Condition: good (used), Year of construction: 1989, functionality: fully functional, total width: 3,560 mm, total length: 3,300 mm, total height: 2,210 mm, overall weight: 5,000 kg, TSCHUDIN HTG 52 CNC – CNC External Cylindrical Grinding Machine CNC-controlled external cylindrical grinding machine from the Swiss manufacturer TSCHUDIN, based in Grenchen. The machine is equipped with a Marposs E14 CNC control, a Marposs E38 measuring and monitoring unit, and a Heldt & Rossi servo drive control. The equipment includes an external cylindrical grinding spindle, a workpiece spindle, a tailstock, and a coolant supply. The machine has various clamping and holding devices, as well as a separate control cabinet. Bjdj Ahyxiepfx Aknslp Technical data: - Manufacturer: TSCHUDIN, Grenchen (Switzerland) - Model: HTG 52 CNC - Type designation: 365 - Machine type: CNC external cylindrical grinding machine - CNC control: Marposs E14 - Measuring and monitoring unit: Marposs E38 - Servo drive control: Heldt & Rossi SM 807 DC - Grinding wheel diameter: 500 mm (identification of the installed wheel) - Mains connection: 3 × 380 V - Frequency: 50 Hz - Current consumption: 19.7 A - Power rating according to the nameplate: 13 kW Equipment: - CNC control Marposs E14 - Marposs E38 measuring and monitoring unit - Heldt & Rossi servo drive control - External cylindrical grinding spindle with grinding wheel - Workpiece spindle - Tailstock - Measuring device in the work area - Coolant supply - Clamping and holding devices - Separate control cabinet - Bellows covers - Operating and adjustment devices Note: The information is based on the available nameplates and the visible machine components. Year of manufacture, center distance, center height, travel distances, machine weight, and functional condition are not confirmed. Subject to errors, changes, and prior sale.

Condition: used, Year of construction: 2010, 2 CNC cylindrical grinding machines Manufacturer: Junker Type: Jumat 3000/50S Year of manufacture: 2010 Control system: Siemens Beds Agr H Rspfx Aknslp The technical specifications can be found in the attachment (images 11–13). Accessories, tools and clamping devices shown in the images are only included in the scope of delivery if this is explicitly stated in the additional information.

Condition: like new (used), Year of construction: 2022, operating hours: 40 h, functionality: fully functional, total width: 1,600 mm, total length: 3,700 mm, total height: 2,200 mm, type of input current: three-phase, spindle speed (max.): 2,406 rpm, grinding spindle motor power: 22,000 W, overall weight: 12,000 kg, input frequency: 60 Hz, input voltage: 480 V, space requirement height: 2,200 mm, Very Low Hours, Hardly Ever Used- Specifications: Workpiece diameter: max. 100 mm (3.94") Workpiece diameter: min. 2 mm (.08") Workpiece length with plunge grinding: max. 195 mm (7.68") Grinding wheel diameter: max. 500 mm (19.69") Blodpfxo Agptyo Aknsp Grinding wheel diameter: min. 380 mm (14.96") Maximum wear of the grinding wheel - Straight plunge cut: 60 mm in radius (2.36") - Inclined plunge cut: 25 mm in radius (0.98") Width: max. 200 mm (7.87") Bore: 305 mm (12") Circumferential speed of the Grinding wheel standard: max. 63 m/s Regulating wheel diameter: max. 300 mm (11.81") Width: max. 200 mm (7.87") Bore: 203 mm (7.99")Grinding wheel drive power standard: 22 kW Unit: Metric - Provision of the grinding wheel and regulating wheel unit: X1/X2 axis - Infeed axis of the grinding wheel dressing tool: Z1 axis - Longitudinal feed of the regulating wheel dresser: W2 axis - Speed control of the grinding wheels: SP1 spindle - Speed control of the regulating wheel: SP2 spindle 3 operating modes: - Set-up - Grinding in single operating mode (only with plunge grinding) - Automatic grinding - cycle operating mode Noise emission at the machine: Automatic loading - Basic machine: approx. 12,000 kg (approx. 26,455 lbs.) - Dimensions of the basic machine (without control cabinet) Length: 3,700 mm (146") Width: 1,600 mm (63") Height: 2,200 mm (87") Equipped with: Grinding Wheel Balancing System, Regulating Spindle Swivelling, Height Adjustment of Work Rest Holder-NC axes, Auxiliary for Grinding Wheel Exchange, Second Operating Panel, Loading Unit, Loading System for Manual Loading, Unloading System with Integrated Measuring Unit, Workpiece Dependent Accessories, Compact Filter Unit

Condition: good (used), Machine Data Type: ESO 400 Design: Centerless, with regulating and grinding wheel Overhaul: July 2003 (according to the sign) Truing: For regulating and grinding wheel Blsdpfx Akj Agpflenjp Workpiece support: Between regulating wheel and grinding wheel Extraction: Donaldson Torit DCE extraction system, installed Enclosure: Safety cabin with viewing windows Control cabinet: Separate control cabinet Equipment and scope of supply Donaldson Torit DCE extraction system Separate control cabinet Truing devices for regulating and grinding wheel Accessories as shown in the photos Donaldson Torit DCE extraction system, separate control cabinet, and accessories as shown in the photos. Technical specifications are subject to change without notice. Errors and prior sale are reserved. The characteristics and scope of supply agreed upon in the purchase contract shall be binding.

Condition: used, center height: 80 mm, center width: 400 mm, grinding diameter: 80 mm, Cylindrical Grinding Machine Manufacturer: STUDER/GSN Model: S20-0C Overhauled: 2016 Control System: SIEMENS Technical Details: Bjdpfxj Agcibo Aknjlp Center height: 80 mm Distance between centers: 400 mm Grinding diameter: 80 mm Max. workpiece weight between centers: 20 kg Grinding wheel dimensions: 300 x 30 mm Workhead spindle speed: 60 – 1,200 rpm Condition: Used The machine was completely overhauled in 2016 and has since been used in a training workshop. Accessories, tools, and work-holding devices shown are included in the scope of delivery only if explicitly stated in the additional information. Subject to changes and errors in the technical data and specifications; prior sale reserved!

Condition: ready for operation (used), functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS GENERAL DATA Machine type: Cylindrical grinding machine Manufacturer: Heid MSO GRINDING DATA Center height above table: approx. 150 mm Grinding wheel diameter: 250 mm Blsdpo Ad Eq Refx Aknsp ELECTRICAL DATA Operating voltage: 380 V Control voltage: 22 V Rated current: 35 A MACHINE DETAILS DIMENSIONS AND WEIGHT Length: 2,000 mm Width: 1,800 mm Height: 2,000 mm Weight: 1,000 kg

Condition: used, Year of construction: 1984, overall weight: 1,500 kg, capacity: 400 x 200 mm device for indoor use. Bsdps Abbi Refx Aknjlp

Condition: used, Year of construction: 2000, Schaudt PS51 U600 Grinding Cell comprising Schaudt PS51 U600 grinding machine (2001) refubrished 2013 600mm clamping length 600mm maximum grinding diameter 360mm maximum grindable workpiece diameter 180mm centre distance 1,080mm centre height above machine base 300kg maximum workpiece weight (between centres) Axis travel 430mm X-Axis (Grinding Slide) Axis speed X-Axis15,000 mm/min Z-Axis15,000 mm/min Workhead 1 1,000rpm speed range 48Nm drive torque MK4 work centre adapter Grinding Unit 22 kW drive power 30 50 m/s grinding wheel peripheral speed 762 mm maximum grinding wheel diameter 315 mm maximum grinding wheel width Bedoz Stmdspfx Aknolp 304.8 mm grinding wheel bore 440 kg maximum Grinding wheel weight Felsomat FZ350 infeed and outfeed system (2000) Crane (1999)

Condition: used, machine/vehicle number: 41225, with digital display, type: CHECKOMATIC 1200, max. grinding length: 420 mm, center height: 150 mm, with pivoting internal grinding spindle, belt filter system, and coolant system. Bedpfsz Nhqlox Aknjlp

Condition: used, Cylindrical Grinding Machine TSCHUDIN type HTG 400 Between points: 400 mm Centre height: 100 mm Cone: CM4 Bjdpfx Aoz I Aw Neknslp Spindle speed: from 70 to 500 RPM Max table travel: 420 mm Table orientation at 15° Grinding wheel: Ø 300 mm Retractable tailstock CM3 Machine rebuilt by REWITECH SA (Switzerland) in 1995 Equipped with one settling tank PHILIPS Voltage: 380 V Dimensions (L x W x H): 2000 x 1400 x 1600 mm Weight: approx 1,5 T

Condition: used, total width: 1,700 mm, total length: 3,100 mm, total height: 1,600 mm, Year of manufacture: 1972 Bodpszy H A Asfx Aknjlp Colour: Green Empty weight: 2.500 kg Price: On request - Year: 1972 - Serial number: 1011/447 - Drive system: Conventional - Grinder type: Internal and external grinding machine - Drive system: Hydraulic - Power [kW]: 6.5 - Distance between centres [mm]: 1000 - Centre height [mm]: 175 - Grinding diameter [mm]: 350 - Max. grinding wheel diameter [mm]: 400 - Max. grinding wheel thickness [mm]: 50 - X-axis travel [mm]: 260 - Z-axis travel [mm]: 1300 - Swivel range [°]: 270 - Table width [mm]: 1590 - Table depth [mm]: 140 - Main spindle power [kW]: 3 - Min. spindle speed [rpm]: 1500 - Max. spindle speed [rpm]: 2200 - Transport dimensions: 3100mm x 1700mm x 1600mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 155847, Round grinding machine Knuth RSM 1000, year of manufacture 2012, fully functional, with internal grinding attachment. Condition: fully functional Year of manufacture: 2012 Location: West Saxony Price: on request Technical data: Manufacturer: Knuth Werkzeugmaschinen GmbH Type: RSM 1000 Serial number: 155847 Power: 9.5 kW Grinding length: 1,000 mm Grinding diameter: up to 320 mm Center height: 180 mm Dimensions: L 3,600 × W 1,650 × H 1,800 mm Machine weight: approx. 3.7 t Equipment: Digital 2-axis position display (DRO) Internal grinding attachment (standard) Bodpozyltmjfx Aknslp Steady rest (standard equipment) Central lubrication system Coolant system Description: For sale is a Knuth RSM 1000 round grinding machine, manufactured in 2012, with a digital 2-axis position display. With a grinding length of 1,000 mm and a grinding diameter of up to 320 mm, the machine is suitable for both single-part machining and small-batch production. It comes standard with an internal grinding attachment and a steady rest for machining long workpieces. The machine is fully functional. Inspection and test run possible at the location in West Saxony by appointment. Price: on request Other machines available from site liquidation Takeover of the location negotiable.

Condition: excellent (used), Year of construction: 2006, functionality: unexamined, overall weight: 8,000 kg, JUNKERS FLUTEMAT: a CNC machine for highly flexible groove grinding. The FLUTEMAT is the perfect machine for creating grooves in various tool types. For example: • Application: Grinding 3 or 4 chip and flute grooves in HSS taps, milling cutters, and reamers. • Workpiece diameter: Diameter from 2 to 16 mm. • Clamping system: The thread tool is precisely fixed in a square clamping device and the tailstock center. • In-process dressing: A CNC-controlled dressing unit is located directly behind the grinding spindle. • Enormous speed: a cycle time of approx. 75 seconds for an M12 HSS tap. • Design: The machine features a vibration-damping machine bed made of mineral cast. • Control: Modern control technology via the company's own Erwin Junker Operator Panel (EJ-OP). • Grinding media: Extremely durable CBN or diamond grinding wheels are used. • Manufacturer: Erwin Junker Maschinenfabrik GmbH • Model: FLUTEMAT • Year of manufacture: e.g. 2006 • Control: CNC Junker Operator Panel, e.g. Siemens Sinumerik • Workpiece diameter range: approx. 2 – 16 mm • Total workpiece length: Max. e.g. 150 mm • Number of grooves: 3- or 4-groove tools (straight and helical grooves) • Grinding spindle drive: e.g. 7.5 kW / 11 kW • Grinding media: Designed for CBN and diamond grinding wheels • Dressing unit: Integrated, CNC-controlled in-process dressing unit • Machine bed: Vibration-damping mineral cast • Included accessories: Oil mist extraction, • Coolant system • Robot cell with various clamping tables, • Various grinding wheel flanges, Bodpfxjzya Hhs Aknslp • Documentation/manuals. For more information? For example, a VIDEO is available upon request by email.

Condition: excellent (used), Year of construction: 1963, Maximum height: 100 mm Distance between centers: 500 mm Grinding wheel diameter: 300 mm Maximum grinding wheel speed: 2,825 min-1 Grinding head can be rotated 90° to the left and right Maximum workpiece speed: 750 min-1 Spindle taper MK 4 Tailstock 3-jaw grinding chuck 125 mm Faceplate 160 mm ER 40 collet chuck with 28-piece collet set Fixed center Grinding wheel flange with grinding wheel Blsdezxqt Nspfx Aknop Wet grinding device

Condition: used, significantly increased accessories and three flanges for the SCHAUDT cylindrical grinding machine. Blodpfx Akozwxulonop

Condition: good (used), Year of construction: 1970, functionality: fully functional, Data : Tip width 300 mm Tip height 150 mm External grinding spindle 4.0 kW Grinding wheel max. 400 x 80 x 127 mm Spindle cone MK4 Workpiece headstock 0.55 kW Bsdpfx Aezu Incsknjlp Workpiece speeds 30 - 450 rpm Internal grinding spindle 1.5 kW

Condition: used, Year of construction: 1980, centre distance 900 mm 440 weight of the machine ca. 3 t Bledpfxjztfzko Aknjp

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Maximum grinding diameter: 200mm Maximum grinding length: 340mm Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Bljdpozrt Ipjfx Aknsp Coolant system Wheel guard Machine lighting

Condition: used, rand: DANOBAT Model: RT 1200 Bodpszqrmzsfx Aknelp Useful support surface 1200 x 450 mm Useful grinding surface (100 mm wheel) 1200 x 600 Useful grinding surface (50 mm wheel) 1200 x 550 Longitudinal travel X axis 1300 mm. Transverse travel Y axis 500 mm

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 500 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 500 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 4,600 kg, Demonstration CNC cylindrical grinding machine with automation setup Brand OKAMOTO Model OGM-350 P NCIII Year of manufacture 2020 Control: Fanuc Oi Model D Operating hours: approx. 200 hours Technical specifications Maximum swing diameter: 320 mm Maximum distance between centers: 500 mm Maximum workpiece diameter to be ground: 300 mm Maximum workpiece weight between centers: 150 kg Maximum workpiece weight: flange + chuck + workpiece: 40 kg Grinding wheel: Diameter x width x bore: 455 x 75 x 127 mm Wheel speed: Continuously variable Circumferential speed: 45 m/sec Grinding headstock (x-axis) Maximum travel: 300 Swivel angle: Non-swivel Workpiece table (z-axis) Travel: 870 mm Swivel angle: 0 – 10° Bljdpjzn U S Ijfx Aknep Workhead Fixed/Live Center Design MK 4 Taper Chuck Spindle Bore Diameter 20 mm Spindle Speed ​​10 – 500 rpm Swivel Angle: Non-Swivel Tailstock Tailstock Type: Manual Fine Taper Adjustment Quill Travel 30 mm MK 4 Taper Chuck Drive Power Grinding Wheel Drive 5.5 kW Total Power 20 kVA Dimensions/Weight Length x Width x Height approx. 3400 x 2330 x 1950 mm Machine Weight approx. 4,600 kg Standard Equipment: 2 Carbide Centers Full FANUC Keyboard with Radius Compensation for Creating ISO Programs Workshop Programming: Graphic Software for Grinding and Dressing Cycles with Teach-in Function GAP Eliminator Shoulder Positioning Constant Table coolant flush 3 color LED lamp Documentation Leveling screws and support plates Operating tool set Accessories Automation preparation Automatic door Automation interface Grinding wheel guard fully open when door is open Miscellaneous Signal lamp Tailstock with electric quill retraction 1 flange 1 grinding wheel Options upon request: Paper belt filter on request Clamping devices on request Commissioning and training on request (Commissioning by Okamoto is required for warranty purposes) Transport on request

Condition: used, Year of construction: 2005, Junker cylindrical grinding machine, type EJ 10 Bsdpeznx Hcjfx Aknjlp Year of manufacture: 2005 Control system: Siemens 810 Distance between centers: 150 mm Center height: 100 mm Maximum workpiece weight: 5 kg Maximum grinding wheel diameter: 400 mm Maximum grinding wheel width: 63 mm Grinding wheel bore: JUNKER spindle bore 27 mm This offer is exclusively aimed at business operators within the meaning of §14 of the German Civil Code (BGB).

Condition: ready for operation (used), Year of construction: 1962, functionality: fully functional, type of input current: three-phase, overall weight: 1,500 kg, input voltage: 380 V, Cylindrical roll grinder, VEB Schleifmaschinenwerk Berlin (WMW), type SI 40×70, manufactured in 1962 (factory number 1383/62). The machine is complete, with the original control panel (ON/OFF/STOP), and is in working condition. It can be inspected and tested on-site before purchase. Technical specifications: Type / construction size: SI 40×70 Factory number / year of manufacture: 1383/62 Total weight: 1.5 t Current circuit: SI 40-8DT Wiring diagram: SI 41-002 Type of current: 3-phase alternating current (3~) Frequency: 50 Hz Operating voltage (input): 380 V Distribution voltage: 220 V Connected power: 2.8 kW Slow-blow fuse: 20 A Manufacturer: WMW / VEB Schleifmaschinenwerk Berlin – a German brand known for its robust, industrial-grade cylindrical grinders from that era. Blodpfx Akeznu Trsnop Transportation throughout Europe is available upon agreement. We provide a VAT invoice or receipt.

Condition: used, Year of construction: 2010, functionality: fully functional, Rolling machine with accessories. Blsdpfxezg Hlwe Aknop

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 632054, There are several machines of the same type/process available. Loading varies – both gantry and robot systems are used. Bjdpfozfwnaox Aknslp --- (Please provide us with your offer price.) Sales only within Europe, including Turkey. Price excludes packaging; delivery condition: FCA (machine location). ===== Technical data can be found in the attached handout. Any warranty claims are excluded. We do not guarantee the accuracy of the technical data and year of manufacture, the completeness of accessories and tool equipment, or compliance with all safety and environmental protection requirements mentioned in the accident prevention regulations. No sales to private individuals.

Condition: excellent (used), Year of construction: 2001, Description to follow! Blodpfx Ajzd E Tzeknep
