Used Printed Circuit Board for sale (11,482)

Condition: ready for operation (used), Year of construction: 1967, A Winkler + Dünnebier envelope printing machine is available. Envelope type: peel & seal gumming, format range side seam min./max.: 114mm x 150mm/330mm x 450mm, format range center seam min./max.: 114mm x 150mm/230mm x 450mm, paper weight range: 70g-165g/m², production output: 250 envelopes/min. Including vacuum pump and blow air pump. Documentation available. On-site inspection is possible. Ffodpfjvva Hqex Ac Neu

Condition: ready for operation (used), A screen printing system including a feed table with XY adjustment is available. Printing area: 800mm/500mm, max. print object height: 160mm, max. frame dimensions X/Y/Z: 1290mm/760mm/40mm, max. printing speed: 500 prints/h, machine dimensions X/Y/Z: approx. 1700mm/1100mm/2000mm, weight: approx. 450kg. Documentation available. An on-site inspection is possible. Ffsdpfx Acswut Hao Nou

Condition: ready for operation (used), Year of construction: 2013, A RokuPrint universal screen printing machine for flat, round and radius printing as well as laboratory applications is available. Screen frame format: 600mm/300mm, max. flat printing dimensions X/Y: 300mm/200mm, max. part height: 160mm/250mm, printing capacity: approx. 1800 prints/h, machine dimensions X/Y/Z: approx. 800mm/550mm/600mm, weight: approx. 50kg. Documentation available. An on-site inspection is possible. Fedpfxoxd Avyo Ac Nefu

Year of construction: 2022, condition: ready for operation (used), Offered is an SLM280 2.0 Single 700W year 2022, approx. 5350h, SLM MCS control, build volume X/Y/Z: 280mm/280mm/365mm minus thickness of substrate plate, 3D optics configuration: Single single/double 400W/700W, Dual 400W/700W IPG fiber laser, build rate: 113cm³/h, layer thickness: 20μm-90μm, feature size: 150μm, beam focus diameter: 80μm-115μm, scan speed max.: 10m/s, inert gas consumption process: 5l/min (argon), inert gas consumption purging: 110l/min (argon). Accessories: chiller package HRS050 L/W, screening station PSM100 V3, handling device BPH280, bottle lift, material change kit. SLM280 2.0 complete incl. PSM100, powder containers, substrate plates (1.2709 & AlSi10Mg), additional filter housings, filter elements. Fully serviced annually by SLM Solutions (service reports available). Availability from 01.12.2025, machine dimensions X/Y/Z: 2600mm/1200mm/2700mm. Inspection possible by arrangement. Fodpfxexy R Ezo Ac Njfu

Condition: ready for operation (used), Year of construction: 2014, Printing technology: piezo DOD printheads: Xaar 1001, resolution: 720x360dpi, drying: 1xUV GOZ and 1xUV FOZ Höhnle with 7,2kW, pinning system (LED) after printing unit 1+5, extraction: in the drying unit for cooling the UV lamps and for odor minimization and improvement of sensory conditions, inert gas system: oxygen-reduced curing unit (inert gas system), consumption: under 6m³/h, printing: roll-to-roll, web width: 350mm, print width: 330mm, repeat length: min./max. printable section length 10-1000mm, print tolerance: single spacing +/-0,2mm, cumulative spacing: +/-1,5mm (over one meter), register: register accuracy +/-50μm, max. speed: 48m/min with 4 colors depending on ink coverage, white at 30m/min, speed must be preselected from 18 to 48m/min, print pre-treatment: corona with 1500VA, web cleaning: polymer rollers LC 350, air shafts: for cores with 76mm diameter for unwinding and rewinding, air shaft clamping pneumatic, clamping releasable to allow rotation of the winding mandrel, max. roll diameter for unwinding and rewinding: 610mm, max. roll weight for unwinding and rewinding: 120kg. power consumption: approx. 39kVA/60A, air consumption: 100NL/min, cooling capacity: approx. 60.000BTU/h =18kW, data interface: USB2.0, Ethernet, data format: PDF-X1 or X3 or EPS or AI, length: 4550mm, width: 1750mm, height: 2200mm, weight: approx. 3t. With documentation, chiller unit and inks. The machine is fault-free, complete and ready for operation, and has been serviced regularly. On-site inspection is possible. Ffodexz Ewnjpfx Ac Nou

Condition: ready for operation (used), Year of construction: 1993, Web width min./max.: 214mm/686mm, max. roll diameter: 1500mm, production output: 1000 covers/min. The machine is not equipped with peel-and-seal, but only with wet gumming. Including printing unit 2+1. The machine can cut and punch envelopes with windows. Documentation available. On-site inspection is possible. Ffodpfeuqndijx Ac Neu

Condition: ready for operation (used), An Eickmeyer flat printing machine with parallel lifting upper frame is available. Printing format X/Y: 500mm/800mm, max. screen frame dimensions X/Y/Z: 1050mm/520mm/30mm, max. workpiece height: approx. 140mm, operating hours: approx. 50h. Documentation available. On-site inspection is possible. Ffsdpfx Aovuadtsc Nju

Condition: ready for operation (used), Year of construction: 2005, A complete 8-color Fischer & Krecke flexographic printing system is available. Number of colors: 8, max. print width: 1250mm, max. material width: 1300mm, repeat print length min./max.: 320mm/800mm, max. mechanical speed: 360m/min, printable materials: PET (min. 12µm)/PP/OPP/LDPE/laminate materials. Inks: solvent-based, drying: thermal oil. Roll diameter: 800mm, core diameter: 76mm/152mm. Including BST Video Web Inspection System Premius, cleaning system Flexpress AutoClean (ACA), viscosity control Bloss Viscolor 1300, automatic roll change and rewind Flying Splice as well as an additional chill roll with a diameter of 460mm. Documentation available. On-site inspection is possible. Ffsdsvva E Hopfx Ac Nsu

Condition: ready for operation (used), Year of construction: 2000, Format range: Envelopes min./max.: 114x176mm/254x324mm, Booklet min./max.: 114x127mm/270x360mm, Pockets: With center seams min/max: 114x178mm/330x406mm, With side seams min/max: 114x178mm/254x406mm. Output: Dextrin or peel and seal: 600/min, latex gumming: 400/min. Documentation available. On-site inspection is possible. Ffjdpfxsv Rp R Uj Ac Neu

Condition: ready for operation (used), Year of construction: 1985, The system consists of 7 screen printing units, 6 with dryers and 1 without. Olbrich gravure printing unit, Olbrich hot stamping and smoothing calendar, Brinkhaus cooling segment, MT cutting unit and Olbrich rolling machine. The individual drives were added in 2008. Production speed (depending on product): 60m/min. Substrate: max. print width: 1200mm, max. web width: 1250mm, repeat: 640mm, repeat optional: 530mm/914mm. Main channel length: 28m, web width: 1200mm. Ffodpfer Equ Dox Ac Nou

Year of construction: 1992, condition: ready for operation (used), Max. paper size: 720x1040mm, min. paper size straight printing: 360x520mm, straight/reverse printing: 440x520mm, paper thickness: 0.06-0.5mm, max. print size straight printing: 710x1030mm, straight/reverse printing: 700x1030mm, max. throughput straight printing/ straight/reverse printing: 7000/ 5000 sheets/h, printing plate size (recommended): 790x1045mm, print start: 48mm, print-free gripper margin: 10.5mm ±1mm. Equipment: Miller TP 104 basic machine with two printing units, perfecting device between the first and second printing unit, numbering tower with control for Zeiser and Leibinger mechanical numbering units (without numbering units), Spiess TP 104/1 sheet feeder, load: 10,000N. Remote adjustment via control console: colour control 1st and 2nd printing unit, fine adjustment of circumferential and lateral register: ±1.5mm, plate cylinder, 2x plate clamping rails at the front - single - only divided at the rear, blanket cylinder washing device - completely defective, cleaning by hand, powder sprayer without additional control, delivery extension additional area after numbering unit by approx. 1.85m, 10x application ink rollers, 8x ink transfer rollers, 1x blanket roller, 1x wash roller, 1x ink lifting roller, complete documentation. Ffjdpfx Aew Azuboc Nsu

Condition: ready for operation (used), A 4-color Padane single-cylinder counter-printing machine with 4 inking units in pressing operation is available. Printing units: 4, repeat range: 280mm-650mm, max. printing width: 780mm, max. foil width: 810mm, cliché thickness: 2.84mm, printing process: single-sided, max. roll diameter: 600mm, number of cliché cylinders at 270mm: 2, number of cliché cylinders 280mm-650mm: 4, machine dimensions X/Y/Z: approx. 7500mm/2600mm/3000mm. Documentation available. On-site inspection is possible. Expected to be available from June 2025. Ffsdpowdwzaofx Ac Nsu

Condition: ready for operation (used), Year of construction: 2013, A Morlock single-color pad printing machine is available. Ink system: cup system, oval print image diameter range: 100mm-250mm, min. cliché print image dimensions X/Y: 100mm/210mm, max. cliché print image dimensions X/Y: 250mm/280mm, ink cup diameter: approx. 80mm, pressing force range: 1100N-1500N, max. cycle rate: 1400-1800 cycles/h, machine dimensions X/Y/Z: approx. 1050mm/500mm/650mm, weight: approx. 250kg, control: Siemens. Documentation available. An on-site inspection is possible. Ffsdpoxd Av Hsfx Ac Neu

Condition: ready for operation (used), Year of construction: 2016, A complete combined gravure/immersion roller system for Chadwick wallpaper rolls is available. Working width: approx. 560mm, substrate: paper/fleece, gravure printing process: water-based, printing units: 7, technical output: 180m/min, realistic output: 140m/min, production output: approx. 13000-15000 rolls/24h. 1) Windmöller & Hölscher 892C unwinder, year of manufacture: approx. 1970s. 2) 7x Chadwick gravure printing units. 3) Under-paper unwinding and gluing station. 4) Lenze pulling station. 5) 2x Saueressig cold embossing stations, year of construction: 1986/1989. 6) 2-section continuous dryer, total length: approx. 8m. 7) Double roller cooling station. 8) Web monitoring system WV-Star 500, year of construction: 2016. 9) Aligning and cutting system Saueressig 200440Y, inscription: G9, year of construction: 1989. 10) Ritter automatic roller machine. 11) Turning station Saueressig 201482Y, year of construction: 1989. 12) Inclined conveyor belt, working width: approx. 1000mm, length: approx. 3000mm. 13) Centralized supply and exhaust air unit SitVerba, year of construction: 2016, supply air fans: 7, exhaust air fan: 1. The entire system was equipped with new direct drives, drive control, system control, control cabinets, piping construction, process air technology, etc. and completely overhauled in 2016. Documentation available. On-site inspection is possible. Fodpfewqqv Dox Ac Nefu

Condition: ready for operation (used), Year of construction: 1989, Printing units outside/inside: 3/1, doctor blade units: available, envelope size range: booklet min./max.: 100mm/150mm–180mm/254mm, pocket min./max.: 89mm/120mm–187mm/305mm. Documentation available. An on-site inspection is possible. Ffedpfxexbrxlj Ac Nsu

Condition: ready for operation (used), Year of construction: 2006, A complete screen and gravure printing system for paper and non-woven wallpapers is available. Output: 15000 rolls/24h, substrates: paper: 80g-150g/m², non-woven: 50g-150g/m², printing width: 1060mm, working width: 1200mm, printing speed: 5m-150m/min. Components: Preconditioning, gravure printing unit, 5x screen printing units, 2x screen gravure printing units, 5x intermediate dryers (standard version), 2x intermediate dryers (1.5 times dryer height), 1x main channel with 6x 4m zones, roller/unwinder, register embossing, double-head printing units. Including various peripheral devices and units. Total dimensions X/Y/Z: approx. 60m/8m/6m. Documentation available. On-site inspection is possible. Ffsdpfxot Rkato Ac Nju

Condition: ready for operation (used), Year of construction: 1996, The gravure printing machine was used for wallpaper and other substrates. Number of printing units: 7, track width: 59mm, max. printing width: 53mm, max. roll diameter: 1000mm. King shaft drive / DW 1 + 7, single drive possible. Unwinding with lifting platform aid. Intermediate dryer operated with thermal oil. Paper and non-woven printing substrate, register control. Ffjdpfx Acjr Equyj Nou

Condition: ready for operation (used), Year of construction: 1993, Output: 1000 envelopes/min, min/max envelope size: 90mm x 120mm/176mm x 254mm, roll unwind: Contiweb, web alignment system: 1x BST, print units: 5+0 or 4+1 Doctor Blade, ink tanks: 4x Inkcan, ink pump: 4x Pneumatic, window unit: traditional punching knives and adhesive paper. Includes Top and bottom scriber, time lubrication unit, latex and dextrin sealing, infrared drying, electronic counter and monitoring. Ffedpfxjtqnuxe Ac Nou

Condition: ready for operation (used), Printing units: 2+1 flexo printing units, max. output with dextrin: 900 envelopes/min, paper weight: 70g/m²-120g/m². Formats: Book format min./max: 83x120mm/185x330mm, Diagonal format min./max: 83x120mm/185x265mm. On-site inspection is possible. Ffodpfetq Ha Tjx Ac Nou

Condition: ready for operation (used), Year of construction: 1996, Printing units outside/inside: 2/1, doctor blade units: 3, production capacity: 800 envelopes/min, window unit: Mini-Splice 356 CMG, roll/splicer: Winkler + Dünnebier 191, web guiding: BST EKR 1000, gumming: standard remoist (moisture-activated gumming for sealing flaps), ink pumps: 2, extraction: window punching waste. Documentation available. An on-site inspection is possible. Ffodpfx Acexbrxfs Nsu

Condition: ready for operation (used), Year of construction: 1991, Envelopes (wallet): min.: 127mm/150mm, max.: 255mm/420mm, pockets: Center seam: min.: 228mm/127mm, max. 420mm/305mm, Side seam: min.: 228mm/127mm, max.: 420mm/262mm. Speed: 500 pockets/min, paper weight: 80g/m²-150g/m². Ffjdpfotqnu Aox Ac Nju

Condition: ready for operation (used), A 4-color central cylinder printing system WDB Systemtechnik is available. Printing units: 4, ink type: UV, max. material width: 650mm, max. printing width: 600mm, printing length range: 300mm–800mm, max. printing speed: 250m/min, material types: PET/OPP/aluminum/laminate/composite materials, material thickness range: 20µm–150µm, max. unwind and rewind roll diameter: 1000mm, operating hours: 28h, printed length: approx. 57000m. System components: unwind and rewind unit, corona, UV dryer, drying channel, IR heater, cooling unit, and supply and exhaust air fan. Including lamination unit. Documentation available. An on-site inspection is possible. Ffodpfsxmkctjx Ac Nou

Year of construction: 2023, condition: ready for operation (used), A fully automatic SPEA bed-of-nails in-circuit tester for SMEMA production lines is available. Type: inline ICT tester, slots: 2x768/Core, conveyor width range: 50mm-380mm, conveyor length: 450mm, resistance measurement range: 1mΩ-1GΩ, capacitance measurement range: 0.5pF-1F, inductance measurement range: 1µH-1H, dimensions X/Y/Z: approx. 900mm/1000mm/1750mm. Including various feeders (8x2-56). Documentation available. An on-site inspection is possible. Fedpfexghn Hex Ac Nofu

Condition: good (used), I am selling a Teca-Print TPX 350 pad printing machine. Functional and in good condition. Ffjdpfx Acjv H Sgwo Neu

Condition: good (used), Mirus Anleger printing machine, in working order. Fsdpfx Acsud Awvj Nofu
