Used Studer Universal External Cylindrical Grinding Machine for sale (69,283)

Condition: used, Year of construction: 1980, Technical details: grinding diameter: 380 mm grinding length: 1000 mm centre height: 180 mm grinding wheel diameter: 400 mm max. workpiece weight between centres: 250 kg total power requirement: 10 kW weight of the machine ca.: 4,1 t dimensions of the machine ca.: 3 x 2 x 1,6 m with internal grinding attachment with fixed and swivelling headstock Gbedswy Ri Nspfx Ad Ijp with coolant tank *

Condition: used, grinding diameter 360 mm grinding length 1000 mm centre height 260 mm grinding wheel dia. x width 500x80 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale Gjdpfxoyqv Udj Ad Ijbp apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, Year of construction: 2024, functionality: fully functional, Universal CNC cylindrical grinding machine for high-precision internal & external cylindrical grinding MBF 453U from the MaiBase platform The machine is a completely new development with strong dimensions in a small space! Technical data: Center width: 430 mm Standard center height: 200 mm Grinding length: 400 mm Grinding wheel diameter: 500 mm Z-axis adjustment path: 550 mm X-axis travel: 385 mm Dimensions and weight: 2200 x 2500 x 2400 mm // 6500 kg Equipment of the machine: Gedpfx Ajtrf Smod Iebp - FANUC Oi-F Plus control system - Grinding headstock (swiveling) with 15kW motor spindle - Workpiece headstock MK5 - Tailstock MK3 with 20 mm stroke (optional 60 mm / 120 mm) - Handwheel for manual axis movement - Z-axis - X-axis - C-axis - B-axis - Glass scales for X- and Z-axis - Internal grinding spindle FISCHER UJ80 - Internal grinding spindle (GMN motor spindle) optional - Dressing spindle attached to the workpiece headstock for rotary dressing - Automatic door drive

Year of construction: 1979, condition: refurbished (used), functionality: fully functional, TECHNICAL DETAILS Maximum height: 125 mm + 50 mm height adjustment Distance between centers: 1,000 mm Grinding wheel › Diameter: 400 mm Gedpfx Ajk H Hp Nod Isbp › Width: 50 mm › Bore: 127.0 mm Angle adjustment: 270° Workpiece spindle head: 20 - 400 rpm Spindle taper: 5 MT Tailstock taper: 3 MT Table angle adjustment: 8° Table speed: continuously variable up to 6.0 m/min Internal grinding spindle with 60,000 rpm External grinding wheel motor: 4.0 kW Workpiece spindle motor: 1.5 kW Machine weight: 3,100 kg Overall machine dimensions: 2,860 × 1,680 × 1,670 mm (L × W × H) EQUIPMENT & SCOPE OF DELIVERY • Machine completely refurbished • New control cabinet & new wiring diagram • New motor & frequency inverter for the working head • 2-axis DRO • Coolant tank with paper filter • Geometry manufactured according to the Kellenberger protocol • Internal grinding spindle • Numerous accessories Please refer to the test report for the machine in the appendix below.

Condition: excellent (used), FANUC 21i-T Control Center Height 175 mm Distance between centers 1000 mm Grinding head B-axis 1° Grinding wheel 500 x 63 x 203 mm Grinding wheel speeds -1'500 rpm Internal grinding attachement 60'000 rpm Work piece spindle head C-axis 0.001 ° Godpfx Aoyabt Dsd Isbp Measuring probe Automatic balancing attachement Wheel dresser Misc. accessories MARCELS MASCHINEN AG

Condition: used, Year of construction: 1982, Technical details: grinding diameter: 600 mm grinding length: 3000 mm centre height: 315 mm workpiece weight max.: 3000 kg work piece spindle speed: 8 - 120 U/min grinding wheel motor: 25 kW grinding wheel speed: 45 m/sec grinding wheel width x diameter: 750 x 80 mm table speeds: 30 - 4500 mm/min feeds of grinding head: 0 - 5 mm/min table swivelabel +/-: 7,5 ° total power requirement: 55 kVA weight of the machine ca.: 18 t dimensions of the machine ca.: 11,5 x 4 x 2,2 m Gjdpovb Dl Usfx Ad Ijbp - Internal grinding device - taper grinding up to 10,1° based on diameter - automatic grinding cycle - grinding wheels and flanges - dressing device - coolant attachment - dust exhauster, various steady rests *

Year of construction: 2014, condition: ready for operation (used), A Karstens cylindrical grinding machine from 1992, which was completely overhauled and modernized in 2014, is available. Center width: 1000mm, center height: 180mm, grinding diameter: 360mm, max. workpiece weight center/flying: 250kg/70kg, grinding wheel diameter: 400mm. Spindle holder: MK4, speed: 450rpm, swivel range: 90°, quill holder: MK4, quill stroke: 45mm, quill force: 600N. Table swivel: 10°, infeed spindle: 80mm, rapid traverse: 50mm, coarse adjustment: 280mm, weight: approx. 3800kg. Including 3x centering points and grinding wheels as good as new. Documentation available. On-site inspection is possible. Gbedpfx Adjv Sufte Ijp

Year of construction: 2016, condition: ready for operation (used), Grinding wheel diameter: 220mm, grinding wheel width: 5mm, base body width: 20mm, bore diameter: 52mm. Test piece: diameter: 100mm, width: 300mm, profile height: 35mm. Small workpiece: Outer diameter: 400mm, bore diameter: 205mm, wheel width: 100mm, torque: 20Nm, weight including mandrel: 200kg. Large workpieces: Outer diameter: 700mm, bore diameter: 350mm, disk width: 300mm, torque: 800Nm, weight: 250kg. Accuracy: Repeat accuracy: less than 2µm, axial and radial run-out accuracy (large spindle): less than 2µm at 400mm diameter, axial and radial run-out accuracy (small spindle): less than 2µm at 200mm diameter, parallelism over 300mm between test piece and workpiece axis: less than 2µm. Tool spindle speed: 10000rpm, small workpiece spindle: 23000rpm, large workpiece spindle: 6000rpm, test piece spindle: 1000rpm. Gbodpsv T Aqgefx Ad Isp

Year of construction: 1958, condition: ready for operation (used), Grinding length: 1500mm, center height: 175mm, max. workpiece diameter: 350mm, max. workpiece weight: 300kg, grinding wheel diameter: 450mm, grinding wheel width: 80mm, bore: 203mm. Machine dimensions X/Y/Z: approx. 3600mm/1900mm/1900mm, weight: approx. 4000kg. Documentation available. An on-site inspection is possible. Gjdpfx Ajyg Nvmod Iobp

Condition: used, Year of construction: 1965, There are two WMW SU 315x3000 available, connected load machine 1/ 2: 12.6/ 12kW, weight machine 1/ 2: 8.2/ 9t, machines need overhauling. Gsdpfexg Ihgsx Ad Ijbp

Condition: used, Year of construction: 2005, Technical details: grinding diameter: 5 - 55 mm Gsdpfezlh Spsx Ad Iobp grinding length: 500 mm centre height: 75 mm total power requirement: 45 kW

Condition: excellent (used), functionality: fully functional, KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE MODEL: 1000 U YEAR OF MANUFACTURE: 2000 PARTIAL OVERHAUL: 2026 Centre height: 175 mm Grinding length: 1000 mm Equipment: - Standard accessories - Standard workpiece headstock MK5 with adapter flange DIN 55027, size 5 - Splash guard hood for the above - Tailstock with fine adjustment, MK4 - Internal grinding attachment with protective cover for grinding spindle D:80 mm for belt-driven spindles - FISCHER internal grinding spindle type HJN 842, incl. grinding mandrels (4 pieces, choice) - HJNZ 42 collet chuck - Oil mist lubricator for HJN spindles - STREULI magnetic paper band filter system, type: SPB 2 - Coolant supply through the workpiece spindle - HEIDENHAIN digital length measuring system on X and Z axes - Sine bar on the workpiece headstock incl. alignment arbor MK5 - Permanent magnetic chuck, D:200 mm - Three-jaw chuck, D:160 mm - Four-jaw chuck, D:160 mm - Collet attachment for Schaublin collets B32 - Set of B32 collets, D: 1.0–30.0 mm, increment 0.5 mm (59 pieces) - Dial indicator stop for table swivel with indicator 0.01 mm - Table fixed stop - Dressing stop for internal grinding - LED machine lamp Gedoyf E Suepfx Ad Iobp - Various grinding wheel flanges, left (2 pieces) - Pneumatic table load relief - Swiveling dressing device for external, face, or internal grinding operations - Set of vibration damping pads - New three-color paint finish (light grey RAL 7035 / blue RAL 5012 / dark grey RAL 7016) - New acceptance protocol according to KELLENBERGER standard - Documentation - CE conformity The machine is currently being overhauled, sample photos shown!

Condition: used, Year of construction: 1999, grinding diameter 360 mm grinding length 650 mm Gbedpfx Ast Hw A Hjd Iop centre height 180 mm Control SIEMENS 840 D total power requirement 15 kW weight of the machine ca. 9500 kg dimensions of the machine ca. m

Year of construction: 2002, condition: used, grinding diameter 10-300 mm grinding length 650 mm centre height 175 mm total power requirement 12 kW weight of the machine ca. 3,7 t Gbedpfx Asva I N Ued Iep

Condition: used, centre height 100 mm centre distance 500 mm grinding wheel diam. min/max. 200 - 300 grinding wheel speeds 2.250/2.420/2.680 U/min workpiece turning speeds 30 - 750 U/min Workpiece spindle: MK 4 Grinding power 3 kW Gbjdpszkv Dkofx Ad Isp Headstock Power 0,45 kW In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: used, centre height 200 mm Gedpfx Adey Ay N Ds Isbp dist. between centers 1.000 mm grinding length 1.000 mm max. workpiece diameter 360 mm grinding wheel width 127 mm spindle tunring speed 1.500 U/min turning speed range - workpiece spindle 15 - 320 U/min dimensions 2,80 x 1,50 x 1,70 m In our assessment, the machine is in good used condition and can be inspected under power by appointment. The machine has been overhauled. The guideways have been re-scraped. The spindle has new bearings. The control cabinet is new. Accessories, tools, and clamping devices shown in the images are only included if explicitly stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2006, grinding diameter 250 mm grinding length 1000 mm Control Kavalir K 51 peripheral speed 25 - 45 m/sec max. workpiece weight between centres 80 kg voltage 400V AC 50 Hz control voltage 24V AC/DC current -Sicherung für Zuleitung 35 A weight of the machine ca. 3,8 t In our assessment, the machine is in good used condition Gbjdpfxsx I Sigs Ad Ijp and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Year of construction: 1998, Year 1998 Control Fanuc In our opinion, the machines are in very good used condition Condition and can be viewed under power by appointment. Accesories: - Suction - Felsomat loading system An accessory package can be purchased additionally. Gbodpfx Adjxc Nyvj Isp Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well Subject to prior sale!

Condition: used, Year of construction: 1998, Year 1998 Control Fanuc In our opinion, the machines are in very good used condition Condition and can be viewed under power by appointment. Accesories: - Suction - Felsomat loading system An accessory package can be purchased additionally. There are 2 identical machines available. Gbodexc Nypspfx Ad Iop Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well Subject to prior sale!

Condition: used, Model: CW Serial No: 26520 Capacities: Maximum Swing Over Bed: 430mm Maximum Distance Between Centres: 2500mm Wheel Dimensions: 660x 75mm Work Head Speeds: (3) 20 – 160rpmrpm Wheel Head Speeds: 735rpm Table Swivels: Electrics: 415v, 3ph, 50 Cycles Motors Wheel Head: 20 HP 975rpm Work Head: 3HP 1120rpm Complete With: 2 No 2 Point Open Steadies Complete Tailstock Mounted Wheel Dressing Attachment Gedpfeyx Hx Dox Ad Iebp Coolant Approximate Dimensions: 6,750 x 2000 x 1800mm Approximate Weight: 9,000kg

Condition: used, Year of construction: 2012, workpiece . workpiece diameter 15 -70 mm swing diameter max. 150 mm clamping length max. 500 mm Swing over bezel area 70 mm dimension 150 x 300 mm max. turning speeds 250 min/-1 longitudinal adjustment manuell über Kettenrad Fixed tip MK 4 (Junker D75 mm) clamping capacity ü. Hydraulik einstellbar travel -z axis max. 1000 mm feed z - Achse (CNC gesteuert) dimension D 205 x 450 mm flange diameter D 190 mm standards association D 127 mm drive 30 kW speed control mit Frequenz- Umformer max. turning speeds 4400 min/-1 type Borazon (CBN) o. Diamant mm diameter 450 mm bore D 127 mm peripheral speed max. 90 m/sec type GR-3520-NR mm diameter range D 20 - D 35 mm dimension D 80 x 250 mm flange D 100 standards association D 75 drive 1,8 kW max. turning speeds 24000 min/-1 weight of the machine ca. 7,0 t Gbjdpex H Andsfx Ad Ijp In our opinion, the machine is in good condition and can be inspected under power by appointment. There are 2 identical machines available. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: used, Cylindrical Grinding Machine TSCHUDIN type HTG 400 Between points: 400 mm Centre height: 100 mm Gedozk Dbdspfx Ad Ijbp Cone: CM4 Spindle speed: from 70 to 500 RPM Max table travel: 420 mm Table orientation at 15° Grinding wheel: Ø 300 mm Retractable tailstock CM3 Machine rebuilt by REWITECH SA (Switzerland) in 1995 Equipped with one settling tank PHILIPS Voltage: 380 V Dimensions (L x W x H): 2000 x 1400 x 1600 mm Weight: approx 1,5 T

Condition: used, External/Internal Cylindrical Grinding GENDRON RU 28.100 Between points: 1000 mm Maxi grinding diameter: Ø 290 mm Tool holder rotation: from 70 to 370 RPM 4-jaws Ø 200 mm chuck Grinding wheel: Ø 300 mm Auto pass plug Swivel table External hydraulic group External lulbricant tank Gbjdozk Dayepfx Ad Ijp Voltage: 380 V Dimensions (L x W x H): 3000 x 1900 x 2000 mm Weight: approx 3 T

Condition: used, External/Internal Cylindrical Grinding JONES-SHIPMAN type 1310 Gbsdpfx Aozk Damed Ijp Capacity: Ø 200 x 450 mm (8'' x 18'') Tilted table Grinding wheel: Ø 300 mm x thickness 25 mm x bore Ø 125 mm Drive wheel speed: 1750 and 2300 RPM Rotary grindstone holder support Supplied without internal grinding spindle Equipped with 1 lubricant tank Voltage : 380 V Length: 1800 mm Depth: 1600 mm Total height: 1900 mm Weight: approx 2 T

Year of construction: 2008, condition: used, functionality: fully functional, machine/vehicle number: TTS10371, Our TT8500 is in very good condition and fully functional. It is equipped with an EPSON manipulator and is very well suited for pre-grinding operations such as with step drills, necking, relief grinding, chamfers, etc. The centerless processing also offers special advantages, especially regarding the concentricity of the tools to be produced. Gsdpow H Sguofx Ad Isbp
