Used Deckel Maho Dmc 100 V for sale (339)

Year of construction: 2006, condition: ready for operation (used), Travel X/Y/Z: 835mm/510mm/510mm, speed: 12000rpm, spindle power: 14kW, table dimensions X/Y: 1000mm/560mm, table load capacity: 800kg, max. workpiece height: 720mm. Tool positions: 20, tool holder: SK40, max. tool diameter: 80mm/130mm, max. tool length: 250mm, rapid traverse: 30m/min, feed: 20m/min. Machine dimensions X/Y/Z: approx. 3500mm/3500mm/2700mm, weight: approx. 4500kg, control: Heidenhain iTNC 530, operating hours: 112962h, spindle hours: 30702h. Including chip conveyor, IKZ, distance measuring system. Documentation available. On-site inspection is possible. Ljdpfxov H Dgpo Af Ejru

Condition: used, Year of construction: 2007, reus 8000 min-1 U/min Weight 5500 kg Year 2007 Lredpfxswm Rqas Af Eeu Control Siemens 840D Dimensions (L/W/H) 3600 x 2800 x 2400 mm travel -x axis 1035 mm travel -y axis 560 mm travel -z axis 510 mm

Condition: used, Year of construction: 2005, x-travel 750 mm y-travel 560 mm z-travel 600 mm Control HEIDENHAIN iTNC 530 total power requirement 70 kW weight of the machine ca. 11.000 kg dimensions of the machine ca. m D E C K E L M A H O (Germany) Vertical CNC Machining Centre with high speed linear drives in 3 Axis and in double column design for high precision work Model DMC 75 V LINEAR Year 2005 _____ Working range: Longitudinal stroke X Axis 750 mm Vertical stroke Z Axis 600 mm Cross stroke Y Axis 560 mm Table clamping size 950 x 650 mm Ledpst Hw Trjfx Af Ejru Max. Table load 1.000 kg Max. height of workpiece 600 mm Tool holder Cone HSK 63 Spindle (KESSLER) speeds 18,000 rpm Torque, max. 86/130 Nm Spindle run-up time / stop time 3.2 sec Feeds / Quickfeeds, X, Y and Z Axes max. 90,000 mm/min Feed force 11.000/9.500 N Axis acceleration, X / Y / Z Axes 15 / 12 / 18 m/s Spindle drive 25/35 kW Total electrical load, approx. 75 kW - 400 V - 50 Hz Weight, approx. 11.000 kg Accessories / Special Features: This machine is very interesting because of the very stable double Column Portal Design and with the modern linear technology for fast and powerful high precision work. * HEIDENHAIN modern CNC Control System Model iTNC 530 in 3 axes, with all the usual options, cycles and sub programmes. * Table moves only in x axis and allows a comfortable loading of heavy workpieces * 30-position disktype tool magazine for max. tool Ø 100, 140 and 200 mm x max. length 300 mm. Max. weight 10 kg. Cut-to-cut time 6 sec. Pick-Up by main spindle. * BLUM tool-breakage control, Blum Receiver for RENISHAW –Head, no head available. * Double linear motors ensure very fast feed motions and strong feed power, equipped with own cooling system. * KESSLER Milling Spindle, Liquid-cooled, steplessly programmable up to 18.000 rpm * Completely covered working area with 2 sliding doors, one with spin-type bull-eye. * KNOLL Coolant device with scraper-type chip conveyor and pressure pomp. * Spindle working hours approx. 23.000 h Condition : Very good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rotational speed (max.): 12,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS Travel X: 1,040 mm Travel Y: 600 mm Travel Z: 500 mm Spindle speed: 12,000 rpm Lrodpewtrb Hjfx Af Eju Spindle taper: SK 40 Tool magazine: 30 positions Internal coolant supply: 40 bar Clamping area: 1,250 x 600 mm Maximum table load: 800 kg EQUIPMENT - Chip conveyor - Spindle cooler - ICS (internal coolant supply) - Tool measurement - Documentation

Condition: good (used), Year of construction: 1994, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, For sale is a Deckel Mori 70 V gantry machining center. The machining center is ready for immediate use and fully functional. Technical specifications: Year of manufacture: 1994 Grundig Dialog 112 control system X travel 700 mm Y travel 550 mm Z travel 500 mm SK 40 chuck mount Brushless AC servo motor Drive type: Continuously variable 0-8000 rpm Feed speed: Continuously variable 10000 mm/min Table size: 900 x 550 mm Table load: 0.8 t Machine weight: approx. 7.2 t Knoll scraper conveyor belt Internal cooling system Rapid traverse x/y 30000 mm/min Rapid traverse z 20000 mm/min Transport and loading can be arranged throughout Europe upon request for an additional charge. Prices plus VAT. Viewings available by appointment. Contact us; our team will be happy to assist you. Trade-ins or exchanges are available! Machine Purchase/Sale PURCHASE/SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality, yet affordable metalworking machine for your production? Or do you want to sell yours? Lrodpfx Afsv T U Ude Esu For further information or to contact us, visit our website.

Condition: excellent (used), Year of construction: 2011, Heidenhain TNC 620 control system Lsdpfowid Ecjx Af Eeru Travel X/Y/Z: 1035/560/510 mm Spindle speed: 12,000 rpm Tool magazine for 30 tools, SK 40 Through-spindle cooling: 12 bar Chip conveyor

Year of construction: 2008, condition: ready for operation (used), Travel X/Y/Z: 1050mm/800mm/560mm, C-axis: 360°, spindle head swivel range: -10°/110°, speed: 18000rpm, spindle power: 25kW/35kW, table diameter: 950mm, table load capacity: 800kg, max. workpiece height: 500mm. Tool positions: 30, tool holder: HSK A 63, max. tool diameter: 80mm/130mm, max. tool length: 250mm, rapid traverse: 90m/min, feed: 20m/min. Control: Heidenhain iTNC 530, operating hours: 117490h, spindle hours: 18086h. Including chip conveyor, IKZ, distance measuring system, Blum laser and measuring probe. Documentation available. On-site inspection is possible. Lodpjv H Dgiofx Af Ejru

Condition: ready for operation (used), Year of construction: 2003, operating hours: 8,810 h, functionality: fully functional, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS X-travel: 640 mm Y-travel: 600 mm Z-travel: 500 mm Control: SIEMENS 810D powerline Spindle speed: 12,000 rpm Table dimensions: 850 x 630 mm Table load: max. 600 kg Tool magazine: 30 positions Ledjv Rdbuopfx Af Eoru MACHINE DETAILS Total power requirement: 42 kW Machine weight: approx. 6.5 t Space required: approx. 3.50 x 3.30 x 3.60 m On-time: 52,248 h Spindle hours: 8,810 h EQUIPMENT - BLUM tool breakage/measurement system - Electronic handwheel - 3 leveling elements - Chip conveyor - Interlit SPB coolant/belt filter system 3/600

Condition: excellent (used), Year of construction: 2005, operating hours: 18,436 h, functionality: fully functional, travel distance X-axis: 885 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, swivel angle B-axis (min.): -10 °, swivel angle B-axis (max.): 110 °, No reserve price - guaranteed sale at the highest bid! TECHNICAL DETAILS X-axis: 885 mm Y-axis: 600 mm Z-axis: 600 mm Rotary axes: B-axis -10° to +110°, C-axis 360° Feed, dynamics and tool holder Maximum feed rate: 90 m/min X-axis acceleration: up to 15 m/s² Y-axis acceleration: up to 12 m/s² Z-axis acceleration: up to 18 m/s² Tool holder: HSK-A63 Table and load NC rotary table diameter: 750 mm Maximum load: 600 kg Cooling lubricant system & chip conveyor Container capacity: 500 liters Coolant supply: 40 l/min at 2.3 bar Chip disposal: Efficient scraper belt conveyor (Discharge height 850 mm) MACHINE DETAILS Operating hours: 18,436 h Switch-on time: 46,702 h Rated power: 73 kVA Rated current: 105 A Operating voltage: 400 V Lredpfx Afevrxcpj Eju Operating pressure: 6 bar Compressed air connection delivery rate: 30 Nm³/h Submitting a bid obliges you to collect the machine on time by February 19, 2025!

Condition: ready for operation (used), Year of construction: 2008, operating hours: 37,826 h, functionality: fully functional, machine/vehicle number: 29100008944, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, workpiece weight (max.): 600 kg, table width: 850 mm, table length: 630 mm, TECHNICAL DETAILS Travel in X-axis: 640 mm Travel in Y-axis: 600 mm Travel in Z-axis: 500 mm Table size: 850 x 630 mm Maximum table load: 600 kg Spindle taper: SK 40 MACHINE DETAILS Lsdpfswtq Rmox Af Ejru Control: FANUC Connected load: 39 kVA Power-on time: 75,884 h Spindle hours: 37,826 h

Condition: ready for operation (used), Year of construction: 2010, operating hours: 43,000 h, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, spindle speed (max.): 14,000 rpm, number of slots in tool magazine: 60, New spindle installed in 2024! TECHNICAL DETAILS X travel: 635 mm Y travel: 510 mm Z travel: 460 mm Table dimensions: 560 x 790 mm Speed: 14,000 rpm Tool holder: SK40 Number of tool positions in the magazine: 60 MACHINE DETAILS Weight: 5,500 kg Connected load: 35 kVA Operating voltage: 400 V, 50 Hz Operating hours: approx. 71,000 h Spindle hours: approx. 43,000 h Lodpfx Afju Unv Es Ejru EQUIPMENT - Chip conveyor - ShopMill - Paper filter

Condition: excellent (used), Year of construction: 2003, Siemens 840D control with ShopMill Travel paths X/Y/Z: 640 x 600 x 500 mm Spindle speed 12,000 min-1 Tool magazine for 30 tools, SK 40 3D measuring probe Lredjv Dt Rropfx Af Eou

Condition: ready for operation (used), Travel X/Y/Z: 1000mm/600mm/600mm, feed rate: 30m/min, rapid traverse: 30m/min, table dimensions X/Y: approx. 1200mm/600mm, max. table load: 800kg, tool stations: 24, tool holder: SK40, speed: 8000rpm. Machine dimensions X/Y/Z: approx. 3000mm/3500mm/3000mm, weight: approx. 5000kg, operating hours: approx. 10346h, spindle hours: approx. 10346h. Includes a compact filtration system Interlit SUK 200/550, year of manufacture: 2000. The machine is equipped with a new control system. Documentation available. An on-site inspection is possible. Lrsdpfew Dut Hsx Af Esu

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 1148000080, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 12,000 rpm, number of slots in tool magazine: 60, swivel angle C-axis (max.): 360 °, TECHNICAL DETAILS X-travel: 1,000 mm Y-travel: 1,000 mm Z-travel: 1,000 mm C-axis: 360° Control: MillPlus IT Heidenhain Tool magazine Capacity: 60 slots Spindle Max. spindle speed: 12,000 rpm Spindle mount: SK50 DIN 69871 Table Clamping surface: 1,000 mm x 800 mm MACHINE DETAILS Total power requirement: 65 kVA Machine weight: approx. 24.5 t Space requirement: approx. 6.50 m x 5.20 m x 3.50 m EQUIPMENT - Pallet changer - Electric handwheel HR410 - 4th operating mode - BLUM Laser tool measurement Lredevrfnfepfx Af Eju - Vibration sensor - IKZ pressure level 40 and 80 bar - Rotoclear Air filter system Coolant system 980 l Chip conveyor

Year of construction: 2004, condition: good (used), functionality: fully functional, machine/vehicle number: 28860011684, TECHNICAL DETAILS X axis: 1000 mm Y-axis: 600 mm Z-axis: 600 mm Control: SIEMENS SINUMERIK 810 D POWERLINE rotational speed: 10.000 rpm tool places: 24 tool holder: SK 40 Lrjdpspvlbnofx Af Esu MACHINE DETAILS on request EQUIPMENT IKZ 15 bar, 800L tank Chipping machine Flushing gun X-Y-Z AxBs measuring system

Condition: ready for operation (used), Year of construction: 2002, operating hours: 23,838 h, functionality: fully functional, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, workpiece weight (max.): 600 kg, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 640 mm Y-axis travel: 600 mm Ledewtq Rgepfx Af Esru Z-axis travel: 500 mm Control: Heidenhain iTNC 530 External length: 850 mm External width: 630 mm Max. table load: 600 kg Spindle speed range: 12,000 rpm Tool holder: SK 40 MACHINE DETAILS Operating hours: 107,000 h Spindle hours: 23,838 h

Year of construction: 2008, condition: good (used), functionality: fully functional, machine/vehicle number: 1540503266A, TECHNICAL DETAILS X axis: 635 mm Ljdpfxsng Amvj Af Esru Y-axis: 510 mm Z-axis: 460 mm Control: Heidenaihn İTNC 530 Number of tools: 30 Tool holder: SK 40 MACHINE DETAILS on request EQUIPMENT Direct path measuring system X,Y,Z Measuring probe Heidenhain TS640 Spindle conveyor Operating mode 4

Condition: excellent (used), Year of construction: 2003, DECKEL MAHO DMC 104 V SIEMENS 810 D Technical specifications: X-travel: 1040 mm Y-travel: 600 mm Z-travel: 500 mm Spindle speed: 12,000 rpm Spindle mount: SK 40 Tool magazine: 30 positions Clamping area: 1250 x 600 mm Lodpfx Aswm Aq Eef Eeru Max. table load: 800 kg Internal coolant supply 40 bar Accessories: Chip conveyor, spindle cooler, internal coolant supply, tool measurement, documentation

Condition: ready for operation (used), Year of construction: 2006, operating hours: 9,442 h, functionality: fully functional, machine/vehicle number: 29110004034, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS Lrsdpewa Tmwefx Af Eeu Control: Siemens 810D Powerline Table surface: 1,250 x 600 mm X-axis travel: 1,040 mm Y-axis travel: 600 mm Z-axis travel: 500 mm Spindle & tool holder Tool holder: SK 40 Spindle speeds: 1 - 12,000 rpm Spindle drive: 13 kW / 19 kW (100% / 40% ED) Tool changer: 30 positions MACHINE DETAILS Spindle hours: 9,442 h On-time: 32,189 h EQUIPMENT - Linear drive in the X-axis for more precise movements - Bed flushing to clean the work area - Spiral chip conveyor for efficient chip disposal - Direct position measuring system for precise Position determination - Temperature compensation of the Z-axis via temperature sensor with active cooling unit - Blown air from outside via two pipes for chip removal

Condition: ready for operation (used), Year of construction: 1996, General Data Measurements width 2400 mm Measurements depth 3100 mm Measurements height 2600 mm Machine weight 10000 kg Main Drive Spindle speed range 15000 Table Table load 1200 kg Tools Number of index 30 Max weight 12 kg Max tool diameter 80 mm Max tool length 300 mm Media Power consumption 50 kva General Data Measurements width 2400 mm Measurements depth 3100 mm Measurements height 2600 mm Machine weight 10000 kg Main Drive Spindle speed range 15000 Table Lsdpfsxp Slzsx Af Eeru Table load 1200 kg Tools Number of index 30 Max weight 12 kg Max tool diameter 80 mm Max tool length 300 mm Media Power consumption 50 kva This 3-axis DECKEL MAHO DMC 100V was manufactured in 1996. It features a robust 10,000 kg weight, dimensions of 3.1 x 2.4 x 2.6 m, and a power consumption of 50 kVA. The machine offers a usable table area of 1250 x 800 mm and can handle a maximum table load of 1200 kg. It includes a tool magazine with 30 tools. If you are looking to get high-quality milling capabilities consider the DECKEL MAHO DMC 100V machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2012, Control Unit Brand SIEMENS Model Sinumerik 840D Movement X-Axis Movement 1000 Y-Axis Movement 1250 Z-Axis Movement 1000 Additional Equipment Chip conveyor/ Oil mist collector /980 litre high pressure coolant through the spindle system with paper band filter /Infrared measuring sensor/ Tool measurement with BLUM Laser 3D/ Quick Set preparation /Full set of manuals in English, Estonian, and digital copy (English)/ Cooling unit Air blast through the spindle /Maintenance kit with installation, filters, and wipers This 5-axis DMG DECKEL MAHO DMC 100U duoBLOCK was manufactured in 2012. It features a Siemens Sinumerik 840D control, a 1000x800 mm pallet clamping surface, and rapid traverse rates up to 60m/min. The spindle reaches speeds of 18,000 rpm with a maximum torque of 119 Nm. Includes a 60-position tool changer and a high-pressure coolant system. Consider the opportunity to buy this DMG DECKEL MAHO DMC 100U duoBLOCK universal machining centre. Contact us for more information about this machine. Application Types Milling Lredpfx Aew R E R Usf Esu

Condition: ready for operation (used), Year of construction: 2005, Control Unit Brand SIEMENS Model SINUMERIK 840D Main Drive Spindle speed range 8000 This DMG DECKEL MAHO DMC 100H duoBLOCK was manufactured in 2005. It features a Siemens 840D control system, a 60-tool automatic tool changer, and a BT50 spindle capable of 8000 rpm. The table measures 1000x800 mm. Consider the opportunity to buy this DMG DECKEL MAHO DMC 100H duoBLOCK horizontal machining centre. Contact us for more information. Application Types Lsdpfx Afewxz Hvj Eeru Milling

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Technical Data: Deckel Maho DMC 103V - Year of manufacture: 2002 - Control system: Heidenhain TNC 426 (electronic handwheel) - Travel: X - 1000 mm, Y - 600 mm, Z - 600 mm Working Spindle: - Max. spindle speed: 10,000 rpm - Tool holder: SK40 Lrodpjxcyrvjfx Af Esu Table: - Clamping area: 1200 x 600 mm - Table load capacity: 800 kg Tool Magazine: - Number of tool positions: 24 Operating Hours: - Machine on: 49,189 hrs (see photo) - Spindle on: 17,590 hrs (see photo) (spindle replacement, NEW spindle has run approx. 14,000 hrs) Options: - External coolant supply - Documentation, machine manuals Accessories: - 1 tool trolley equipped with SK40 tool holders (see photo) - 1 3D probe (see photo) Delivery Time: - Immediately Special Features: - Machine is ready for immediate operation. - Machine is available for immediate delivery. - The machine can be inspected and tested under power on site. - Machine is loaded free on truck. - Forklift for loading is available. - Transport can be organized upon request.

Condition: excellent (used), Year of construction: 2003, Technical Data: Deckel Maho DMC 63V - Year of manufacture: 2003 - Control: Heidenhain iTNC 530 (electronic handwheel) - Travels: X-630mm, Y-500mm, Z-500mm Working Spindle: - Max. spindle speed: 10,000 rpm - Tool holder: SK40 Tool Magazine: - Number of tool stations: 24 Operating Hours: - Machine on: 45,163 hrs - Spindle on: 14,919 hrs (INFO: Spindle replaced - NEW spindle has approx. 2,000 operating hours) Accessories: - 1 tool cart incl. SK40 tool holders (see photo) - 3D measuring probe (see photo) Delivery time: - Immediate Options: - External coolant supply Lodpfx Asw Rd Dmof Eeru - Documentation, machine manuals Special Features: - Machine is immediately ready for operation. - Machine is available for immediate delivery. - Machine can be inspected and tested under power on site. - Machine will be loaded onto truck free of charge. - Forklift for loading is available. - Transport can be organized upon request.

Condition: used, Universal Machining Center Machine type: DMG Deckel Maho DMC 340 U Control: Heidenhain iTNC 530 Year of manufacture: 2002 TECHNICAL DATA: Travel: X-axis: 2,800 mm Y-axis: 3,400 mm Lodpfx Aewa Aihjf Ejru Z-axis: 1,600 mm B-axis C-axis Rapid traverse: (X/Y/Z): 60 / 30 / 40 m/min. Swivel head Speed range: 10,000 rpm Drive power: 44/32 kW Torque: 288 Nm Tool holder: HSK 100 Tool positions: 120 Tool diameter: 130 / 250 mm Tool length: 650 mm Tool weight: 30 kg NC rotary table: 2500 x 2000 Pallet system Number of pallets: 2 Pallet size: 2500 x 2000 mm Top table: 2800 mm diameter Features: Internal cooling (IKZ): bar Coolant tank: l Chip conveyor Electronic handwheel Chip flushing gun
