Christel

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 403 6274, overall weight: 297 kg, Dimensions: Machine width: approx. 700 mm Machine depth: approx. 1,350 mm Machine height: approx. 1,250 mm Weight: approx. 250 kg Cutting angle 45 degrees Tools used: All milling and cutting tools must meet the DIN EN 847-1 standard and have an appropriate working speed to the speed of the milling cutter motors. Milling cutter: Ø 150x30x3.0 32 teeth Cutting disc: Ø 300x30x2.6 96 teeth GLA 403 USER MANUAL Copyright  by FM ROTOX Sp. z o. o. Page: 14 Processed material: PVC glazing beads: Profile length: min. 200mm (depending on the length bumper) Profile height: min. 5mm max. 50mm Profile width: min. 10mm Ljdjwhpp Rspfx Af Eoru max. 50mm Tool pressure: Pneumatic Electrical part: Electrical connection: 400V, 50Hz (AC) Power consumption: 2.2kW Fuse: 16A (slow) Saw motors: 230/400V; 4.0/2.3A 1.1kW; 50Hz; 2860 1/min Pneumatics: Working pressure: 5-6 bar Limit pressure: min. 5 bar (also during operation) max. 6 bar Air consumption: approx. 15 l/min / saw run-up Tip: NW Ø 9mm Permitted temperature during operation: min. 15°C and max. 40°C

Condition: as good as new (ex-display), Year of construction: 2024, Pneumatic Glazing Bead Saw Type GLSP-200N-AV Pneumatic Automatic saw feeding Pneumatic work piece clamping Adjustable table height 2 x 45° motors Accessories: HM Saw blade 200 x 2.2 x 32mm HSS Saw blade 103 x 2.0 x 32mm Z=60/45° Right HSS Saw blades 103 x 2.0 x 32mm Z=60/45° Left Glazing Bead Simulation- System With feed cylinder, 1 Revolver stop with Lodpfeuydgsx Af Eoru 16 stops and 4 clamping cylinders Fixtures for 2 Glazing Beads, support And leg adjustable for simulation Exhaust support D=80mm

Year of construction: 2018, condition: as good as new (ex-display), Glazing Bead Saw GLSM-200E Manual saw feeding Pneumatic work piece clamping (4) Adjustable table height Adjustable table height Lsdpfxjuxxxs Af Eeru 2 x 45° motors Accessories: HM Saw blade 200 x 2.2 x 30mm HM Saw blades 103 x 2.0 x 30mm Z=60/45° Left HM Saw blades 103 x 2.1 x 30mm Z=60/45° right Variable measuring stick 1.5m Variable measuring stick 3.0m Support for measuring stops 3.0m
