Nucleum Development Srl

Condition: good (used), Functionality: fully functional, power: 87 kW (118.29 HP), fuel type: diesel, fuel tank capacity: 80 l, overall weight: 8,350 kg, Year of construction: 2011, operating hours: 6,000 h, machine/vehicle number: CRG108371810-1, Equipment: crane, gripper hydraulics, hydraulics, rubber tracks, Atlas Copco drilling rig MUSTANG 4 - F1 Composed by: DRILL MAST BMI 3.9 HD - New roller type incl. chain feed, hyd. feed motor with gear reducer and neg. brake, Force on the Feed beam 85 kN Feed and retract force on Rotation Head 47 kN Feed length ..... 3900 mm Total length..... 5650 mm Feed rate speed..... 26m/min HOSE REEL. FOR FEED BEAM 3.9 and 3,9HD for guiding hyd. hoses to power head. OFF-HOLE SHIFT, hyd. operated, allows rotation head to move laterally 270 mm SERVICE CONTROL PANEL with valves laterally mounted DRILLING CONTROLS mounted on flexible arm SILENCED POWER UNIT with 2 hydraulic pumps A10V+A10V, Engine Deutz D 914 L06 2V step III, air cooled diesel engine rated 86,5 kW, 2300 rpm, 24V El. and safety system, oil tank 180l, filling pump, filter unit , fuel tank 80l and piping. Electrical oil cooler incorporated. MAST ATTACHMENT with hydraulic elevating device (double cylinder) and clamp for drill mast. ATTACHMENT for FEED HD type with 500 mm feed advance cylinder CRAWLER, U-F25-1-67 (7 rollers) hydraulically driven, with Rubber pads, Ground clearence 310mm Track width: 300 mm Track length: 2570 mm Crawler width: 1950 mm / Rig width 1950 mm Weight: 1050 kg crawler / 6300 kg rig Max inclination: 30° Max speed: 2,2 km/h Max totally traction force: 66,1 kN HYDRAULIC JACKS Set of four. stroke 4x 450 mm in rear and front elephant foots incl. EMERGENCY STOP DEVICE Always included in basic unit. ASSEMBLY KIT ROT.HEAD DHR48H56-68 Note: rotary head is not incl. in kit ROTARY HEAD DHR48H68-3 Rotation motors 2xOMSS250 Gear ratio : 4,31 :1 , Including floating sub 2 3/8 API Reg box SELECTOR VALVE KIT serial/parallell mode ROT. HEAD DHR48H68 given Serial mode rot.: 0-80 RPM - Torque 2850Nm Serial mode rot.: 0-40 RPM - Torque 5700Nm Figures at 90 l/min and 175 Bar HYD. ROD HOLDER AND BREAKER Incl. plate jaws. Free opening 250 mm. (Extend feed 360mm) Gripping force 88,25 kN (19,730 lbf.) at 180bar Breaking torque 23,8 kNm (5,400 lbf.) at 180 bar HYD OPERATED DIVERTER HEAD DHR48, basic kit including cutting collector head, attachment and two hyd cylinder Guides and seals for ODEX strings not included, To be specified and ordered separately GASKET DIVERTER HEAD tube 89mm GUIDE KIT Diverter head for casings 178mm 7 , MAIN HOIST with short crown block Hydraulically driven hoist HP6/E FH, with disc brake.Hydraulic shut-off device for minimum rope capacity. Steel wire 10mm, L=30m. Lifting hook. Short crown block Lebam type, to handle tubes in drill center. Max. pull capacity 1st layer :10,0 kN Max. lifting speed 1st layer :38m/min HOLD BACK DEVICE new type DTH HAMMER FOG LUBRICATOR LUBROSTAR type incl. high pressure air hose to swivel. Max. 30 bar operating pressure. Lubrication oil tank holds 10 litres. FOAM-WATER PUMP max flow 30 l/min Max delivery pressure 25 bar. RIG CLEANING DEVICE spray gun kit to be used in conjunction with foam water pump SWIVEL 4.5-SI for mud drill activities BELLIN PUMP type NG1200- L2PC max flow 660l/min at max 25 bar - rotor and stator fault WANGEN mud pump with helical rotor, 470 L/min, 25 bar - rotor and stator fault TILTABLE PIPE RACK 40PCS x 76mm x 3 tubes 7 BAR AIR OUTLET for grinder HYDRAULIC OUTLET FOR WELDER HYDRAULIC WELDING UNIT HWG 200-30 defective Gslhceuwfnajdwxjit ROUND JAWS SET FOR CASING OD 178 mm HOLD BACK PRESSURE SYSTEM drill pipe and accessories are sold separately
