Condition: good (used), Year of construction: 1989, functionality: fully functional, Technical details x-travel 400 mm y-travel 390 mm z-travel 350 mm Control DIALOG4/CONTOUR 3 tool taper SK 40 spindle turning speed range 31 - 3150 U/min feed range 10 - 2000 mm/min weight of the machine ca. 1,7 t dimensions of the machine ca. 1.600 x 2.500 x 2.000 mm Additional information Kdodjyv Abvopfx Ahvsi CNC control DIALOG4/CONTOUR 3 Table: 700 x 480 mm rigid angle table Swivel-type vertical milling head Coolant tank

Condition: reconditioned (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, feed rate X-axis: 3,600 m/min, feed rate Y-axis: 3,600 m/min, feed rate Z-axis: 3,600 m/min, quill stroke: 80 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 40 rpm, rapid traverse X-axis: 4 m/min, rapid traverse Y-axis: 4 m/min, rapid traverse Z-axis: 4 m/min, table length: 530 mm, table width: 900 mm, rotational speed (max.): 4,000 rpm, rotational speed (min.): 40 rpm, table load: 450 kg, Equipment: rotational speed infinitely variable, The machine is designed and built to be very stable and robust. Thanks to its excellent accessibility, it is extremely user-friendly. The machine can also be moved manually using mechanical handwheels. CNC Path Control DECKEL Dialog 11 Easily programmable 3D path control with color graphic support, dialogue guidance for cycle input, contour path calculator, editor functions, clear program and tool management, and the possibility of parallel programming. Kjdpfsyn Dq Ijx Ahvodi Travel paths X / Y / Z: 560 / 500 / 450 mm Tool holder: SK40 DIN 69872 Clamping system: Hydromechanical clamping system SK40 with drawbar according to DIN 2080 or DIN 69872 Working spindle: Vertical and horizontal. Manually retractable quill in vertical direction 80 mm. Milling head: Manually swivels +/- 90° Speed range: 40–4000 rpm, geometrically stepped Direct-drive gearbox for maximum torque / milling performance at the working spindle Feed rate: 2–3600 mm/min, infinitely variable feed Rapid traverse: 4000 mm/min Angle table: 530 x 900 mm, max. load capacity 450 kg

Condition: used, Year of manufacture: 1980s Technical data: Travel X/Y/Z: 400 / 400 / 400 mm Tool holder: SK 40 Speed range: 40 - 4000 rpm Feed, stepless adjustable: 2 - 360 mm/min Rapid traverse: 4000 mm/min Swivel table: 700 x 460 mm, max. load 350 kg Tool changer: Number of tools: 20 Max. tool diameter: 80 mm Kdjdjyfrf Ispfx Ahvsi Max. tool length: 300 mm Max. tool weight: 6 kg Equipment: - Control: CNC path control Deckel Dialog 11 - Hydromechanical clamping system SK 40 with drawbar according to DIN 69872 - Vertical and horizontal working spindle - Milling head manually swivels +/- 90° - Geometrically stepped direct drive for maximum torque - Milling performance at the working spindle

Condition: good (used), Year of construction: 2008, functionality: fully functional, Milling machine Macmon M 434 NC Manufacturer: Macmon Type: 434 NC Control: Heidenhain TNC 128 Year of manufacture: 2008 Condition: used X-axis: 400 mm Y-axis: 250 mm Z-axis: 400 mm Clamping surface 600 x 320 mm Main drive: AC motor kW 3 Speed range: Vertical infinitely variable 30 - 6300 Horizontal stepless 0 - 4200 - Feed rate 0 - 10 m/min Tool holder ISO 40 Kdodpjxnpg Hsfx Ahvei Operating voltage 400 / 50 Volt / Hz Control voltage 24V Weight 1200 kg Scope of delivery - Documentation - Machine feet - Coolant system - Spindle guard - Machine light - HR410 Handwheel - Horizontal spindle Counterholder

Condition: used, Year of construction: 1990, x-travel 0500 mm y-travel 400 mm z-travel 400 mm table-size 680 x 380 mm CNC control 432 PHILIPS feed range 1-3000 mm/min rapid traverse 6 m/min Tool bore ISO 40 turning speed range 20 - 3150 U/min main drive DC 5 kW milling head -swivable +/- 90 ° total power requirement 12 kW Kedpsu Rt Nrofx Ahvedi weight of the machine ca. 1,2 to dimensions of the machine ca. 2,5 x 2 x 2 m CNC milling machine with 432 Control.

Condition: used, Year of construction: 1987, - Lid Contour 3 CNC control - Sliding vertical milling head with extendable spindle - counter bearing for long milling arbors - Hydraulic tool clamp - Automatic speed gearbox - Automatic clamping in X/Y/Z axes - Automatic central lubrication - coolant device - direct path measurement - Collision protection clutch in Z/Y axes - year of construction 1987 Technical data Working range: - X-axis (longitudinal): 485 mm - Y-axis (transverse): 385 mm - Z-axis (vertical): 380 mm - Vertical quill stroke: 80 mm - Vertical milling head can be moved on headstock: 150 mm Main drive: - Motor: pole-changing three-phase AC brake motor and manual gearbox with clockwise/anticlockwise rotation - Power: 3.7 / 4.4 kW - 18 working spindle speeds: 50 - 2500 rpm - Step change: 1.25 - Tool holder: SK40 (M16) - Tool clamp: hydraulic Feed drive: - X-axis: 1 DC motor - Y- and Z-axis: 1 DC motor - All axes: ball screws - Feed speed programmable: 10 - 1000 mm/min - Rapid traverse X-/Y-/Z-axis: 2000 mm/min Universal table: - Number of T-slots: 7 - T-slot width: 14/H7 mm - T-slot spacing: 63 mm - Center bore Ø/depth: 63H6 / 8 - Distance from table center to screw-on surface: 260 mm - Max. Passage height (vertical milling spindle/table surface): 490 mm - Permissible load: 300 kg - Weight: 230 kg - Rotation range in horizontal position (axis C): 360 ° - Tilt range (axis A): +450 / -150 ° Kdjdpfx Aheu Awlzsvoi - Pivoting range (axis B): ± 450 ° - Measuring range with direct digital display: Resolution 360000 x 0.001 ° - Reduction ratios: 60:1 / 120:1 / 240:1 Installation: - Space requirement with safety area: approx. 2.3 x 2.5 m - Operating voltage: 400 V / 50 Hz - Total connected load: 7.5 kW / 9.5 kVA - Machine weight: approx. 1830 kg - Floor load: 3000 kg/m²

Condition: good (used), Stock number: 2888 Make: Hermle Kedpfeub Rxcjx Ahvedi Machine number: Type / Model: FU 801 Travel x-y-z: 400 - 150 - 350 mm Manual travel: 430 - 160 - 370 mm Table: 800 x 220 mm Speed range: 50 to 3,150 rpm Spindle holder: SK 40 Feed rates: 4 to 1,100 mm/min Rapid traverse: 8 to 3,300 mm/min Connection: Accessories/equipment: Coolant device; counter bearing, dividing head (integrated), various holders, various horizontal spindles Condition: good, Z-axis only works with manual adjustment Weight: 0.8 t Dimensions: 2,300 x 1,700 x 2,400 mm

Condition: used, Year of construction: 1985, x-travel 485 mm Kdsdpetqqllsfx Ahvsi y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Year of construction: 1983, condition: used, Universal tool milling machine Hermle Type UWF 700 year of manufacture 1983 table 700 x 285 mm travel X / Y Z 400 / 290 / 380 mm mounting SK 40 spindle speed 40 - 2000 rpm quill stroke 63 mm drive power 2,2 kw Digital display counterholder weight 1500 kg Kdodpslqx Azofx Ahvoi

Condition: good (used), Year of construction: 1989, Conventional Universal Milling Machine, travel X/Y/Z 400/300/400 mm, table size 320x750xmm, 18 speed 40-2000 rpm, motor 2,2 KW, spindle ISO 40, drilling quill 60 mm, tilting head +/- 90°, dimensions 1220x1810x1710 mm, ca. 2020 kgs; accessoires: horizontal milling device, shaping head Kedeip N Rgopfx Ahvsdi

Condition: refurbished (used), Year of construction: 1985, General overhauled 2022 CNC control Heidenhain TNC 124 new new wiring control cabinet, new drive technology Kdodpfx Aeh Uqh Nehvoi dimensions (L x W x H) 2170 x 2360 x 1852 mm total weight approx. 1900 kg working range X-axis: 500 mm working range Y-axis: 400 mm working range Z-axis: 400 mm rigid angle table: 810 x 400 mm working spindle tool holder: ISO 40 18 spindle speeds: 50 - 2500 rpm feed range X- and Z-axis: 1 - 750 mm/min feed range Y-axis: 1 - 500 mm/min rapid traverse X and Z axis: 1200 mm/min rapid traverse Y: 600 mm/min quill stroke: 80 mm drive power: 6,63 KW

Condition: used, Year of construction: 1986, machine/vehicle number: 2204-0929, x-travel:560 mm y-travel:500 mm z-travel:450 / 390 mm quill stroke:80 mm feed:2 - 3600 mm/min table surface area:800 x 460 mm spindle turning speed range:40 - 4000 U/min Kdjdpfx Aocxxriehvoi spindle taper ISO:ST40 spindle head swivable left - right:+/- 90 ° control:Contour 2 total power requirement:4,0 kW weight of the machine ca.:2,8 t dimensions of the machine ca.:2,0 x 2,5 x 2,2 m The Deckel FP4 A Universal Milling Machine - CNC - Spilndle Head can be swiveled 90 ° (Right or left) - Angular Fixed Work Table: 800 x 460 mm - Hydralic Tool clamping system SK40 with Pull studs DIN 2080 or DIN 69872 - Portable Handheld operating unit for easy control of machine - 4.0 kw Motor for Main Spindle. - Central Lubrication and Coolant system, Seperate Power cabin, Chip tray

Year of construction: 1989, condition: used, machine/vehicle number: 2204-1736, table mounting size: 460 x 800 mm movement x: 485 mm movement y: 385 mm movement z: 380 mm tailstock stroke: von Hand ca. 70 mm spindle turning speed range: 50 - 3150 rpm carriages continuously adjustable: 2 - 1000 mm/min rapid move: 2 m/min electrical connection: 3,7/4,4 kW Kdsdpfeclli Uex Ahvsi space needed: 2100 x 1650 x 1730 mm weight: 1850 kg
