Condition: good (used), Maximum height: 630 mm Gjdpfxjv N Hk As Afreuh Diameter of clamping disks: 1000 mm Pitch: 1° Arbor diameter: 100 mm Dimensions L x W x H: 1100 x 750 x 1170 mm Weight: approx. 2000 kg Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: used, 4 INGERSOLL adjustable chuck jaws for face plate Chuck jaws for lathe chuck, mechanical clamping device, clamping block No: 39.02.10000 / 501.397 Jaw width 70 mm Jaw length 180 mm Jaw carrier height 150 mm Base plate 325 x 265 mm - Stepped jaws for turning as turning and drilling jaws - Jaw adjustment via trapezoidal threaded spindle Guodpfou Axzksx Afrsh - Jaw carrier with 6 recesses 40 x 30 mm for fastening - Distance between recesses 280 x 133 and 220 x 90 mm (centered) Dimensions L x W x H 325 x 265 x 215 mm Weight per jaw 36.5 kg Weight of all 4 jaws 146 kg Good condition

Condition: excellent (used), Reversing clamp Manufacturer: Rückle Type: PKTW 2 Dimension: 5 x 1 x 1,5 meter Forkardt power chuck type FNC 315-65 Bore 65 mm Godpfx Aoin Ef Rsfreuh Outer diameter 315 mm Further: Profile rail guide RUE 45 4 centering and clamping units Integrated chip guide

Condition: good (used), Year of construction: 1983, Reversible clamping device, 4th axis, rotary table, rotary indexing table, controlled rotary table, dividing head, dividing head, rotary indexing table -Model: AWH 355 -can be opened on one side -without hydraulic unit Gsdpfx Asb A Nn Tsfrsuh -with hydraulic valves -without control -controlled via cam switches -supported by clamping brackets for heavy machining -Clamping surface: Ø 350 mm -Peak height: 350 mm -braked: hydraulically -driven: hydraulically -Hydraulic motor speed: 10-1500 rpm -Swallowing volume: 20 cm³/rev -Dimensions: 680/360/H620 mm -Empty weight: 290 kg
