information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 2080403, CNC Horizontal 5-Axis Double-Spindle Machining Center Manufacturer: SW – Schwäbische Werkzeugmaschinen GmbH Type: BAW06-22 Year of Manufacture: 2017 Machine Number: 2080403 Control System: CNC Siemens 840 Number of Axes: 5 Number of Spindles: 2 Double Table System Travel Ranges X/Y/Z: 600 / 600 / 510 mm Spindle Speed: up to 17,500 rpm Rapid Traverse: up to 45 m/min Tool Interface: HSK-A63 Machine Weight: approx. 16,000 kg Equipment: Standard accessories Powerful CNC horizontal machining center with a double spindle and double table system for precise and efficient series production. Cjds Aarqpepfx Agrshd Location: Maribor, Slovenia Availability: By arrangement Inspection possible by appointment.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 2080100, CNC Horizontal 5-Axis Twin-Spindle Machining Center Manufacturer: SW – Schwäbische Werkzeugmaschinen GmbH Cjdpfj Aarpxox Agrohd Type: BAW06-22 Year of Manufacture: 2011 Machine Number: 2080100 Control System: CNC Siemens 840SL Number of Axes: 5 Number of Spindles: 2 Dual Table System Travel in X/Y/Z: 600 / 600 / 510 mm Spindle Speed: up to 17,500 rpm Rapid Traverse: up to 45 m/min Tool Interface: HSK-A63 Machine Weight: approx. 16,000 kg Equipment: Standard accessories High-performance CNC horizontal machining center with twin spindle and dual table system for precise and cost-effective series production. Location: Maribor, Slovenia Availability: Immediately available Inspection possible by arrangement.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 2080082, Used CNC horizontal machining center, 5-axis, with dual spindle and dual table Technical data – SW BAW06-22 Manufacturer: SW – Schwäbische Werkzeugmaschinen GmbH Model: BAW06-22 Year of manufacture: 2010 Machine number: 2080082 Control system: CNC Design: Horizontal Number of axes: 5 Number of spindles: 2 Chjdpfx Ago Aarpfored Number of work tables: 2 Travel in X-axis: 600 mm Travel in Y-axis: 600 mm Travel in Z-axis: 510 mm Maximum spindle speed: 17,500 rpm Rapid traverse rate: up to 45 m/min Tool holder: HSK-A63 Machine weight: approx. 16,000 kg Accessories: Standard accessories Availability: Available immediately Machine description Used CNC horizontal machining center SW BAW06-22 with 5-axis machining, two work spindles, and a dual table system. The dual-spindle design allows two workpieces to be machined in parallel. The high spindle speed of up to 17,500 rpm enables productive and precise machining. Additional manufacturer data According to the technical data sheet from SW, the following values are specified for the BA W06-22 series: Spindle distance: 600 mm Spindle power: 2 × 35 kW Spindle torque: 2 × 80 Nm Tool magazine: 2 × 42 positions, optional larger Maximum tool length: 425 mm Maximum tool weight: 10 kg Control system according to manufacturer: Siemens SINUMERIK 840D sl Operating voltage: 400 V / 50 Hz

Condition: used, Year of construction: 2001, functionality: unexamined, machine/vehicle number: 81147, Origin: JP Dimensions: 290x180x220 cm Net machine weight: 4500 kg TECHNICAL SPECIFICATIONS Axis travels X-axis: 305 mm Y-axis: 305 mm Z-axis: 330 mm B-axis: continuous rotation 360°, indexing 0.001° Table and pallets Pallet dimensions: 254 × 254 mm Number of pallets: 2 Maximum load per pallet: up to 250 kg Spindle Spindle taper: BT40 / NST40 Maximum speed: 15,000 rpm Cedpfx Aoz U Uy Regrohd Spindle power: approximately 7.5 to 12 kW Tool changer Magazine capacity: 40 tools Tool change time: approximately 1.7 seconds Chip-to-chip time: approximately 6.5 seconds Feed rates Rapid traverse X/Y/Z: up to 24 m/min Numerical control CNC YASNAC i80Mi or YASNAC 180Mi depending on configuration Dimensions and weight Main equipment Automatic pallet changer (APC) Integrated 4th axis 40-tool magazine Coolant system RS232 communication interface (depending on configuration) Subject to error or omission, the technical information is provided without guarantee.

Condition: ready for operation (used), Year of construction: 1997, operating hours: 19,000 h, travel distance X-axis: 500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 480 mm, controller manufacturer: MATSUURA, controller model: G-Tech 18i, spindle speed (max.): 15,000 rpm, number of slots in tool magazine: 80, number of axes: 3, This 3-axis Matsuura H.PLUS-300 was manufactured in 1997. It features a maximum spindle speed of 15,000 rpm and impressive travels of 500 mm in both the X and Y axes, with a Z-axis travel of 480 mm. The machine is equipped with an automatic tool changer that holds 80 tools and includes coolant in the spindle. If you are looking to get high-quality machining capabilities, consider the Matsuura H.PLUS-300 horizontal machining centre. Contact us for further details. Chodpfxsz Tzrws Agred • Through-spindle coolant • Tool setter Technical Specification Taper Size ISO 40

Condition: used, Year of construction: 2006, operating hours: 6,526 h, functionality: fully functional, machine/vehicle number: SN0575, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, nominal power (apparent): 40 kVA, controller manufacturer: Fanuc, controller model: 16i, total height: 2,800 mm, total length: 4,800 mm, total width: 2,800 mm, table width: 400 mm, table length: 400 mm, overall weight: 10,500 kg, spindle speed (max.): 8,000 rpm, operating hours of spindle: 6,526 h, spindle motor power: 18,500 W, spindle nose: BT 40, number of spindles: 1, number of slots in tool magazine: 210, Equipment: chip conveyor, documentation/manual, MITSUI SEIKI precision machining center with very few spindle hours, as it was only put into operation in 2017. Cjdpfx Asz R Rcbsgrehd Matrix magazine with 201 positions. High-pressure coolant system KNOLL 200/1400. Scraper conveyor chip removal system Knoll 450K-1/290. Fanuc 16iMA. Can be inspected while powered on.

Condition: used, Year of construction: 2013, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, controller model: Siemens, workpiece weight (max.): 100 kg, total height: 3,030 mm, total length: 5,400 mm, total width: 6,265 mm, overall weight: 24,000 kg, spindle speed (max.): 7,500 rpm, spindle motor power: 32,000 W, number of spindles: 2, number of slots in tool magazine: 100, Equipment: CE marking, chip conveyor, documentation/manual, type plate available, SAMAG MFZ 4-2W CNC twin-spindle machining center For sale: SAMAG MFZ 4-2W CNC machining center, currently in working order and available for inspection at our facility. The machine is ideal for high-productivity machining thanks to its twin-spindle configuration and has been maintained in good working condition. >Included in the supply: Cjdpfx Agez Nlzzerehd Spare electro-spindles Spare B-axis motors Spare W-axis motors Spare A1/A2 motors Machine documentation available (mechanical and electrical) >Main features: CNC twin-spindle machining center Year of manufacture: 2014 Machine in working order Inspection and testing possible on-site by appointment The inclusion of spare parts represents a significant added value, allowing for reduced time and costs for any future maintenance work. The system includes a chip extraction system for cast iron components from Knoll, complete with a filter mat for managing the emulsion for coated parts. Spindle mount: HSK-80 The 3D (step) model of the machine is also available for use with simulators. IMPORTANT: The machine will be sold without tooling, as it is specific to the components being produced! For further information, photographs, videos of the machine in operation, or to arrange a visit, please contact the seller directly.

Condition: excellent (used), Year of construction: 1990, operating hours: 18,960 h, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 510 mm, feed rate X-axis: 8,000 m/min, feed rate Y-axis: 8,000 m/min, feed rate Z-axis: 8,000 m/min, controller manufacturer: Mitsubishi CNC Co., total height: 2,206 mm, total length: 2,490 mm, total width: 3,220 mm, table width: 400 mm, table length: 400 mm, table load: 400 kg, overall weight: 7,200 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 7,000 rpm, spindle motor power: 5,500 W, spindle mount: MK 4, number of spindles: 1, additional equipment features: + same Extra Machine for spare parts!, Equipment: chip conveyor, documentation/manual, We offer this very good Mazak H400 horizontal machining center, year of construction 1990. Manufacturer: MAZAK Model: H400 NC number: M335M038240 Manufacture date: April 1990 Serial number: A81117 Chsdpfjz E I Twox Agred EXTRA NOTES: - The price includes AN EXTRA Machine as the one provided for SPARE PARTS! (attached pictures) - The offer includes many Tool Holders, Coillets, two fixturing Hubs! If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 2080092, Used CNC horizontal 5-axis twin-spindle double-table machining center Manufacturer: SW – Schwäbische Werkzeugmaschinen GmbH Type: BAW06-22 Year of manufacture: 2011 Machine No.: 2080092 Weight: approx. 16,000 kg Technical data: - CNC horizontal machining center - 5-axis design - Twin spindle - Double table - Travel ranges: - X-axis: 600 mm - Y-axis: 600 mm - Z-axis: 510 mm - Rapid traverse: up to 45 m/min - Tool interface: HSK-A63 - Spindle speed: up to 17,500 rpm Equipment: Cedpfx Aoz E Ddfogrohd Machine with standard accessories. Availability: Available in the short term.

Condition: used, Year of construction: 2015, functionality: fully functional, total height: 3,500 mm, total length: 5,900 mm, total width: 4,000 mm, SW Swabian Machine Tools BA W08-22 CNC control system: Siemens SINUMERIK 840 D sl Work area X-axis: 800 mm Y-axis (swiveling): 900 mm (1,200 mm) Z-axis: 660 mm Spindle distance, fixed (variable)*: 800 mm (799 mm - 851 mm) Workpiece clamping Swiveling table/counter bearing with Cjdjz D Ey Ejpfx Agrshd helical gearing: swiveling time 0/180°: approx. 5.0 s A- and U-axes, prepared for mounting of clamping bridges, up to max.: Ø 950 mm x 1,830 mm Drive system: Torque motor Transport load: 2 x 800 kg Speed range A-, U-axes: 1 - 40 min-1 Working spindle HSK-A80 Speed range: 1 - 12,500 min-1 Acceleration time 0 - nmax: < 0.9 s Spindle bearing diameter: 90 mm Power / torque (10% duty cycle): 2 x 42 kW / 2 x 200 Nm (10% duty cycle) Feed drive Drive system: Linear motor Rapid traverse X / Y / Z: 120 m/min Axis acceleration X / Y / Z: 11 / 11 / 22 m/s2 Max. feed force X / Y / Z: 2 x 8,000 / 16,000 / 2 x 8,000 N Accuracy Position measurement: Direct, absolute Position tolerance X / Y / Z: Tp = ≤ 0.006 mm Repeatability R (ISO 230-2) ≤ 0.004 mm Tool magazine Tool changing system: Pick-Up Capacity: 2 x 42 (2 x 70 / 2 x 91 / 2 x 126)* Max. tool Ø: 85 / 200 mm (-o-) Max. tool length: 550 mm Max. tool weight: 12 / 18 kg Tool change chip-to-chip time: approx. 3.00 s Weight / Dimensions Machine weight: approx. 24,000 kg Transport dimensions W x H x D: 4.00 m x 3.5 m x 5.70 m Installation dimensions W x H x D: 5.35 m x 4.20 m x 8.20 m Connection power Operating voltage: 3 x 400 Volt, 50 Hz, TN-S/TN-C network Total connection power: approx. 152 kVA Average air consumption: 0.6 Nm³/min (5.5 bar) Several machines are available. The machines were integrated into an automated system. They were loaded by a robot system. They were connected to a central coolant system. Therefore, these machines do not have their own coolant system. Chips were also removed via a central disposal system.

Condition: used, OKK HM 4 is a horizontal machining center designed for precision, high accuracy and reliability. Working capacity: table 400×400 mm, travels X 560, Y 510, Z 560 mm; workpiece up to 620×620×700 mm, table load 400 kg. Key specs: spindle ISO 40 100–12,000 rpm (stepless), max torque 150 Nm, feed 1–40 m/min, rapid 40 m/min, spindle nose‑to‑table 150–710 mm; machine size L2100×W3995×H2884 mm. Equipment: 60‑station tool magazine, tool Ø 82 mm (140 with free adjacent pockets), length 300 mm, max tool weight 8 kg, tool change 1 s, chip‑to‑chip 3.4 s, automatic pallet changer (2), pallets 8, coolant 400 L with 20 bar through‑spindle, status light. Delivers tight tolerances; ideal for automotive, aerospace, medical, watchmaking and machine tool sectors. Chedpfx Agez Dv Akersd

Condition: used, Year of construction: 2014, functionality: fully functional, total height: 3,250 mm, total length: 5,200 mm, total width: 3,700 mm, overall weight: 20,000 kg, SW Swabian Machine Tools BA W06-22 CNC control: Siemens SINUMERIK 840 D sl Working area X-axis: 600 mm Y-axis (swiveling): 630 mm (920 mm) Z-axis: 510 mm Spindle distance, fixed (variable)*: 600 mm (590 mm - 651 mm) Workpiece clamping Swiveling table/counter bearing with helical toothing: swiveling time 0/180°: approx. 3.4 s A and U axes, prepared for mounting Chedpozz Sdnefx Agred of clamping bridges, up to max.: Ø 675 mm x 1,430 mm Drive system: Torque motor Transport load: 2 x 600 kg (720 kg)* Speed range A, U axes: 1 - 50 min-1 Working spindle HSK-A63 Speed range: 1 - 17,500 min-1 Acceleration time 0 - nmax: < 0.65 s Spindle bearing Ø: 80 mm Power / Torque (40% ED): 2 x 35 kW / 80 Nm (40% ED) Feed drive Drive system: Linear motor Rapid traverse X / Y / Z: 120 m/min Axis acceleration X / Y / Z: 12 / 10 / 24 m/s2 Max. feed force X / Y / Z: 10,000 / 10,000 / 2 x 5,000 N Accuracy Path measurement: Direct, absolute Position tolerance X / Y / Z: Tp = 0.006 mm Tool magazine Tool changing system: Pick-up Capacity: 2 x 42 (2 x 72 / 2 x 108)* Max. tool Ø: 80 / 200 mm (-o-) Max. tool length: 425 mm Max. tool weight: 10 kg Tool change time, chip-to-chip: approx. 2.25 s Weight / Dimensions Machine weight: approx. 20,000 kg Transport dimensions W x H x D: 3.70 m x 3.25 m x 5.20 m Installation dimensions W x H x D: 4.80 m x 3.50 m x 7.50 m Connection power Operating voltage: 3 x 400 Volt, 50 Hz, TN-S/TN-C network Total connection power: approx. 133 kVA Average air consumption: 0.6 Nm³/min (5.5 bar) Several machines are available. The machines were integrated into an automation system. They were loaded by a robotic system. They were connected to a central coolant system. Therefore, these machines do not have their own coolant system. Chips were also removed via a central disposal system.
