Condition: good (used), Year of construction: 1994, Pressure: 250 t Djdez Iyy Ijpfx Al Aoku Throat depth: 360 mm Table size: 1250 x 630 mm Table diameter: 250 mm Ram clamping surface: 850 x 450 mm Installation height: 800 mm Piston stroke: up to 500 mm Piston diameter: 400/360 mm Ram speed downward: 200 mm/sec Ram speed upward: 110 mm/sec Total power requirement: 20.5 kW Machine weight approx.: 8 t

Condition: good (used), Year of construction: 1975, Pressure: 250 t Throat: 400 mm Stroke: 30...140 mm Table size: 1000 x 750 mm Passage opening in table: 360 x 400 mm Ram area: 630 x 500 mm Dkjdpfx Alsz Iyyzj Aju Ram adjustment: 110 mm Total power requirement: 18 kW Machine weight approx.: 16 t

Condition: used, Year of construction: 2000, pressing force: 1,600 t, total length: 6,000 mm, total width: 3,000 mm, total height: 8,000 mm, overall weight: 200,000 kg, Press force: 16,000 kN Max. ram stroke: 1,700 mm Max. opening between table and ram: approx. 2,450 mm Min. opening: 770 mm Ram plate: 4,500 × 2,500 mm Table size: 4,500 × 2,500 mm Rapid traverse: 350 mm/s Working speed at 66% press force: 23 mm/s Working speed at 100% press force: 13 mm/s Max. return speed: 220 mm/s Max. retraction force: 1,600 kN Ram cushion: Force: 2,000 kN Stroke: 150 mm Pressure plate: 3,650 × 1,580 mm Table cushion: Force: 2 × 1,000 kN or 3 × 500 kN Stroke: 300 mm Pressure plate: 1,550 × 700 mm Drive: Main motors: 2 × 132 kW Motor filter unit: 4 kW Motor speed: 1,500 rpm Suitable for demanding forming, deep drawing, and pressing operations with large tools and high press forces. Dimensions (LxWxH) approx.: 6000 x 3000 x 8000 mm Weight approx.: 200,000 kg Dedpfoz Htalex Al Asku Pressing force max.: 1,600 t Year of construction: 2,000 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: like new (used), Year of construction: 2022, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, pressing force: 100 t, stroke length: 500 mm, operating speed: 400 mm/s, reverse speed: 450 mm/s, table width: 1,250 mm, table length: 630 mm, table height: 860 mm, throat depth: 360 mm, ram plate width: 850 mm, ram plate length: 450 mm, distance table to ram: 800 mm, retraction force: 1.6 t, total length: 2,300 mm, total width: 1,865 mm, total height: 3,650 mm, overall weight: 7,000 kg, year of last overhaul: 2026, controller manufacturer: SIEMENS, Equipment: CE marking, documentation/manual, safety light barrier, Hydraulic C-frame press ZEULENRODA | 100t | Retrofit system from 2026 with CE conformity + manufacturer's warranty --3 units available | short delivery time-- HIGHLIGHTS Dkedpfx Ajz Hcz Ssl Aeu - Press frame in steel welded construction for maximum stability and rigidity - Press force 1,000 kN | adjustable based on stroke and pressure - Clamping area, table 1250 x 630 mm - Ram stroke 500 mm - infinitely adjustable - Ram plate with anti-rotation protection and guided by columns - Rapid traverse and short stroke function - Active oil cooling - Hydraulic ball-type quick-release couplings for safe and fast tool changes - Protection on the operator side via light curtain, on the side and rear via safety guard - SIEMENS control + touch panel - Interface for automation - Comfortable operation with BWS-1 cycle + BWS-2 cycle - Remote maintenance - CE conformity + manufacturer's warranty Ram column guidance: - Two diagonally arranged guide columns each. They also serve to prevent the ram plate from twisting. Hydraulic equipment: - Oil tank, hydraulic control / pump completely installed and ready for operation with all required pipelines, pumps and valves as well as the control units. - Electronic stroke measurement system - Stroke control: stroke-dependent - pressure-dependent - stroke-pressure-dependent - Option for setting a press time of 0 ... 10 minutes Safety: - BWS / light curtain on the operator side - Transparent protective elements on the sides, movable - Retraction lock (interlock) - Hydraulic and electrical safety devices in accordance with DIN EN 16092-3 Control / Operation: - SIEMENS - Touch panel control unit as a lift console (height adjustable) - Standing two-hand control unit - 100 storable tool data sets - Transfer of stroke parameters using the teach-in method - Various password levels - ... Operating modes of the press - Off - Setup / Two-hand - Single stroke / Two-hand - Single stroke BWS 1 cycle / 2 cycle - Master / Combined operation / Automation Tool control / protection - 6 x tool cams (24V / 2A outputs), freely programmable - Electronic tool protection with 8 inputs, freely configurable Remote maintenance (eWON Cosy) Service & Support ZEULENRODA PRESSTECHNIK

Condition: new, Year of construction: 2026, machine/vehicle number: ST-80, functionality: fully functional, pressing force: 80 t, stroke length: 450 mm, operating speed: 4 mm/s, reverse speed: 5 mm/s, table width: 1,000 mm, table length: 1,750 mm, table height: 800 mm, total length: 2,000 mm, total width: 1,750 mm, total height: 1,750 mm, overall weight: 1,700 kg, Equipment: CE marking, documentation/manual, Model: ST-80 STANDARD DESCRIPTION: We have designed the ST series of motorized hydraulic presses with a movable gantry and adjustable ram, offering a range of three different capacities from 80 to 150 tons. Specifically designed for straightening welded structures, as well as plates cut by oxy-fuel or laser. The design facilitates easy loading and unloading of large volumes: parts, plates, or structures. It provides access to various pressure points without having to reposition the workpiece, thanks to the lateral movement of the cylinder and the longitudinal travel of the gantry. STRUCTURE AND TABLES: The ST series hydraulic presses feature an electro-welded frame manufactured exclusively from S355JR steel. The frame is stress-relieved and precision-machined after welding to ensure perfect parallelism and accuracy. All structural calculations and design are performed using finite element software. As a result, we always guarantee our high standards of precision and quality. The gantry provides longitudinal movement. Dkjdpfx Ajz E Hb Hjl Aou CYLINDER AND HYDRAULIC UNIT: Double-acting cylinder with honed barrel, chrome-plated piston, and maintenance-free anti-wear guides. Cylinder operation via a lever hydraulic valve. Equipped with a removable pressure pad to protect the piston. Motorized hydraulic unit with two speeds and automatic switch-off of the fast approach speed at working pressure, including a pressure relief valve. ELECTRICAL SYSTEM AND SAFETY: Electrical circuit includes a motor protection switch with emergency stop. Supplied with a glycerin-filled pressure gauge (reading in tons) and hydraulic oil. Complies with all essential health and safety requirements according to CE standards. Delivered with an operating manual. MODEL ST-80 Capacity (t) 80 Motor Power (kW) 3 Working Speed (mm/s) 3.8 Approach Speed (mm/s) -- Return Speed (mm/s) 4.7 Max. Pressure (bar) 315 Piston Stroke – J (mm) 450 Lower Table (mm) 1,000 x 1,750 Ram Travel – C (mm) 730 Gantry Travel – D (mm) 1,100 Front Opening – A (mm) 1,050 Vertical Opening – B (mm) 500 Working Height – E (mm) 800 Overall Width – G (mm) 2,000 Overall Depth – H (mm) 1,750 Overall Height – I (mm) 2,250 Weight (kg) 1,700

Condition: good (used), Year of construction: 1983, Offer 26245 Technical data: - max. pressing force 100 t - max. ram stroke approx. 500 mm - stroke speed 25 mm/s - return speed 125 mm/min - installation height approx. 800 mm - overhang to the center of the ram 380 mm - ram clamping surface 530 x 400 mm - ram clamping pin 40 mm Dkjdpfx Alez A Az Re Aou - table size 750 x 560 mm - table bore / through hole in the table 200 mm - table height above floor 720 mm - oil filling volume approx. 200 l - drive 400 V / 11 kW - space requirement approx. W 1150 x H 2980 x D 1850 mm - weight approx. 4600 kg

Condition: good (used), Year of construction: 1981, machine/vehicle number: 027-006-20, Offer 26244 Technical data: - Max. pressing force 63 t - Max. ram stroke 500 mm - Stroke speed 200 mm/sec - Return speed 400 m/min - Installation height 800 mm - Overhang to center of ram 360 mm - Ram clamping surface 530 x 460 mm - Ram clamping pin 40 mm Dsdpfoz A Axvjx Al Aeku - Table size 750 x 560 mm - Table bore / through hole 180 mm - Table height above floor 700 mm - Oil capacity (approx.) 300 l - Drive 380 V / 11 kW - Space requirement (approx.) W 1150 x H 3100 x D 1750 mm - Weight (approx.) 4300 kg

Condition: used, Year of construction: 1997, Press force: 40 t Stroke: 620 mm Throat depth: 280 mm Shut height (stroke up): 830 mm Table area: 620 x 520 mm Table opening: 150 mm Table height above floor: 600 mm Ram area: 150 mm Downstroke speed: 120 mm/s Upstroke speed: 30 - 450 mm/s Dsdpjzypmwjfx Al Asku

Condition: used, Year of construction: 1987, Pressing force: 65 t Dkodpfxezyl Dfe Al Aju Stroke: 1100 mm Frame width: 930 mm Side frame opening: 705 mm

Condition: used, Year of construction: 2013, pressing force: 500 t, total length: 6,000 mm, total width: 3,000 mm, total height: 5,000 mm, overall weight: 200,000 kg, Press force: 16,000 kN Max. ram stroke: 1,700 mm Max. opening between table and ram: approx. 2,450 mm Min. opening: 770 mm Ram plate: 4,500 × 2,500 mm Table size: 4,500 × 2,500 mm Rapid traverse: 350 mm/s Working speed at 66% press force: 23 mm/s Working speed at 100% press force: 13 mm/s Max. return speed: 220 mm/s Max. retraction force: 1,600 kN Ram cushion: Dkjdpjzyd Hlofx Al Aju Force: 2,000 kN Stroke: 150 mm Pressure plate: 3,650 × 1,580 mm Table cushion: Force: 2 × 1,000 kN or 3 × 500 kN Stroke: 300 mm Pressure plate: 1,550 × 700 mm Drive: Main motors: 2 × 132 kW Motor filter unit: 4 kW Motor speed: 1,500 rpm Suitable for demanding forming, deep drawing, and pressing operations with large tools and high press forces. Pressing force max.: 500 t Dimensions (LxWxH) approx.: 6000 x 3000 x 5000 mm Weight approx.: 200,000 kg Year of construction: 2,013 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: used, Year of construction: 1991, functionality: fully functional, input voltage: 380 V, input current: 22 A, input frequency: 50 Hz, type of input current: three-phase, total length: 1,450 mm, total width: 1,800 mm, total height: 2,750 mm, overall weight: 3,500 kg, We are offering this used Walter hydraulic press, manufactured in 1991, for sale. Dkodezxp Ufjpfx Al Asu Year of manufacture: 1991 Condition: used No additional or special tools are included. If you have any questions or require further information, please feel free to send us a message or call us. Documentation is available.

Condition: used, Year of construction: 1999, Hydraulic press Dunkes HEZ 100-40, year of manufacture 1999 Hydraulic press Dunkes HS2 63, year of manufacture 1999 Dkodpfx Aozu Arvsl Asu Eccentric press Ebu 75, year of manufacture 1985

Condition: good (used), Year of construction: 1999, machine/vehicle number: H99-2989, functionality: fully functional, power: 24 kW (32.63 HP), input voltage: 400 V, input current: 63 A, input frequency: 50 Hz, pressing force: 63 t, stroke length: 420 mm, operating speed: 92 mm/s, reverse speed: 430 mm/s, table width: 620 mm, table length: 520 mm, table height: 1,000 mm, ram plate width: 600 mm, ram plate length: 400 mm, distance table to ram: 610 mm, clearance between the columns: 800 mm, oil tank capacity: 700 l, total length: 1,400 mm, total width: 1,900 mm, total height: 3,800 mm, overall weight: 4,500 kg, Equipment: CE marking, documentation/manual, For sale: hydraulic drawing press, in good condition, including drawing die (force 250 kN, stroke 150 mm, drawing die area 300 mm x 420 mm). Djdpfxjzl R Imo Al Ajku UVV inspections (occupational safety inspections) were carried out regularly, most recently in 2024. The machine was used in single-shift operation for prototype production. Price excludes dismantling and transportation.

Condition: new, Year of construction: 2026, machine/vehicle number: 06-26-005, functionality: fully functional, power: 17 kW (23.11 HP), input voltage: 400 V, type of input current: three-phase, pressing force: 160 t, stroke length: 500 mm, operating speed: 200 mm/s, reverse speed: 125 mm/s, table width: 900 mm, table length: 630 mm, throat depth: 360 mm, ram plate width: 750 mm, ram plate length: 450 mm, distance table to ram: 800 mm, total length: 2,200 mm, total width: 1,250 mm, total height: 3,500 mm, overall weight: 7,000 kg, year of last overhaul: 2026, controller manufacturer: SIEMENS, Equipment: CE marking, documentation/manual, safety light barrier, Hydraulic single-column press PYE 160 S1/M >completely overhauled / CE marking with  24 months warranty< from the manufacturer ZEULENRODA PRESSTECHNIK Hydraulic press for forming and assembly operations, pressing force 160 t Complete overhaul with CE conformity Ram stroke: 500 mm Clamping plate, press table: 900 x 580 mm with customer-specific clamping arrangement One-piece C-frame press in steel welded construction Newly manufactured table and ram plate according to customer requirements! Ram plate, twist-proof 3-sided protective guard, on the operator side via light curtain, on the side via sliding guard elements SIEMENS control system -new- Conversion to electronic stroke measuring system Remote maintenance ----- Further services, plant retrofit Control / Operation: Dedezf Ht Sopfx Al Ajku • Rapid traverse function • USB interface for data exchange • Touchscreen / visualization SIEMENS • Two-hand control unit with two-channel monitoring of the two-hand synchronous circuit on the press table, (incl. 5m cable) • Limit switches for stroke adjustment are replaced by initiators • Monitoring of the initial stroke after completion • Replacement of the existing 60-V DC solenoids on the pilot control valves with 24-V DC solenoids, including the necessary intermediate plates • The press has an electronic stroke measuring system (including teach-in function and display of the current ram position). This eliminates the mechanical cam switching mechanism. Hydraulic system • Hydraulic safety block for monitoring the closing movement on the main cylinder • Position-monitored directional control valve for the up and down movement of the ram • Replacement of the motors of the main and control pump • Replacement of the seals on the main cylinder • Fine filter with contamination indicator • All installation and piping work New documentation including CE declaration of conformity Delivery time / Implementation time: approx. 5 months

Condition: ready for operation (used), machine/vehicle number: 13214814, functionality: fully functional, power: 11 kW (14.96 HP), type of input current: three-phase, pressing force: 250 t, year of last overhaul: 2010, Equipment: documentation/manual, Hydraulic press, 250 tons – fully functional, manufactured in former East Germany (DDR), model VEB Wema Zeulenroda. Dkodpfx Alezbyxno Asu

Condition: new, Year of construction: 2026, machine/vehicle number: ST-150, functionality: fully functional, pressing force: 150 t, stroke length: 450 mm, operating speed: 3 mm/s, reverse speed: 10 mm/s, table width: 1,500 mm, table length: 3,000 mm, table height: 750 mm, distance table to ram: 700 mm, total length: 3,000 mm, total width: 3,000 mm, total height: 2,750 mm, overall weight: 5,000 kg, Equipment: CE marking, documentation/manual, MODEL ST-150 Capacity t 150 Motor power kW 4 Working speed mm/s 2.3 Approach speed mm/s 7.4 Return speed mm/s 10 Maximum pressure bar 305 Piston stroke – J mm 450 Lower table mm 1,500 x 3,000 Head travel – C mm 1,000 Bridge travel – D mm 2,500 Front opening – A mm 1,550 Vertical opening – B mm 700 Working height – E mm 750 Overall front dimension – G mm 3,000 Overall side dimension – H mm 3,000 Overall height – I mm 2,750 Weight kg 5,000 STANDARD DESCRIPTION: We have designed motorized hydraulic presses with a movable frame and adjustable head from the ST series, offering a range of three different capacities from 80 to 150 tons. Specifically designed for straightening welded structures and plates cut with oxy-fuel or laser. Its design facilitates the loading and unloading of large volumes: parts, plates, or structures. It allows access to different pressure points without the need to move the workpiece, thanks to the lateral displacement of the cylinder and the longitudinal movement of the frame. STRUCTURE AND TABLES: The ST series hydraulic presses consist of an electrowelded structure made exclusively of S355JR steel. It is stabilized and machined at the end of the welding process to ensure perfect parallelism and precision. Calculated and designed using finite element software. All of this guarantees our high standards of precision and quality. The longitudinal travel of the frame. CYLINDER AND HYDRAULIC UNIT: Double-acting cylinder with lapped liner, chrome-plated piston, and maintenance-free wear-resistant guides. Cylinder actuation via a lever-operated hydraulic distributor. Dkedpfxey E Iq Uj Al Aju It is equipped with a removable wiper to prevent piston damage. Two-speed motorized hydraulic unit with automatic disengagement of the approach speed by hydraulic pressure and a relief valve. ELECTRICAL INSTALLATION AND SAFETY: Electrical installation equipped with a motor guard with emergency stop. Supplied with a glycerin-filled pressure gauge with reading in tons and hydraulic oil. Complies with and meets all essential safety and health requirements according to CE regulations. Supplied with an instruction manual.

Condition: good (used), Year of construction: 1984, machine/vehicle number: 054-008-212, Offer 25272 Technical data: - Max. pressing force: 25 t - Max. ram stroke: 500 mm - Stroke speed: 0 – 2.4 m/min - Return speed: 0 – 12 m/min - Installation height: 800 mm - Throat depth to ram center: 360 mm - Ram clamping area: 440 x 360 mm - Ram mounting shank: 40 mm - Table size: 630 x 500 mm - Table bore/opening: 180 mm - Electric foot switch Dodpey Ewtrefx Al Asku - Two-hand control panel - Drive: 400 V / 8.75 kW - Required space approx.: W 800 x H 2750 x D 1150 mm - Weight approx.: 2000 kg

Condition: new, Year of construction: 2026, pressing force: 100 t, Durendus DCD-100 – Hydraulic Deep-Drawing Press in C-Frame Design 15–100 t – 800 × 600 mm For sale: a hydraulic C-frame deep-drawing press (single-column press) from Durendus with an adjustable pressing force from 15 to 100 t. This machine is designed for demanding forming, deep-drawing, and assembly tasks. It is equipped with an integrated deep-drawing cushion and a state-of-the-art Siemens control system. Featuring high travel speeds and precise control, it is ideal for both series production and flexible single-part applications. ===== Technical Data & Information: Hydraulic C-Frame Press – DCD-100 ==== General Specifications - Manufacturer: Durendus - Model: DCD-100 - Design: C-frame / single-column press - Pressing force: 15–100 t (adjustable) - Total weight: approx. 6,500 kg - Overall dimensions: approx. 1,850 × 1,845 × 3,520 mm - Table height above floor: 1,000 mm ==== Working Area - Max. distance table – ram: 1,000 mm - Stroke: 0–700 mm (adjustable) ==== Table & Ram - Table size: 800 × 600 mm - Ram size: 800 × 600 mm - T-slots: according to DIN 650, 18 mm, cross arrangement ==== Speeds - Rapid traverse speed: 180 mm/s - Working speed: 22 mm/s - Return speed: 180 mm/s ==== Hydraulics & Drive - Operating pressure: max. 250 bar - Main pump: Bosch Rexroth, approx. 65 l/min - Motor power: 11 kW + 1.5 kW - Oil tank capacity: approx. 280 l - Hydraulic block: Duplomatic - Filter: Filtrec - Cooling: air cooler ==== Additional Functions - Deep-drawing cushion: 50 t, stroke 250 mm, speed 50 mm/s - Ram ejector: 10 t, stroke 100 mm ==== Control & Operation - PLC: Siemens S7-1200 - Touch panel: Siemens SIMATIC 10" - Programmable: up to 99 programs - Adjustable: pressure, stroke, speed, lubrication - Positioning accuracy: up to 0.1 mm - Remote maintenance available ==== Safety & Equipment - Two-hand operation - Safety PLC - Monitoring of all operation statuses via display - Oil temperature and filter monitoring - Automatic shutdown in case of overheating ===== Deep-drawing, forming, assembly operations, punching processes, series production, toolmaking Single-column press, C-frame press, deep-drawing press, hydraulic press, industrial press, tryout press, tool try-out press Are you looking for a hydraulic press tailored to your specific application? Contact us for a customized offer. Our hydraulic presses are manufactured according to German machinery directives, as well as European Machinery Directive 2006/42/EC, EC standards, and EU safety requirements. Additionally, our presses exceed Canadian and European safety standards by fully complying with the national Brazilian safety guideline NR 12, which is based on these requirements. Our core strengths are special machine construction and press automation. We supply bespoke hydraulic presses at surprisingly competitive prices. For the hydraulics, we primarily use components from leading European manufacturers. Dksdpfxeyw I T Hs Al Aeu

Condition: excellent (used), pressure 16 t weight of the machine ca. 16 t Dedpfx Aoyrhmhel Asku

Condition: refurbished (used), Single-column hydraulic press (completely overhauled) PYE 160 S1M - Pressing force: 1600 kN - Installation height: 800 mm - Stroke: 500 mm Dedpfx Aoycl Hgel Asku - Speed: downwards 200 mm/s - Draw cushion selectable: 630 kN, stroke: 200 mm - Drive: 17 kW - Dimensions: 3500 x 2000 x 1200 mm - new control system, new switch cabinet, light curtain (1-stroke, 2-stroke, safety), new hydraulics, - new seals, paint finish as requested - new UVV safety inspection

Condition: refurbished (used), Single-column hydraulic press (completely overhauled) PYE 250 S1M with draw cushion - Pressing force: 2500 kN - Installation height: 800 mm - Stroke: 500 mm - Speed: downwards 200 mm/s - Draw cushion: 1000 kN, stroke: 200 mm - Drive: 20.5 kW - Dimensions: 3500 x 2000 x 1200 mm Dkjdjycl Evepfx Al Aeu can be retrofitted with: - new control system, new control cabinet, light curtain (1 cycle, 2 cycles, protection), new hydraulics, - new seals - new occupational safety inspection

Condition: excellent (used), functionality: fully functional, pressing force: 100 t, stroke length: 500 mm, operating speed: 200 mm/s, reverse speed: 200 mm/s, table width: 750 mm, table length: 560 mm, distance table to ram: 800 mm, total length: 1,560 mm, total width: 1,200 mm, total height: 3,200 mm, overall weight: 5,040 kg, The press is in nice condition. It is fully complete and under power. Dksdoxwuz Uspfx Al Aou

Condition: good (used), Year of construction: 1981, machine/vehicle number: 022-009-36, Offer 24374 Technical Data: - Max. pressing force: 100 t - Max. ram stroke approx.: 500 mm - Stroke speed: 25 mm/sec - Return speed: 125 mm/min - Installation height approx.: 1000 mm - Throat depth (to ram center): 380 mm - Ram clamping surface: 530 x 400 mm - Ram clamping pin: 40 mm - Table size: 750 x 560 mm - Table bore / through-hole: 200 mm - Table height above floor: 720 mm - Oil capacity approx.: 200 ltr - Drive: 400 V / 11 kW - Space requirements approx.: W 1150 x H 3250 x D 1850 mm - Weight approx.: 4600 kg Dodpfoxuhzcex Al Asku

Condition: used, Year of construction: 2001, Technical details: pressure: 250 t throat: 360 mm distance table/ram: 800 mm max. ram stroke: 500 mm ram speed - reverse: 390 mm/sec. ram speed - forward: 450 mm/sec. hydraulic-pressure: 280 bar connected load: 43 kW Dkedsxna Uzepfx Al Aou work speed: 11....50 mm/s operating pressure: 20 MPa total power requirement: 20,5 kW weight of the machine ca.: 17 t dimension machine xH: 3,9 x 1,9 x 4,0 m

Condition: new, Year of construction: 2024, functionality: fully functional, operating hours: 818 h, pressing force: 350 t, stroke length: 890 mm, warranty duration: 12 months, 📋 Technical Specifications (English) Capacity: 350 Tons at 250 bar (including auxiliary cylinders) Main Cylinder: Ø395 mm, Rod Ø300 mm, Stroke: 890 mm Auxiliary Cylinders: Ø80 x 100 mm, Rod Ø50 mm, Stroke: 890 mm Cushion Cylinders: Ø180 x 230 mm, Rod Ø115 mm (4 units) Motor: 18.5 kW – 25 HP, 1500 rpm, IE3, 380 V Pump: 71 cc, 105 L/min, variable displacement, pressure-compensated piston type (Taiwan, imported) Valve Block: NG-16, 24 DC, P-Q proportional control Equipped with precise proportional control for all movements: pump protection valve, decompression relief valve, ram–cushion line, pressure transmitter, auxiliary throat protection valve, cushion-seal protection valve, free fall valve. Electrical Panel: Siemens Screen: GMT 7” (domestic, 1-year warranty) Pre-Fill Valve: NG 160 (Taiwan model) Speeds: Dkjdpexf Dzgjfx Al Aju Down fast speed: 175 mm/s (P-Q proportional adjustable) Up fast speed: 285 mm/s (P-Q proportional adjustable) Pressing speed: 5 – 14.5 mm/s (P-Q proportional adjustable) Dimensions: Table 1200 x 1000 mm, Daylight 1000 mm Linear Scale: Yes Light Curtain: Yes Machine Weight: 15,000 kg ± Oil Tank: 1300 x 900 x 600 mm, 700 L capacity
