Condition: excellent (used), Packo PHP 2 Pharmaceutical Process Pump The Packo EHEDG and 3A-certified PHP2 series pharmaceutical process pumps are used for the most demanding sterile applications in the pharmaceutical, biotechnology, and semiconductor industries. These perfectly cleanable pumps feature pump housings made of thick, cold-rolled 316L stainless steel, which are 100% non-porous and extremely smooth. The pumps feature fully machined, open impellers made of 1.4435 material. Thanks to their gap-free design and final electropolishing, the PHP2 series pumps are perfectly cleanable, making them a reliable component in your production process. Areas of Application These perfectly cleanable process pumps are the ideal solution for clean water circuits, cleaning applications, etc. Typical fluids include pure water, WFI, CIP, syrups, etc. Your Benefits High pump efficiency leads to lower energy consumption Low NPSH values: reduced risk of cavitation Electropolished: perfectly cleanable Simple design and maintenance: less downtime Standard components Fully certified (roughness value, FDA, USP, 3.1 for wetted parts, certificate of conformity, etc.) Suitable for SIP Robust construction according to ASME BPE guidelines Wetting parts < 0.4 µm Gjdpew Hc Hmofx Afiebu Manufacturer: Packo Type: PHP 2/40-1857752 Flow: 14 m³/h Height: 59 m Weight: 91 kg Find more items - new and used - in our shop! International shipping costs on request!

Condition: used, functionality: unexamined, machine/vehicle number: ML-348, Used Hyco ML-348 Vacuum Diaphragm Pump Model: ML-348-D37-SA Type: p-227/1 | 207/1 | p-173/2 Voltage: 230-400, 50/60 Hz Gbedpfxjw Evhze Afiju Multiple units in stock.

Condition: excellent (used), functionality: fully functional, Year of construction: 2013, power: 4 kW (5.44 HP), 2 pieces magnetically coupled centrifugal pumps made of stainless steel. Last used for pumping caustic soda. Manufacturer: CP Pumpen AG (Switzerland) Type: MKP 20-15-160 Design: Monoblock with base plate Delivery rate: 5 m³/h (1.38 liters/second) Delivery head / Pressure: 21.1 meters (2.1 bar) Medium temperature: 35 - 40 °C Impeller Ø153 mm Gjdpfowncv Rsx Afisbu Speed: 2950 rpm Material casing and impeller: 1.4581 Including screws and connector for connection cable Motor: Siemens Type: 1LE10011BA222FA4 Power: 4 kW Voltage: 400 Volt Efficiency: IE2 Dimensions: Length: 590mm Width with temperature sensor: 440mm Width base plate: 330mm Height: 360 mm Weight: 81 kg Suction side: DN 20 Pressure side: DN 15

Year of construction: 2013, operating hours: 50 h, condition: like new (used), functionality: fully functional, machine/vehicle number: Model #2WN137F1-H23Z-BJMVA-21/50T,

Condition: good (used), 12,500 liters per minute at 8 bar per pump with a power of 237 kW. Engine brand FIAT, model 9L15 Gbodpfxov Rwyds Afieu

Condition: excellent (used), Year of construction: 1996, total length: 1,590 mm, total width: 780 mm, total height: 600 mm, power: 15 kW (20.39 HP), rotational speed (max.): 980 rpm, Vacuum pump Becker VTLF 500 Used goods, good condition, see pictures length 159 cm width 78 cm Height 60 cm 15 kW Suction capacity: 500 m³/h Speed 980 rpm Negotiated price: € 700,-- net ex stock Goods are in stock. Transportation and assembly possible on request. Viewing possible at any time by appointment. Further information on request. Constantly over 5000 running meters of pallet racking from numerous manufacturers in stock. (Subject to changes and errors in the technical data, specifications and prices as well as prior sale reserved! See our GTC, all prices excl. VAT ex stock) Godpfx Afstwzvyeijbu

Year of construction: 1997, condition: refurbished (used), 2 pieces volute casing pump in process design 1 piece completely overhauled, new ball bearings for pump and motor. Mechanical seal overhauled by specialist company. All seals new. Flow rate: 6 m³/h Delivery head: 25 m Pump speed: 1440 1/min Shaft seal: double-acting mechanical seal Manufacturer: Burgmann HRZ 13754-00 SIC/SIC/-CAR/SIC-VITON Impeller type: closed two-channel impeller Impeller diameter: 277mm Bearing type: roller bearing Impeller side: 1x NU411 Drive side: 2x 7311 Lubrication type drive end oil Lubricant monitoring Oil level controller Materials: Pump housing: Duplex steel Noridur 1.4593 (9.4460) Wear plate: Duplex steel Noridur 1.4593 (9.4460) Pressure cover: Duplex steel Noridur 1.4593 (9.4460) Shaft: Heat-treated steel C45+N Impeller: Duplex steel Noridur 1.4593 (9.4460) Bearing bracket lantern: Cast iron EN-GJL-250 Shaft sleeve: Duplex steel 1.4462 Nominal size of suction nozzle: DN 80 Discharge connection Nominal diameter: DN 40 Nominal pressure suction PN 10 Nominal pressure pressure PN 10 Coupling manufacturer: Flender Coupling type: Eupex NH with intermediate sleeve Base plate: gray cast iron Motor manufacturer: AEG AM 132 Efficiency class: IE 0 Motor speed: 1476 1/min Frequency: 50 Hz Rated voltage: 400 V Rated motor power: P2 7.50 kW Thermal class: F Motor protection class: IP55 Cosphi: 0.82 Dimensions: Length: 1270 mm Width: 550 mm Height: 570 mm Weight: 300 kg The material 1.4593 Noridur is very well suited for - Chemical and process engineering industry - Sulphuric and phosphoric acid - Salt extraction and processing - Petrochemical industry - Coking plants - Textile and pulp industry - Food and sugar industry - Mining/coal mining and extraction - Flue gas desulphurization plants Gedpfjiuznuox Afisbu - Acidic, chloride-containing washing suspensions - Acidic process water - Waste water treatment/sewage treatment plants - Offshore and marine technology

Year of construction: 2009, condition: refurbished (used), functionality: fully functional, 1 piece liquid ring vacuum pump. Please read the description carefully to the end !!! The pump is not suitable for: Water, food industry and non-corrosive media. For these media, cheaper materials such as 1.4408 or 1.4571 are more suitable. The pump is made of the special material Alloy 59 !!! This alloy is used when the corrosion resistance of conventional chromium-nickel steels is no longer sufficient. Especially when chloride-induced pitting and crevice corrosion and stress corrosion cracking are a problem. Alloy 59 is used for: Environmental engineering, chemical industry (chemical processes with oxidizing and reducing acids, resistance to moist chlorine gas) and waste incineration plants. 2.4605 is mainly used in the chemical industry, the pulp and paper industry and in flue gas desulphurization plants. Excellent resistance to mineral acids such as nitric, phosphoric, sulphuric and hydrochloric acid and in particular to sulphuric/hydrochloric acid mixtures Typical applications are -plant components for organic chemistry processes with chloride-containing media, especially when chloride-based catalysts are used -Multipurpose plants in the chemical industry -Plant components in the fine chemicals and pharmaceutical industries scrubbers, heat exchangers, dampers, fans and agitators for flue gas desulphurization plants (FGD) in fossil-fired power plants and waste incineration plants -SO2 scrubbers for marine diesel engines -components for seawater and concentrated brines -equipment and components for geothermal and sour gas applications -Reactors for acetic acid and acetic anhydride -Reactors for hydrofluoric acid -sulphuric acid coolers -Pipelines in geothermal power plants -Components in flue gas desulphurization plants Manufacturer: Busch Type: LC 0220 A ZZO XX ZZ Volume flow: 195 m³/h Motor power: 7.5 kW Gbodsigqutepfx Afiou Voltage: 400/ 690 Volt Speed: 1440 rpm Vacuum: 33 mbar Material: 2.4605 ( Alloy 59 ) NiCr23Mo16Al All ball bearings new, mechanical seal refurbished by specialist company. Weight: 121 kg Dimensions: Length 960mm, width 370mm, height 370mm Connection: DN 50 ( 2")

Condition: used, Air operated double diaphragm pump DEPA Type DH40-FA-ZRT Air operated diaphragm pump, double pump Serial No.: B1802498 Year of manufacture 09.05.2018 Temperature: max. 130°C Size: 40 Grain size: max. 16 mm Suction height: approx. 2 m Suction height product filled: approx. 9 m Operating pressure: max. 7 bar air connection: 3/8" suction connection: 1 1/2" pressure connection: 1 1/2" - self-priming - aluminum housing Gbjdpfjib D H Usx Afieu - Diaphragm plate made of stainless steel - Diaphragm made of nopped E4® PTFE compound - Balls made of PTFE - Ball seats made of stainless steel Space requirement: L x W x H: 370 x 270 x 450 mm own weight: 15 kg very good condition

Year of construction: 1987, condition: excellent (used), 1 piece chemical standard centrifugal pump with very few operating hours. Pump is suitable for acid condensate and aggressive acids. Also suitable for salt water! Manufacturer: Sulzer Model: ZA 200-4500 Material: Duplex 9.4460 / Noridur 1.4593 Delivery volume: 250m³/h Head: 27 meters at 980 rpm Shaft power: 42 kW Motor power: 75 kW Godpoh S Nz Sofx Afijbu NPSH: 1.6 Speed: 980 rpm Year of construction: 1987 Pump speed of 1480 rpm is also possible! Delivery rate approx. at 1480 rpm (information without guarantee) Delivery rate: 430m³/h Delivery head: 62 meters Shaft power: 88 kW Shut-off valves and piping in stainless steel are also available The material 1.4593 Noridur is very well suited for - Chemical and process engineering industry - Sulphuric and phosphoric acid - Salt extraction and processing - Petrochemical industry Bmg9kmu7ug - Coking plants - Textile and pulp industry - Food and sugar industry - Mining/coal mining and extraction - Flue gas desulphurization plants - Acidic, chloride-containing washing suspensions - Acidic process water - Waste water treatment/sewage treatment plants - Offshore and marine technology

Year of construction: 2015, condition: excellent (used), functionality: fully functional, total height: 480 mm, 2 pieces Horizontal, cross-split volute casing pump in process design, with radial impeller, single-entry, single-stage, Manufacturer: KSB Model: MCPK 40-25-160 Year of manufacture: 2015 Shaft seal: Double-acting Burgmann mechanical seal with sealing water connection and flow meter Impeller diameter: 169 mm Pump speed: 2950 rpm Gbedpfx Afofyn Rpsiou !!! ATTENTION !!! Operating parameters are specified on the type plate. Not the actual flow rate at the best point !!!! I have stored 2 characteristic curves as a photo. Photo 11: Best point Photo 12: Operating parameters from last application Flow rate: 6.9 m³/h Delivery head: 33.0 meters Shaft power: 1.73 kW Efficiency: 35.87 % NPSH: 2.17 Data operating point for last application approx. Flow rate: 2.2 m³/h Delivery head: 37.0 meters Shaft power: 1.27 kW Efficiency: 18.07 % NPSH: 1.99 Materials: Volute casing: Noridur 1.4593 Housing cover: Noridur 1.4593 Shaft: C 45+N Impeller: Noridur 1.4593 Other parts in contact with the medium: 1.4517 Electric motor: 5.5 kW Energy efficiency. IE 2 Voltage: 400/ 690 Volt Speed: 2950 rpm The material 1.4593 Noridur is very well suited for: - Chemical and process engineering industry - Sulphuric and phosphoric acid - Salt extraction and processing - Petrochemical industry Bmg9kmu7ug - Coking plants - Textile and pulp industry - Food and sugar industry - Mining/coal mining and extraction - Flue gas desulphurization plants - Acidic, chloride-containing washing suspensions - Acidic process water - Waste water treatment/sewage treatment plants - Offshore and marine technology
