Condition: ready for operation (used), Year of construction: 2014, operating hours: 6,500 h, General Data Measurements width 1800 mm Measurements depth 2200 mm Measurements height 2200 mm Machine weight 5000 kg Control Unit Brand BROTHER Main Drive Spindle speed range 10000 Iedpoxpkt Rofx Afietn Number of axis 4 Movement X-Axis Movement 700 mm Y-Axis Movement 400 mm Z-Axis Movement 350 mm Table Table load 250 kg This 4-axis Brother Speedio S700X1 was manufactured in 2014. It features a robust table size of 700 x 400 mm and a maximum table load of 250 kg. Equipped with a high-speed spindle up to 10,000 rpm and a 15 kW motor, it supports a tool magazine with 24 tools. Ideal for precise and efficient machining. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2018, Control Unit Brand FANUC Model 31i-B5 Main Drive Spindle speed range 10000 / 24000 Spindle motor power BBT30 Number of axis 5 Movement X-Axis Movement 700 mm X-Axis Rapid Traverse 54 m/min Y-Axis Movement 400 mm Y-Axis Rapid Traverse 54 m/min Z-Axis Movement 330 mm Z-Axis Rapid Traverse 54 m/min Table Table load 300 kg Tools Number of index 21 Max weight 3 kg Max tool diameter 80 mm Max tool length 250 mm Iedpoxpklgofx Afietn This 5-axis FANUC Alfa D21LiB5 was manufactured in 2018 and features a robust vertical machining center design. Key specifications include a travel range of 700 × 400 × 330 mm, a table size of 850 × 410 mm, and a maximum table load of 300 kg. It supports a spindle speed of up to 24,000 rpm and a rapid traverse in all axes at 54 m/min. Consider the opportunity to buy this FANUC Alfa D21LiB5 vertical machining center. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2018, operating hours: 10,823 h, functionality: fully functional, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Spinner VC 750 CNC machining center Control: Heidenhain TNC620 Year of manufacture: 2018 Iodsxpct Nspfx Afiotn X-axis travel: 760 mm Y-axis travel: 460 mm Z-axis travel: 460 mm Rapid traverse rate: 36 m/min Milling spindle speed: up to 12,000 rpm Milling spindle drive: 10/17 kW Milling spindle torque: 64/108 Nm Taper: SK40 Number of tools: 32 Chip conveyor Overall height: 2,900 mm Overall length: 4,000 mm Overall width: 2,000 mm Total weight: 4,000 kg

Condition: ready for operation (used), Year of construction: 1997, Main Drive Spindle speed range 80 to 8000 Spindle motor power 5.5 kW Number of axis 3 Movement X-Axis Movement 760 mm Y-Axis Movement 460 mm Z-Axis Movement 610 mm Additional Equipment Lehman 4/5-axis dividing machine, diameter 200 mm Fully protective cabin with sliding door This 5-axis Hurco BMC 30HT/M was manufactured in 1997, featuring a Lehman 4/5-axis dividing head with a 200 mm diameter. It includes a CNC Ultimax 3 control, a tool changer with 24 positions, and a spindle speed up to 8000 rpm. The machine offers X/Y/Z travel paths of 760/460/610 mm and a rapid traverse of 24 m/min. Consider the opportunity to buy this Hurco BMC 30HT/M vertical machining center. Contact us for more information about this machine. Application Types Itedpsxn U Aaofx Afisn Milling

Condition: used, Year of construction: 2014, BAZ Wemas VZ860, year of manufacture 2014 Itodpfx Afsxn Rmhjien

Condition: ready for operation (used), Year of construction: 2005, operating hours: 60,737 h, Control Unit Brand RÖDERS Model RMS 6 V3.6 Main Drive Number of axis 3 Movement Iodjxn Dmzjpfx Afistn X-Axis Movement 760 mm Y-Axis Movement 550 mm Z-Axis Movement 300 mm This 3-axis Roders RFM 760 vertical machining centre was manufactured in 2005. It features a spindle speed range of 3,000 to 42,000 rpm and travel paths of 760 mm in X, 550 mm in Y, and 300 mm in Z. Equipped with Röders RMS 6 V3.6 control, it offers precise machining capabilities. If you are looking to get high-quality milling capabilities, consider the Roders RFM 760 machine we have for sale. Contact us for further details regarding this machine. Application Types Milling

Condition: used, Year of construction: 2006, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, controller manufacturer: Haas, total height: 2,750 mm, total length: 2,250 mm, total width: 2,360 mm, table width: 914 mm, table length: 356 mm, table load: 680 kg, spindle speed (max.): 12,000 rpm, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control Haas CNC Table size 914 x 356 mm Table load 680 kg Number of pallets: 1 x Movement X-axis 762 mm Movement Y-axis 406 mm Movement Z-axis 508 mm Spindle taper DIN 68971A Spindle speed 12.000 1/min Itsdexnm A Eopfx Afion Spindle motor 22,4kW Magazin capacity 24 + 1 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2012, Machine Designation: Vertical Machining Center LCV-760 (Moving Column Type) Manufacturer: LEADWELL CNC Machines Mfg. Corp., Taichung, Taiwan Type / Model: LCV-760 Control System: FANUC Oi-MD Iodpfexnlhgsx Afijtn Technical Specifications • Working Area / Travels: - X-axis travel: 760 mm - Y-axis travel: 610 mm - Z-axis travel: 610 mm - Distance from table (pallet) top to spindle nose: 150 – 760 mm - Distance from column front to spindle center: 718 mm - Table dimensions: 850 × 600 mm - Maximum workpiece weight: 400 kg - Table configuration: M16 × P2.0 mm T-slots - Table height (floor to table top): 1,033 mm • Spindle / Drive: - Spindle speed: 10,000 rpm (optional: 12,000 rpm) - Spindle drive motor: 18.5 / 24 kW (30 min / continuous duty) - Maximum spindle torque: 95 Nm (67.5 ft-lb) - Spindle taper: 7/24 TAPER No. 40 (BT-40) - Spindle bearing inner diameter: 70 mm - Tool clamping force: 1,200 kgf - Transmission: HT.D belt drive - Spindle oil chiller: included - Rigid tapping: standard • Feedrates: - Rapid traverse (X / Y / Z): 32 / 32 / 32 m/min - Cutting feedrate: 10 m/min - Jog feedrate: 2,500 mm/min • Automatic Tool Changer (ATC): - Type: Arm-type changer - Tool capacity: 30 tools - Tool taper: BT-40 - Retention knob: MAS P40T-1 (JIS B-6339) - Max. tool diameter (adjacent): 80 mm - Max. tool diameter (free): 100 mm - Max. tool length: 250 mm - Max. tool weight: 7 kg - Tool change time (tool-to-tool): 2 s - Chip-to-chip: 6 s • Automatic Pallet Changer (APC): - Number of pallets: 2 - Change method: hydraulic swapper - Pallet change time: 12 s • Motors: - Spindle motor: 18.5 kW (24 HP) - X-axis feed motor: 4.5 kW (6.4 HP), 30 Nm torque - Y-axis feed motor: 4.5 kW (6.4 HP), 30 Nm torque - Z-axis feed motor: 3.88 kW (5.4 HP), 22 Nm torque - Hydraulic pump motor: 3 kW - Lubrication pump motor: 0.01 kW - Coolant pump motor: 0.76 kW • Guideways: - X-axis: SNS45C2SSCOEx3 (600 mm width, 1,000 mm distance) - Y-axis: SNS45LC2X151SLHx2 (600 mm width, 600 mm distance) - Z-axis: SHS45R2SSCOEx1305×2 (500 mm distance) • Utilities / Connections: - Power supply: 45 kVA - Compressed air: 0.6 MPa (87 psi), 400 L/min - Hydraulic oil tank: 400 L - Lubrication tank: 2 L - Coolant tank: 300 L • Dimensions / Weight: - Machine height: 2,885 mm - Machine footprint: 3,510 × 2,410 mm - Machine weight: 9,200 – 9,500 kg (approx. 10 t) lifting requirement • Cutting Capacities: - Milling: 230 cm³/min - Drilling: Ø 40 mm - Tapping: M30

Condition: used, Year of construction: 2009, Machine Designation: Vertical Machining Center LCV-760 (Moving Column Type) Manufacturer: LEADWELL CNC Machines Mfg. Corp., Taichung, Taiwan Type / Model: LCV-760 Control System: FANUC Oi-MD Technical Specifications • Working Area / Travels: - X-axis travel: 760 mm - Y-axis travel: 610 mm - Z-axis travel: 610 mm - Distance from table (pallet) top to spindle nose: 150 – 760 mm - Distance from column front to spindle center: 718 mm - Table dimensions: 850 × 600 mm - Maximum workpiece weight: 400 kg - Table configuration: M16 × P2.0 mm T-slots - Table height (floor to table top): 1,033 mm • Spindle / Drive: - Spindle speed: 10,000 rpm (optional: 12,000 rpm) - Spindle drive motor: 18.5 / 24 kW (30 min / continuous duty) - Maximum spindle torque: 95 Nm (67.5 ft-lb) - Spindle taper: 7/24 TAPER No. 40 (BT-40) - Spindle bearing inner diameter: 70 mm - Tool clamping force: 1,200 kgf - Transmission: HT.D belt drive - Spindle oil chiller: included - Rigid tapping: standard • Feedrates: - Rapid traverse (X / Y / Z): 32 / 32 / 32 m/min - Cutting feedrate: 10 m/min - Jog feedrate: 2,500 mm/min • Automatic Tool Changer (ATC): - Type: Arm-type changer - Tool capacity: 30 tools - Tool taper: BT-40 - Retention knob: MAS P40T-1 (JIS B-6339) - Max. tool diameter (adjacent): 80 mm - Max. tool diameter (free): 100 mm - Max. tool length: 250 mm - Max. tool weight: 7 kg - Tool change time (tool-to-tool): 2 s - Chip-to-chip: 6 s • Automatic Pallet Changer (APC): - Number of pallets: 2 - Change method: hydraulic swapper - Pallet change time: 12 s • Motors: - Spindle motor: 18.5 kW (24 HP) - X-axis feed motor: 4.5 kW (6.4 HP), 30 Nm torque - Y-axis feed motor: 4.5 kW (6.4 HP), 30 Nm torque - Z-axis feed motor: 3.88 kW (5.4 HP), 22 Nm torque - Hydraulic pump motor: 3 kW - Lubrication pump motor: 0.01 kW Itodsxnki Aopfx Afien - Coolant pump motor: 0.76 kW • Guideways: - X-axis: SNS45C2SSCOEx3 (600 mm width, 1,000 mm distance) - Y-axis: SNS45LC2X151SLHx2 (600 mm width, 600 mm distance) - Z-axis: SHS45R2SSCOEx1305×2 (500 mm distance) • Utilities / Connections: - Power supply: 45 kVA - Compressed air: 0.6 MPa (87 psi), 400 L/min - Hydraulic oil tank: 400 L - Lubrication tank: 2 L - Coolant tank: 300 L • Dimensions / Weight: - Machine height: 2,885 mm - Machine footprint: 3,510 × 2,410 mm - Machine weight: 9,200 – 9,500 kg (approx. 10 t) lifting requirement • Cutting Capacities: - Milling: 230 cm³/min - Drilling: Ø 40 mm - Tapping: M30

Condition: excellent (used), Year of construction: 2014, operating hours: 21,800 h, functionality: fully functional, machine/vehicle number: P147YH288, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, nominal power (apparent): 11 kVA, overall weight: 2,200 kg, spindle speed (min.): 24,000 rpm, coolant supply: 40 bar, number of slots in tool magazine: 21, Equipment: chip conveyor, documentation/manual, Equipment: - FANUC DDR-T 4th axis digital rotary table with tailstock - high-pressure through-spindle coolant, 24,000 rpm - 200L chip conveyor with high-pressure pump - automated side door for robotic loading - machine under annual FANUC maintenance contract - optional extra: integrated Fanuc M20iA12L robot already mounted on the machine Itjdsxnhvyspfx Afijn

Condition: excellent (used), Year of construction: 2017, operating hours: 15,200 h, functionality: fully functional, machine/vehicle number: P172ZH357, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, nominal power (apparent): 11 kVA, overall weight: 2,200 kg, spindle speed (min.): 24,000 rpm, coolant supply: 40 bar, number of slots in tool magazine: 21, Equipment: chip conveyor, documentation/manual, Equipment: - FANUC DDR-T 4th axis digital rotary table with tailstock - high-pressure through-spindle coolant, 24,000 rpm - 200L chip conveyor with high-pressure pump - automated side door for robotic loading - machine under annual FANUC maintenance contract - optional extra: integrated Fanuc M20iA12L robot already mounted on the machine Itsdpexnhtljfx Afijn

Condition: ready for operation (used), Year of construction: 2009, General Data Measurements width 2220 mm Measurements depth 3700 mm Measurements height 2735 mm Machine weight 5350 kg Control Unit Brand HEIDENHAIN Model iTNC 530 Main Drive Tool taper ISO 40 Number of axis 3 Movement X-Axis Movement 750 mm Y-Axis Movement 500 mm Itsdpfxjxnd T Uj Afien Z-Axis Movement 500 mm Table Table load 650 kg This 3-axis KOVOSVIT MAS MCV 750 Speed was manufactured in 2009. It features a table clamping surface of 1000 x 640 mm, a maximum table load of 650 kg, and a spindle speed up to 12000/min. The machine includes a 24-position tool magazine and has dimensions of 3700×2220×2735 mm. If you are looking to get high-quality milling capabilities, consider the KOVOSVIT MAS MCV 750 Speed machine we have for sale. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2022, operating hours: 413 h, functionality: fully functional, machine/vehicle number: 3126137, SPECIFICATION Swing over cross slide 419mm Maximum cutting diameter 305mm Maximum cutting length 305mm Spindle nose A2-5 Spindle bore 58.7mm Bar capacity 44mm Maximum spindle speed 6000rpm Spindle motor power 11.2kW Number of turret tool station 12 X axis travel 200mm Z axis travel 406mm Rapid traverse X axis 30.5m/min Rapid traverse Z axis 30.5m/min Approximate weight 2750Kg MACHINE EQUIPPED WITH: - Haas CNC Control system Itjdjxm U Sxspfx Afisn 3 jaw chuck 165mm diameter Parts catcher Hydrafeed Multifeed 65 Barfeed 17 assorted tool holders, 5 of which are new and boxed Interlocked guarding Automatic lubrication system Coolant system Manual Cycle start hours 782 Feed cutting hours 413 NB Current list price new, machine £56,415.00, barfeed £12,000.00 Total £68,415.00 Special Price here at RK International

Condition: good (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 16015791684, travel distance X-axis: 350 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 380 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed length X-axis: 60,000 mm, feed length Y-axis: 60,000 mm, feed length Z-axis: 60,000 mm, torque: 41 Nm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 D SL, total height: 3,300 mm, total length: 2,900 mm, total width: 2,400 mm, table width: 400 mm, table length: 730 mm, overall weight: 6,000 kg, spindle speed (max.): 15,000 rpm, operating hours of spindle: 3,179 h, spindle torque (max.): 58 Nm, TECHNICAL DATA & EQUIPMENT: Operating voltage: 400 V Frequency: 50 Hz Rated current: 35 A Tool holder: BT 30 Tool clamping force: 3.5 +/-1.2 kN Feeds: infinitely programmable Travel measuring system resolution X-, Y-, and Z-axis: 0.01 µ Positioning uncertainty: 8 µ Table with 2 T-slots as well as a GRESSEL brand clamping rail Jaw width: 90 mm Additionally, a 25-position tool changer including the tool holders shown in the photo and a touch probe Also included: a 4th axis (rotary table) from manufacturer LEHMANN and a robot cell from DMG MORI Type: WH 3 Year of manufacture: 2022 Itedpfxjxm Tnrs Afion NOTES ON COLLECTION: Pick-up must be firmly scheduled between December 10 and 12 FCA Winterlingen, loaded onto truck

Condition: ready for operation (used), CNC MACHINING CENTER with FADAL 88 HS CNC control TYPE: VMC 3016 HT / 904-1 MACHINE NO.: 9505866 YEAR OF MANUFACTURE: 1995 Equipment: - various tool retention bolts - coolant system with full enclosure - travel paths: longitudinal: 762 mm (x), transverse: 406 mm (y), vertical: 508 mm (z) - tool changer with 21 stations - CE compliance - documentation Iodpjxmg Swsfx Afiotn

Condition: used, Year of construction: 1999, x-travel 1.250 mm y-travel 880 mm z-travel 800 mm control TNC 430 Heidenhain turning speed range - main spindle max. 12.000 min/-1 power capacity - main spindel 15 / 10 kW max. Torque 500 Nm tool taper SK 40 table surface area 1.500 x 1.050 mm max. table load 2.500 kg number of T-slots 10 Isdjxmagnjpfx Afijtn T-slot - width 18 H7 mm T-slot - distance 100 mm number of toolpositions 60 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 315 mm max. tool weight 8 kg max. total weight 100 kg rapid traverse ( X / Y / Z ) 15 m/min feed speeds 10.000 mm/min total power requirement 29 kW weight of the machine ca. 16,0 t dimensions of the machine ca. 7,0 x 5,0 x 3,3 m CNC - Machining Center Vertical DECKEL MAHO - DMU 125 T

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, rotational speed (max.): 10,000 rpm, Travels: x = 762 mm, y = 406 mm, z = 508 mm 5 axes with trunnion. Rigid tapping, rotation and scaling, quick code, spindle orientation M19, high-speed machining, intuitive programming and advanced tool management, programmable coolant nozzle, coolant system, side tool changer 24 + 1 tools, chip auger system, Renishaw. Isdpsxltglsfx Afistn

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 0537, CNC: OSP-U100L X-axis: 1050 mm Y-axis: 560 mm Z-axis: 460 mm Itjdpfx Ajxlta Eofisn Table size: 1300 x 560 mm Number of tool pockets: 32 Spindle taper: BT50 Max spindle speed: 12,000 rpm Spindle motor power: 15 kW Machine dimensions: H=3200 x W=3000 x L=3400 mm Machine weight: 8,000 kg.

Condition: ready for operation (used), Year of construction: 2021, operating hours: 2,256 h, functionality: fully functional, travel distance X-axis: 710 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, table load: 250 kg, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 710 mm Travel Y-axis: 400 mm Travel Z-axis: 350 mm Table dimensions: 850 x 400 mm Max. table load: 250 kg Table height from floor: 850 mm Spindle speed: 12,000 rpm Spindle taper: BBT 30 Main spindle power: 13 kW Rapid traverse (X, Y, Z): 60 m/min Max. tool diameter: 68 mm Max. tool length: 200 mm Max. tool weight: 3.0 kg Tool change time: 0.9 s Max. number of tool stations: 20 MACHINE DETAILS Control: FANUC 0i-MF Dimensions (L x W x H): 2,100 x 2,600 x 2,700 mm Machine weight: 3,150 kg Iodpsxlf Nrsfx Afistn Operating hours Machining time: 2,256 h Run time: 3,557 h Control on: 24,690 h EQUIPMENT Automatic door Keyarrow chip conveyor

Condition: good (used), Year of construction: 2005, Used Victor Vcenter-70 Vertical Milling Center Min - Max Height Under Spindle : 150 - 660mm Traverses XYZ: 700 x 430 x 510mm Spindle Speed: 8000rpm Spindle Motor Power: 7.5kW Rapid Feed Rates: XYZ: 30 x 30 x 24m/minute Control: FANUC OiM Tool Change Capacity: 24 Stations Maximum Workpiece Size: 500kg Pallet Size: 800 x 460mm Number of Pallets: 2 Tool Size: DIN40 Description: Isdpfxexldrls Afietn Swarf conveyor, Coolant, Interlocked guards, Low Volt Light, Manuals, Twin Pallet

Condition: excellent (used), Year of construction: 2016, HAAS VF-2 Year: 2016 Table Size: 915 x 355mm Travels XYZ: 762 x 405 x 510mm Tool Change Capacity: 20 position Spindle Motor Power: 40Hp Spindle Speed: 8100rpm Spindle Taper: SK40 Maximum workpiece weight: 680kg Min - Max Height under Spindle: 102 - 610mm Machine Weight: 3800 Kg Accessories/options: 4.axis rotary table Tool holders Coolant tank Interlocked guards Isdpfx Afexiwftjistn Programmable Coolant Nozzle Swarf Auger USB Port Under power in our warehouse, possible to test it anytime!

Condition: ready for operation (used), Year of construction: 1996, Control Unit Brand SIEMENS Model Acramatic A21000 Main Drive Number of axis 3 Movement X-Axis Movement 750 Y-Axis Movement 500 Z-Axis Movement 400 Isdsxirk Dopfx Afijtn This 3-axis Cincinnati Milacron Arrow 750 was manufactured in 1996. A vertical machining centre, it offers robust construction and precision engineering for reliable performance. If you are looking to get high-quality milling capabilities, consider the Cincinnati Milacron Arrow 750 machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2013, operating hours: 29,083 h, General Data Machine weight 9500kg Control Unit Brand FANUC Main Drive Iodsxg Ui Ropfx Afiotn Spindle speed range 10000 Tool taper BT40 Number of axis 3 Movement X-Axis Movement 762 mm Y-Axis Movement 570 mm Z-Axis Movement 570 mm This 3-axis DOOSAN VC-510 was manufactured in 2013. It features a twin pallet vertical machining center with a table size of 2 x 860 x 570mm, a maximum workpiece height of 520mm, and a spindle speed of 10,000rpm. The machine includes a 40 tool ATC, X-axis travel of 762mm, Y-axis travel of 516mm, and Z-axis travel of 570mm. Consider the opportunity to buy this DOOSAN VC-510 vertical machining center. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2012, operating hours: 37,513 h, General Data Machine weight 9500 kg Main Drive Tool taper BT40 Number of axis 3 Itedpfxoxg Ui De Afien Movement X-Axis Movement 762 mm Y-Axis Movement 516 mm Z-Axis Movement 570 mm Tools Number of index 40 This 3-axis DOOSAN VC 510 was manufactured in 2012. It features a twin pallet vertical machining centre with a table size of 2 x 860 x 570mm, a maximum workpiece height of 520mm, and a spindle speed of 10,000rpm. It includes a 40 tool ATC, X-axis travel of 762mm, Y-axis travel of 516mm, and Z-axis travel of 570mm. Consider the opportunity to buy this DOOSAN VC 510 vertical machining centre. Contact us for more information. Application Types Milling

Condition: like new (used), Year of construction: 2022, functionality: fully functional, travel distance X-axis: 610 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 406 mm, workpiece weight (max.): 200 kg, table width: 500 mm, spindle speed (min.): 10,000 rpm, Equipment: chip conveyor, For sale: HAAS UMC-500 5-Axis Universal Machining Center Condition: Absolutely brand new machine. Only one part was produced for test machining. The equipment has been unused and stored for 2 years. Main technical specifications Travel: X-axis: 610 mm Iodpjxg Nd Nsfx Afijtn Y-axis: 406 mm Z-axis: 406 mm Table: Diameter: 500 mm Maximum workpiece weight: 200 kg 5-axis rotary/trunnion table (trunnion type) Spindle: Inline direct-drive 10,000 rpm 30 HP (22.4 kW) CAT 40 taper (40T) Through-spindle coolant: 300 psi (21 bar) Tool changer: 30 tool positions Side-mount, high speed Precision and compensation: Temperature compensation DWO/TCPC – Dynamic Work Offset and Tool Center Point Control Rigid Tapping Equipment and features: Haas NGC CNC control (FANUC compatible) 1 GB memory Ethernet connection, WiFi connectivity USB port, color 15” LCD display Early power-failure detection module Memory lock (keyswitch) Spindle coolant system Protective enclosure with doors Internal lighting Centralized lubrication system Top cover Measurement and calibration equipment: Renishaw WIPS wireless intuitive probing system (Haas Visual Programming System, macros, spindle orientation, coordinate rotation and scaling) Rotary-Axis calibration tool RJH remote jog handle with color display Chip and coolant systems: Coolant tank – 95 gallons (360 L) Initial fill with Blaser coolant emulsion Chip conveyor (belt type – CONVEYOR-H) High-pressure air system Documentation: Original machine documentation (in English) Application Haas UMC-500 is a compact yet powerful universal 5-axis machining center designed for the production of complex, multi-sided, and free-form surface parts. Suitable for simultaneous 5-axis machining as well as 3+2 machining, significantly reducing setup operations and ensuring high accuracy. If you have further questions, we are happy to assist.
